JVC KD-S847 - Page 36

KD-S847
1-36 (No.49832)
4.10 NJU7241F25-X (IC461) : Regulator
• Pin layout
• Block diagram
4.11 NJU7241F33-X (IC471) : Voltage regulator
• Pin layout
GND 1
VIN 2
VOUT 3
5 STB
4 NC
Short protect
3 VOU
T
1 GND
Vref
VIN 2
STB 5
GND 1
1
2
3
5
4
PIN FUNCTION
1. GND
2. V
IN
3. VOUT
4. +NC
5. STB
