KD-S847
3-3
General assembly
Block No. [M][1][M][M]
Symbol No. Part No. Part Name Description Local
1 ------------ CD MECHA
2 GE10043-210A TOP CHASSIS
3 GE40135-001A EARTH PLATE
4 GE30938-003A HEAT SINK
5 GE30393-002A BOTTOM COVER
6 FSMA3004-203 INSULATOR
7 QYSDST2604Z SCREW 2.6mm x 4mm(x3)
8 FSKZ4005-001 SCREW (x2)
9 QYSDST2606Z SCREW 2.6mm x 6mm(x2)
10 QYSDST2604Z SCREW 2.6mm x 4mm(x3)
11 QYSDST2610Z SCREW 2.6mm x 10mm
12 GE10056-001A FRONT CHASSIS
13 QYSDST2004M MINI SCREW 2mm x 4mm
14 GE30583-001A LOCK LEVER
15 FSKW4005-003 TORSION SPRING
16 FSKW3002-015 COMP.SPRING
17 FSXP3026-002 RLS KNOB
18 GE40140-001A BLIND
19 GE10057-001A FRONT PANEL
20 GE30802-008A FINDER ASSY
21 GE30105-002B POWER BUTTON
22 GE30815-002A VOLUME KNOB
23 GE30816-002A SEL BUTTON
24 FSYH4036-053 SHEET
25 GE30817-001A RIM LENS
26 GE30811-002A PUSH BUTTON
27 GE20143-001A PRESET BUTTON
28 GE30814-007A D. FUNC BTN DOW
29 GE30807-001A DETACH BUTTON
30 FSKW3002-012 COMP.SPRING
31 GE30818-001A NAVI BUTTON
32 GE30819-001A NAVI BASE
33 GE40127-002A COMP.SPRING
34 GE30813-001A D.FUNC BTN UP
35 GE30803-001A EJECT BUTTON
36 GE10058-001A REAR COVER
37 VKZ4777-001 MINI SCREW (x4)
38 GE30804-002A LCD CASE
39 GE30805-001A LCD LENS
40 GE30806-001A LENSCASE
41 GE40150-005A LIGHTING SHEET
42 GE30741-001A NAME PLATE
43 E70891-001 CLASS 1 LABEL
44 LV41843-001A LASER CAUTION
45 QLD0256-001 LCD MODULE
46 QNZ0442-001 LCD CONNECTOR
47 QMFZ047-150-T FUSE 15A
48 GE30912-008A REAR BRACKET
49 QYSDST2606Z SCREW 2.6mm x 6mm
50 QYSDST2606Z SCREW 2.6mm x 6mm
51 QYSDSF2606Z SCREW 2.6mm x 6mm(x2)
52 QYSDSF2606Z SCREW 2.6mm x 6mm
53 GE40172-002A IC BRACKET
54 GE40103-002A REG BRACKET
55 GE40107-002A HEAT SINK
56 GE30854-001A LED HOLDER
