KD-S7350/KD-S690

3-8

Item

Parts number Parts name Area

Electrical parts list (Main board)

Remarks

Block No. 01

C 1 QEKJ1CM-106Z E CAPACITOR

10MF 20% 16V

C 2 QEKJ1HM-224Z E CAPACITOR

.22MF 20% 50V

C 6 NCS31HJ-101X C CAPACITOR

C 12 QEKJ1HM-104Z E CAPACITOR

.10MF 20% 50V

C 14 NCB31EK-103X C CAPACITOR

C 17 NCS21HJ-560X C CAPACITOR

C 18 NDC31HJ-151X C CAPACITOR

C 21 QEKJ1CM-106Z E CAPACITOR

10MF 20% 16V

C 22 NCB31HK-223X C CAPACITOR

C 24 QEKJ1AM-227Z E CAPACITOR

220MF 20% 10V

C 31 QEKJ1HM-225Z E CAPACITOR

2.2MF 20% 50V

C 32 NCB31HK-102X C CAPACITOR

C 33 QEKJ1AM-227Z E CAPACITOR

220MF 20% 10V

C 35 NDC31HJ-470X C CAPACITOR

C 41 NCB31EK-563X C CAPACITOR

C 42 NCB31HK-123X C CAPACITOR

C 81 QEKJ1HM-105Z E CAPACITOR

1.0MF 20% 50V

C 82 QEKJ1HM-105Z E CAPACITOR

1.0MF 20% 50V

C 83 NCB21EK-333X C CAPACITOR

C 84 NCB21EK-333X C CAPACITOR

C 85 NCB31HK-103X C CAPACITOR

C 141 QEKJ1CM-476Z E CAPACITOR

47MF 20% 16V

C 142 QEKJ1AM-107Z E CAPACITOR

100MF 20% 10V

C 143 QEKJ1CM-107Z E CAPACITOR

100MF 20% 16V

C 144 NCB31EK-103X C CAPACITOR

C 151 QERF1HM-105Z E CAPACITOR

1.0MF 20% 50V

C 152 QERF1HM-105Z E CAPACITOR

1.0MF 20% 50V

C 162 NCB31HK-822X C CAPACITOR

C 163 NCB21CK-184X C CAPACITOR

C 164 NCB31AK-224X C CAPACITOR

C 165 NCB31EK-333X C CAPACITOR

C 166 NCB31HK-562X C CAPACITOR

C 167 QERF1EM-475Z E CAPACITOR

4.7MF 20% 25V

C 168 QERF1EM-475Z E CAPACITOR

4.7MF 20% 25V

C 172 NCB31HK-822X C CAPACITOR

C 173 NCB21CK-184X C CAPACITOR

C 174 NCB31AK-224X C CAPACITOR

C 175 NCB31EK-333X C CAPACITOR

C 176 NCB31HK-562X C CAPACITOR

C 183 NDC31HJ-391X C CAPACITOR

C 184 NDC31HJ-391X C CAPACITOR

C 185 QFV61HJ-334Z MF CAPACITOR

.33MF 5% 50V

C 186 QFV61HJ-334Z MF CAPACITOR

.33MF 5% 50V

C 187 QEKJ1EM-475Z E CAPACITOR

4.7MF 20% 25V

C 188 QEKJ1EM-475Z E CAPACITOR

4.7MF 20% 25V

C 193 NDC31HJ-391X C CAPACITOR

C 194 NDC31HJ-391X C CAPACITOR

C 195 QFV61HJ-334Z MF CAPACITOR

.33MF 5% 50V

C 196 QFV61HJ-334Z MF CAPACITOR

.33MF 5% 50V

C 242 QEKJ1CM-226Z E CAPACITOR

22MF 20% 16V

C 243 NCB31EK-473X C CAPACITOR

C 244 QEKJ1HM-224Z E CAPACITOR

.22MF 20% 50V

C 245 QEKJ1HM-105Z E CAPACITOR

1.0MF 20% 50V

C 300 NCB31HK-223X C CAPACITOR

C 303 NDC31HJ-101X C.CAPACITOR

C 304 NDC31HJ-101X C.CAPACITOR

C 305 NDC31HJ-101X C.CAPACITOR

C 306 NDC31HJ-101X C.CAPACITOR

C 308 QERF1EM-475Z E CAPACITOR

4.7MF 20% 25V

C 309 QERF1EM-475Z E CAPACITOR

4.7MF 20% 25V

C 313 NDC31HJ-101X C.CAPACITOR

C 314 NDC31HJ-101X C.CAPACITOR

C 315 NDC31HJ-101X C.CAPACITOR

C 316 NDC31HJ-101X C.CAPACITOR

C 317 NCB31HK-223X C CAPACITOR

C 318 QERF1CM-107Z E CAPACITOR

100MF 20% 16V

C 319 QEKJ1CM-476Z E CAPACITOR

47MF 20% 16V

C 320 QEKJ1CM-226Z E CAPACITOR

22MF 20% 16V

C 321 NDC31HJ-101X MG RESISTOR

KD-S7350

C 333 NCB31EK-273X C CAPACITOR

C 334 NCB31EK-273X C CAPACITOR

C 341 NDC31HJ-101X C.CAPACITOR

C 351 NDC31HJ-101X C.CAPACITOR

C 361 NCB31EK-104X C CAPACITOR

C 362 NCB31EK-104X C CAPACITOR

C 363 NCB31EK-104X C CAPACITOR

C 364 NCB31EK-104X C CAPACITOR

C 501 NCB31HK-103X C CAPACITOR

C 502 NCB31HK-103X C CAPACITOR

C 503 QEKJ1AM-107Z E CAPACITOR

100MF 20% 10V

C 504 NCB31HK-103X C CAPACITOR

C 505 QEKJ1AM-107Z E CAPACITOR

100MF 20% 10V

C 507 NCB31HK-682X C CAPACITOR

C 508 NCB31HK-103X C CAPACITOR

C 509 QEKJ1AM-107Z E CAPACITOR

100MF 20% 10V

C 510 NCB31CK-104X C CAPACITOR

C 511 NCB31CK-104X C CAPACITOR

C 512 NDC31HJ-820X C CAPACITOR

C 513 NCB31HK-103X C CAPACITOR

C 514 NDC31HJ-5R0X C CAPACITOR

C 521 NCB31HK-103X C CAPACITOR

C 522 QEKJ1AM-107Z E CAPACITOR

100MF 20% 10V

C 523 NDC31HJ-470X C CAPACITOR

C 524 NCB31HK-153X C CAPACITOR

C 525 NCB31HK-103X C CAPACITOR

C 526 NCB31HK-272X C CAPACITOR

C 527 NCB31HK-103X C CAPACITOR

C 528 NCB31EK-333X C CAPACITOR

C 530 NCB31EK-333X C CAPACITOR

C 531 NCB31EK-473X C CAPACITOR

C 533 NCS31HJ-471X C CAPACITOR

C 534 NCS31HJ-471X C CAPACITOR

C 535 NCB31EK-473X C CAPACITOR

C 536 NCB31EK-473X C CAPACITOR

C 537 NCB31EK-473X C CAPACITOR

C 538 NCB31EK-473X C CAPACITOR

C 539 QEKJ1CM-107Z E CAPACITOR

100MF 20% 16V

C 540 NCB31HK-103X C CAPACITOR

C 541 NCB31HK-103X C CAPACITOR

C 544 NCB31HK-103X C CAPACITOR

C 545 QEKJ1AM-107Z E CAPACITOR

100MF 20% 10V

C 546 NDC31HJ-101X C.CAPACITOR

C 547 NCB31CK-104X C CAPACITOR

C 548 QEKJ1AM-107Z E CAPACITOR

100MF 20% 10V

C 549 NCB31HK-103X C CAPACITOR

C 550 QEKJ1HM-105Z E CAPACITOR

1.0MF 20% 50V

C 551 QEKJ1AM-107Z E CAPACITOR

100MF 20% 10V

C 552 NCB31HK-103X C CAPACITOR

C 553 NDC31HJ-100X C CAPACITOR

C 554 NDC31HJ-100X C CAPACITOR

C 555 NDC31HJ-121X C CAPACITOR

C 556 QEKJ1AM-107Z E CAPACITOR

100MF 20% 10V

C 561 QEDJ1AM-476Z AL E.CAPACITOR

47MF 20% 10V

C 562 NCB31HK-103X C CAPACITOR

C 563 QEDJ1AM-107Z AL E.CAPACITOR

100MF 20% 10V

C 564 NCB31EK-473X C CAPACITOR

C 565 NCB31EK-473X C CAPACITOR

C 566 NCB31EK-473X C CAPACITOR

C 567 NCB31EK-473X C CAPACITOR

C 571 NCS31HJ-821X C CAPACITOR

C 572 QEKJ1EM-475Z E CAPACITOR

4.7MF 20% 25V

C 573 NCS31HJ-121X C CAPACITOR

Item

Parts number Parts name Area

Remarks

C 331 NDC31HJ-101X MG RESISTOR

KD-S7350
