KD-S790
(No.49788)1-7
2.1.8 Removing the front board
(See Figs.11 to 13)
• Prior to performing the following procedure, remove the front
panel assembly.
(1) Remove the four screws K on the back side of the front
panel assembly.
(2) Release the ten joints f .
(3) Take out the front board.
Fig.11
Fig.12
Fig.13
KK
K
Joint f
Joint f
Joint f
Joint
Front board
