KD-S7350/KD-S690
3-10
Item
Parts number Parts name Area
Electrical parts list (Main board)
Remarks
Block No. 01
A
R 162 NRSA63J-223X MG RESISTOR
R 163 NRSA63J-222X MG RESISTOR
R 165 NRSA63J-473X MG RESISTOR
R 166 NRSA63J-473X MG RESISTOR
R 171 NRSA63J-224X MG RESISTOR
R 172 NRSA63J-223X MG RESISTOR
R 173 NRSA63J-222X MG RESISTOR
R 175 NRSA63J-271X MG RESISTOR
R 176 NRSA63J-271X MG RESISTOR
R 177 NRSA63J-472X MG RESISTOR
R 178 NRSA63J-472X MG RESISTOR
R 183 NRSA63J-273X MG RESISTOR
R 184 NRSA63J-273X MG RESISTOR
R 185 NRSA63J-473X MG RESISTOR
R 186 NRSA63J-473X MG RESISTOR
R 187 NRSA63J-100X MG RESISTOR
R 193 NRSA63J-273X MG RESISTOR
R 194 NRSA63J-273X MG RESISTOR
R 243 NRSA63J-102X MG RESISTOR
R 244 NRSA63J-224X MG RESISTOR
R 245 NRSA63J-123X MG RESISTOR
R 246 NRSA63J-184X MG RESISTOR
R 247 NRSA63J-223X MG RESISTOR
R 248 NRSA63J-470X MG RESISTOR
R 249 NRSA63J-473X MG RESISTOR
R 250 NRSA63J-221X MG RESISTOR
R 306 NRSA02J-471X MG RESISTOR
R 307 NRSA63J-472X MG RESISTOR
R 321 NRSA02J-102X MG RESISTOR
KD-S7350
R 322 NRSA02J-101X MG RESISTOR
KD-S7350
R 331 NRSA02J-102X MG RESISTOR
KD-S7350
R 335 NRSA02J-222X MG RESISTOR
KD-S7350
R 341 NRSA02J-821X MG RESISTOR
R 342 NRSA02J-101X MG RESISTOR
R 345 NRSA63J-222X MG RESISTOR
R 351 NRSA02J-821X MG RESISTOR
R 352 NRSA02J-101X MG RESISTOR
R 355 NRSA63J-222X MG RESISTOR
R 503 NRSA63J-823X MG RESISTOR
R 504 NRSA63J-823X MG RESISTOR
R 505 NRSA63J-334X MG RESISTOR
R 506 NRSA63J-334X MG RESISTOR
R 507 NRSA02J-220X MG RESISTOR
R 508 NRSA02J-220X MG RESISTOR
R 509 NRSA63J-823X MG RESISTOR
R 510 NRSA63J-563X MG RESISTOR
R 511 NRSA63J-103X MG RESISTOR
R 512 NRSA63J-202X MG RESISTOR
R 513 NRSA63J-102X MG RESISTOR
R 514 NRSA63J-153X MG RESISTOR
R 515 NRSA63J-101X MG RESISTOR
R 516 NRSA63J-821X MG RESISTOR
R 519 NRSA02J-151X MG RESISTOR
R 521 NRSA63J-562X MG RESISTOR
R 522 NRSA63J-473X MG RESISTOR
R 523 NRSA63J-474X MG RESISTOR
R 524 NRSA63J-153X MG RESISTOR
R 525 NRSA63J-103X MG RESISTOR
R 526 NRSA63J-0R0X MG RESISTOR
R 527 NRSA63J-101X MG RESISTOR
R 528 NRSA63J-101X MG RESISTOR
R 529 NRSA63J-0R0X MG RESISTOR
R 530 NRSA63J-0R0X MG RESISTOR
R 531 NRSA63J-101X MG RESISTOR
R 532 NRSA63J-101X MG RESISTOR
R 533 NRSA63J-105X MG RESISTOR
R 686 NRSA63J-473X MG RESISTOR
R 701 NRSA63J-472X MG RESISTOR
R 702 NRSA63J-472X MG RESISTOR
R 703 NRSA63J-472X MG RESISTOR
R 706 NRSA63J-222X MG RESISTOR
R 707 NRSA63J-222X MG RESISTOR
R 708 NRSA63J-0R0X MG RESISTOR
R 709 NRSA63J-222X MG RESISTOR
R 710 NRSA63J-473X MG RESISTOR
R 711 NRSA63J-473X MG RESISTOR
R 712 NRSA63J-473X MG RESISTOR
R 714 NRSA63J-103X MG RESISTOR
R 715 NRSA63J-103X MG RESISTOR
R 717 NRSA63J-103X MG RESISTOR
R 718 NRSA63J-472X MG RESISTOR
R 719 NRSA63J-103X MG RESISTOR
R 720 NRSA63J-472X MG RESISTOR
R 721 NRSA63J-103X MG RESISTOR
R 722 NRSA63J-472X MG RESISTOR
R 723 NRSA63J-473X MG RESISTOR
R 724 NRSA63J-473X MG RESISTOR
R 725 NRSA63J-473X MG RESISTOR
R 726 NRSA63J-0R0X MG RESISTOR
R 727 NRSA63J-0R0X MG RESISTOR
R 728 NRSA63J-473X MG RESISTOR
R 729 NRSA63J-473X MG RESISTOR
R 731 NRSA63J-473X MG RESISTOR
R 732 NRSA63J-103X MG RESISTOR
R 733 NRSA63J-473X MG RESISTOR
R 734 NRSA63J-104X MG RESISTOR
R 735 NRSA63J-103X MG RESISTOR
R 746 NRSA63J-103X MG RESISTOR
R 747 NRSA63J-103X MG RESISTOR
R 748 NRSA63J-103X MG RESISTOR
R 749 NRSA63J-0R0X MG RESISTOR
R 750 NRSA63J-473X MG RESISTOR
R 762 NRSA63J-473X MG RESISTOR
R 892 NRSA63J-222X MG RESISTOR
R 893 NRSA63J-473X MG RESISTOR
R 901 QRE142J-102X C RESISTOR
1.0K 5% 1/4W
R 902 NRSA02J-912X MG RESISTOR
R 903 NRSA02J-472X MG RESISTOR
R 905 NRSA63J-122X MG RESISTOR
R 906 NRSA63J-102X MG RESISTOR
R 907 NRS181J-222X MG RESISTOR
R 908 NRS181J-222X MG RESISTOR
R 967 NRSA63J-273X MG RESISTOR
R 968 NRSA63J-103X MG RESISTOR
R 976 NRSA63J-473X MG RESISTOR
TU 1 QAU0281-001 TUNER PACK
X 521 QAX0413-001Z CRYSTAL
X 701 QAX0406-001Z CRYSTAL
R 534 NRSA63J-472X MG RESISTOR
R 535 NRSA63J-472X MG RESISTOR
R 536 NRSA63J-472X MG RESISTOR
R 537 NRSA63J-472X MG RESISTOR
R 538 NRSA63J-103X MG RESISTOR
R 539 NRSA63J-155X MG RESISTOR
R 541 NRS181J-220X MG RESISTOR
R 542 NRS181J-220X MG RESISTOR
R 561 NRSA63J-333X MG RESISTOR
R 562 NRSA63J-822X MG RESISTOR
R 563 NRSA63J-472X MG RESISTOR
R 564 NRSA63J-153X MG RESISTOR
R 566 NRSA02J-822X MG RESISTOR
R 567 NRSA63J-682X MG RESISTOR
Item
Parts number Parts name Area
Remarks
A
R 325 NRSA63J-222X MG RESISTOR
KD-S7350
R 332 NRSA02J-101X MG RESISTOR
KD-S7350
