JVC KD-R992BT User Manual

ENGLISH
37
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
Auxiliary
Frequency Response (±3dB) 20Hz—20kHz
Input Maximum Voltage 1000mV
Input Impedance 30kΩ
Audio
Maximum Output Power 50W×4 or
50W×2 + 50W×1 (Subwoofer = 4Ω)
Full Bandwidth Power
(at less than 1% THD)
22W×4
Speaker Impedance 4Ω—8Ω
Preout Level/Load (CD/USB)
KD-R992BT :
4000mV/10kΩ load
KD-R899BT / KD-R891BT /
KD-R794BT / KD-R792BT :
2500mV/10kΩ load
Preout Impedance ≤600Ω
General
Operating Voltage
(10.5V—16V allowable)
14.4V
Maximum Current Consumption 10A
Operating Temperature Range –10°C — +60°C
Installation Size (W×H×D) 182mm×53mm×158mm
Net Weight (includes Trimplate,
Mounting Sleeve)
1.2k
g
SPECIFICATIONS
JS_JVC_KD_R992BT_E_EN_3.indd 37JS_JVC_KD_R992BT_E_EN_3.indd 37 7/27/2017 9:47:25 AM7/27/2017 9:47:25 AM

JVC KD-R992BT Specifications

General

DIN size	1 DIN
Output power	200 W
Product color	Black
Ready for iPod	Yes
Disc types supported	CD
Audio output channels	- channels
Equalizer bands quantity	13
Maximum power per channel	50 W
Audio formats supported	AAC, FLAC, MP3, WMA
USB version	2.0
Bluetooth version	3.0+HS
USB port position	Front
Bluetooth profiles	A2DP, AVRCP
Line outputs (RCA)	3
USB connector type	USB Type-A
USB ports quantity	1
Hands-free calling	Keep your hands on wheel with Bluetooth™ Hands-free calling. After pairing your compatible Bluetooth mobile phone to your TomTom GPS, you’ll be able to see incoming call information, make and answer calls, and talk hands-free through your device. You’ll e
AM band range	531 - 1611 kHz
FM band range	87.5 - 108 MHz
LW band range	153 - 279 kHz
Supported radio bands	AM, FM
Preset stations quantity	24
Display type	LCD
Illumination color	White
Display number of lines	2 lines
Package weight	1700 g

Weight and Dimensions

Depth	158 mm
Width	182 mm
Height	53 mm
Weight	1200 g
