KD-S7350/KD-S690
3-9
Item
Parts number Parts name Area
Electrical parts list (Main board)
Remarks
Block No. 01
A
C 574 NCS31HJ-821X C CAPACITOR
C 581 NCS31HJ-821X C CAPACITOR
C 582 QEKJ1EM-475Z E CAPACITOR
4.7MF 20% 25V
C 583 NCS31HJ-121X C CAPACITOR
C 584 NCS31HJ-821X C CAPACITOR
C 591 QERF1AM-107Z E CAPACITOR
100MF 20% 10V
C 592 QEKJ0JM-476Z E CAPACITOR
47MF 20% 6.3V
C 593 QEKJ0JM-476Z E CAPACITOR
47MF 20% 6.3V
C 701 QEKJ1AM-227Z E CAPACITOR
220MF 20% 10V
C 702 NCB31EK-104X C CAPACITOR
C 703 NCB31EK-104X C CAPACITOR
C 705 NDC31HJ-220X C CAPACITOR
C 706 NDC31HJ-220X C CAPACITOR
C 707 QEKJ1AM-227Z E CAPACITOR
220MF 20% 10V
C 708 NCB31EK-103X C CAPACITOR
C 710 NCB31EK-104X C CAPACITOR
C 711 NCS31HJ-102X C CAPACITOR
C CAPACITOR
C 717 NCB31EK-104X C CAPACITOR
C 718 NCB31EK-104X C CAPACITOR
C 901 QEZ0615-228 E CAPACITOR
2200MF
C 903 QEKJ1CM-476Z E CAPACITOR
47MF 20% 16V
C 904 QEKJ1CM-226Z E CAPACITOR
22MF 20% 16V
C 905 QEKJ1AM-227Z E CAPACITOR
220MF 20% 10V
C 906 QEKJ1HM-225Z E CAPACITOR
2.2MF 20% 50V
C 907 NCB31HK-103X C CAPACITOR
C 908 QEKJ1AM-227Z E CAPACITOR
220MF 20% 10V
C 909 QEKJ1AM-227Z E CAPACITOR
220MF 20% 10V
C 910 QEKJ1CM-106Z E CAPACITOR
10MF 20% 16V
C 913 QEKJ1CM-106Z E CAPACITOR
10MF 20% 16V
C 914 NCB31EK-104X C CAPACITOR
C 975 NCB31EK-823X C CAPACITOR
C 976 QERF0JM-476Z E CAPACITOR
47MF 20% 6.3V
C 977 QERF1CM-107Z E CAPACITOR
100MF 20% 16V
CJ 1 QNB0100-002 ANT TERMINAL
CJ321 QNN0519-001 PIN JACK
KD-S690
CJ321 QNN0490-001 PIN JACK
KD-S7350
CJ691 VMC0334-001 CONNECTOR
CN501 QGB2027M4-22S CONNECTOR
CN901 QNZ0611-001 CAR CONNECTOR
D 1 1SS355-X DIODE
D 2 1SS355-X DIODE
D 21 1SS355-X DIODE
D 22 1SS355-X DIODE
D 241 UDZS5.1B-X Z DIODE
D 242 RB160M-30-X SB DIODE
D 243 1SS355-X DIODE
D 244 1SS355-X DIODE
D 245 1SS355-X DIODE
D 301 1SS355-X DIODE
D 331 1SS355-X DIODE
D 341 1SS355-X DIODE
D 561 1A3G-T1 SI DIODE
D 701 UDZS6.2B-X SI DIODE
D 702 UDZS6.2B-X SI DIODE
D 703 UDZS6.2B-X SI DIODE
D 704 UDZS6.2B-X SI DIODE
D 705 UDZS6.2B-X SI DIODE
D 706 UDZS6.2B-X SI DIODE
D 707 UDZS6.2B-X SI DIODE
D 708 UDZS6.2B-X SI DIODE
D 709 UDZS6.2B-X SI DIODE
D 901 1N5401-F64 DIODE
D 903 1SS355-X DIODE
D 905 RB160M-30-X SB DIODE
D 906 RB160M-30-X SB DIODE
D 976 1SS355-X DIODE
D 977 UDZS11B-X Z.DIODE
IC161 TEA6320T-X IC
IC302 LA4743K IC
IC501 TA2157FN-X IC
IC521 TC94A14FA IC
IC561 LA6579H-X IC
IC571 HA17558F-X IC
IC701 UPD178078GF-592 I.C(MICRO-COMP)
IC901 HA13164A IC
L 1 QQL244J-4R7Z INDUCTOR
L 521 QQL244J-470Z INDUCTOR
L 522 QQL244J-470Z INDUCTOR
L 523 QQL244J-470Z INDUCTOR
L 524 QQL244J-470Z INDUCTOR
L 701 QQL244J-4R7Z INDUCTOR
L 702 QQL244J-4R7Z INDUCTOR
L 901 QQR1362-001 CHOKE COIL
1 KRC102S-X DIGITAL.TR
2 KRC102S-X DIGITAL.TR
21 2SB624/4/-X TRANSISTOR
22 2SB709A/R/-X TRANSISTOR
23 KRC102S-X DIGI.TRANSISTOR
31 2SD601A/R/-X TRANSISTOR
32 2SD601A/R/-X TRANSISTOR
41 2SC3661-X TRANSISTOR
42 2SC3661-X TRANSISTOR
241 2SD601A/R/-X TRANSISTOR
301 KRC102S-X DIGITAL.TR
321 2SD1781K/QR/-X TRANSISTOR
KD-S7350
341 2SD1781K/QR/-X TRANSISTOR
351 2SD1781K/QR/-X TRANSISTOR
501 2SB1241/QR/-T TRANSISTOR
521 UN2111-X TRANSISTOR
522 KRC102S-X DIGITAL.TR
561 2SB1322/RS/-T TRANSISTOR
963 2SB709A/R/-X TRANSISTOR
964 KRC102S-X DIGITAL.TR
976 UN2111-X TRANSISTOR
977 UN2111-X TRANSISTOR
R 1 NRSA63J-102X MG RESISTOR
R 2 NRSA63J-470X MG RESISTOR
R 3 NRSA63J-102X MG RESISTOR
R 5 NRSA63J-103X MG RESISTOR
R 8 NRSA63J-223X MG RESISTOR
R 9 NRSA63J-822X MG RESISTOR
R 10 NRSA63J-103X MG RESISTOR
R 21 NRSA63J-103X MG RESISTOR
R 22 NRSA63J-102X MG RESISTOR
R 23 NRSA63J-103X MG RESISTOR
R 24 NRSA02J-222X MG RESISTOR
R 25 NRS181J-150X MG RESISTOR
R 26 NRS181J-150X MG RESISTOR
R 27 NRSA02J-100X MG RESISTOR
R 31 NRSA63J-152X MG RESISTOR
R 32 NRSA63J-102X MG RESISTOR
R 33 NRSA02J-103X MG RESISTOR
R 34 NRSA02J-330X MG RESISTOR
R 41 NRSA63J-102X MG RESISTOR
R 42 NRSA63J-392X MG RESISTOR
R 43 NRSA02J-102X MG RESISTOR
R 81 NRSA63J-272X MG RESISTOR
R 82 NRSA63J-272X MG RESISTOR
R 83 NRSA63J-432X MG RESISTOR
R 84 NRSA63J-432X MG RESISTOR
R 91 NRSA63J-0R0X MG RESISTOR
R 161 NRSA63J-224X MG RESISTOR
Item
Parts number Parts name Area
Remarks
A
331 2SD1781K/QR/-X TRANSISTOR
