KD-S847
3-10
Front board
Block No. [0][2][0][0]
Symbol No. Part No. Part Name Description Local
IC601 LC75823W IC
D601 LNJ308G81/1-3/X LED
D602 LNJ308G81/1-3/X LED
D603 LNJ308G81/1-3/X LED
D604 LNJ308G81/1-3/X LED
D605 LNJ308G81/1-3/X LED
D606 LNJ308G81/1-3/X LED
D607 LNJ308G81/1-3/X LED
D608 LNJ308G81/1-3/X LED
D609 LNJ308G81/1-3/X LED
D610 LNJ308G81/1-3/X LED
D611 LNJ308G81/1-3/X LED
D612 LNJ308G81/1-3/X LED
D613 LNJ308G81/1-3/X LED
D614 LNJ308G81/1-3/X LED
D615 LNJ308G81/1-3/X LED
D616 LNJ308G81/1-3/X LED
D617 LNJ308G81/1-3/X LED
D618 LNJ308G81/1-3/X LED
D619 LNJ308G81/1-3/X LED
D620 LNJ308G81/1-3/X LED
D621 LNJ308G81/1-3/X LED
D622 SML-310LT/MN/-X LED
D641 UDZS5.1B-X Z DIODE
D642 1SS355-X SI DIODE
D645 UDZS6.2B-X Z DIODE
D731 NSPW310BS/BRS/ LED
D732 NSPW310BS/BRS/ LED
C601 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C602 NCS31HJ-681X C CAPACITOR 680pF 50V J
C603 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C613 NCB31HK-153X C CAPACITOR 0.015uF 50V K
C614 NCB31HK-153X C CAPACITOR 0.015uF 50V K
R601 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R602 NRSA63J-392X MG RESISTOR 3.9k
Ω
1/16W J
R603 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R604 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R605 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R606 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R607 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R608 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R609 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R610 NRSA63J-272X MG RESISTOR 2.7k
Ω
1/16W J
R612 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R613 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R614 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R615 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R616 NRSA63J-272X MG RESISTOR 2.7k
Ω
1/16W J
R631 NRSA02J-821X MG RESISTOR 820
Ω
1/10W J
R632 NRSA02J-821X MG RESISTOR 820
Ω
1/10W J
R633 NRSA02J-821X MG RESISTOR 820
Ω
1/10W J
R634 NRSA02J-511X MG RESISTOR 510
Ω
1/10W J
R635 NRSA02J-511X MG RESISTOR 510
Ω
1/10W J
R636 NRSA02J-821X MG RESISTOR 820
Ω
1/10W J
R637 NRSA02J-821X MG RESISTOR 820
Ω
1/10W J
R638 NRSA02J-331X MG RESISTOR 330
Ω
1/10W J
R639 NRSA02J-331X MG RESISTOR 330
Ω
1/10W J
R640 NRSA02J-511X MG RESISTOR 510
Ω
1/10W J
R641 NRSA02J-511X MG RESISTOR 510
Ω
1/10W J
R642 NRSA02J-511X MG RESISTOR 510
Ω
1/10W J
R643 NRSA02J-511X MG RESISTOR 510
Ω
1/10W J
R644 NRSA02J-821X MG RESISTOR 820
Ω
1/10W J
R645 NRSA02J-821X MG RESISTOR 820
Ω
1/10W J
R646 NRSA02J-821X MG RESISTOR 820
Ω
1/10W J
R647 NRSA02J-821X MG RESISTOR 820
Ω
1/10W J
R651 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R653 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R654 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R655 NRS181J-103X MG RESISTOR 10k
Ω
1/8W J
R656 NRS181J-103X MG RESISTOR 10k
Ω
1/8W J
R657 NRSA63J-513X MG RESISTOR 51k
Ω
1/16W J
R658 NRSA63J-184X MG RESISTOR 180k
Ω
1/16W J
R659 NRS181J-431X MG RESISTOR 430
Ω
1/8W J
R660 NRS181J-431X MG RESISTOR 430
Ω
1/8W J
R662 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
R672 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R673 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R674 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
CJ601 VMC0335-001 PANEL CONNECTOR
JS690 QSW0793-001 ROTARY ENCODER
S601 NSW0124-001X TACT SW
S602 NSW0124-001X TACT SW
S603 NSW0124-001X TACT SW
S604 NSW0124-001X TACT SW
S605 NSW0124-001X TACT SW
S606 NSW0124-001X TACT SW
S607 NSW0124-001X TACT SW
S608 NSW0124-001X TACT SW
S609 NSW0124-001X TACT SW
S610 NSW0124-001X TACT SW
S611 NSW0124-001X TACT SW
S612 NSW0124-001X TACT SW
S613 NSW0124-001X TACT SW
S614 NSW0124-001X TACT SW
S615 NSW0124-001X TACT SW
S616 NSW0124-001X TACT SW
S617 NSW0124-001X TACT SW
S618 NSW0124-001X TACT SW
