JVC KD-S847 - Page 29

KD-S847
(No.49832)1-29
4.3 IC-PST600M/G/-W (IC702) : System reset
• Block diagram
4.4 RPM6938-SV4 (IC602) : Remote control receiver
• Block diagram
IN
Vout
GND
1
3
2
OP1
Co1
AMP
AGC
Detector
BPF
I/V
conversion
PD
Vcc
Comp
22k
ohm
magnetic shield
VDD
OUT
GND
for
trimming circuit
3
1
2
