KD-S790
1-6 (No.49788)
2.1.6 Removing the main board
(See Fig.9)
• Prior to performing the following procedure, remove the front
panel assembly, front chassis assembly, heat sink, bottom
cover and rear bracket.
(1) Remove the two screws H attaching the main board.
(2) Disconnect connector CN501 and remove the main board.
Fig.9
2.1.7 Removing the CD mechanism assembly
(See Fig.10)
• Prior to performing the following procedure, remove the front
panel assembly, front chassis assembly, heat sink, bottom
cover, rear bracket and main board.
(1) Remove the three screws J .
Fig.10
Main board
H
H
CN501
J
J
CD mechanism assembly
Top chassis
