JVC KD-RD88BT - TECHNICAL SPECIFICATIONS - AUDIO & GENERAL; Audio Output Specifications

ENGLISH
38
Audio
Maximum Output Power 50W×4 or
50W×2 + 50W×1 (Subwoofer = 4Ω)
Full Bandwidth Power
(at less than 1% THD)
22W×4
Speaker Impedance 4Ω—8Ω
Preout Level/Load (CD/USB) 4000mV/10kΩ load
Preout Impedance ≤600Ω
General
Operating Voltage
(10.5V—16V allowable)
14.4V
Maximum Current Consumption 10A
Operating Temperature Range –10°C — +60°C
Installation Size (W×H×D) 182mm×53mm×159mm
(7-3/16"×2-1/8"×6-1/4")
Net Weight (includes Trimplate,
Mounting Sleeve)
1.2k
g (2.7lbs)
Subject to change without notice.
