24
ﻰﺳﺭﺎﻓ
ﺍﺪﺻ ﺕﺎﻤﻴﻈﻨﺗ
[SUBWOOFER
3*2* LPF]
[SW LPF FRQ]
/ [80HZ] / [70HZ] / [60HZ] / [50HZ] / [40HZ] / [30HZ]
/ [180HZ] / [150HZ] / [120HZ] / [100HZ] / [90HZ]
[THROUGH] / [250HZ] / [220HZ]
[SW LPF SLOPE]
[–24DB] / [–18DB] / [–12DB] / [–06DB]
[SW LPF PHASE]
(0°) [NORMAL] /(180°) [REVERSE]
[SW LPF GAIN]
[00DB] ﺎﺗ [–08DB]
ﻪﻓﺮﻃ 3 یﺭﺬﮔ ﻢﻫ ﻢﻴﻈﻨﺗ ﺩﺭﺍﻮﻣ
[SPEAKER SIZE]
[TWEETER]
[LARGE] / [MIDDLE] / [SMALL]
[MID RANGE]
/ [4×6] / [18CM] / [17CM] / [16CM] / [13CM] / [12CM] / [10CM] / [8CM]
[6×9]
/ [6×8] / [5×7]
3* [WOOFER] (ﻩﺪﺸﻧ ﻞﺼﺘﻣ) [NONE] / [38CM OVER] / [30CM] / [25CM] / [20CM] / [16CM]
[X ' OVER]
[TWEETER][HPF FRQ]
/ [6.3KHZ] / [5KHZ] / [4KHZ] / [2.5KHZ] / [1.6KHZ] / [1KHZ]
[12.5KHZ]
/ [10KHZ] / [8KHZ]
[SLOPE]
[–12DB] / [–06DB]
[PHASE]
(0°) [NORMAL] /(180°) [REVERSE]
[GAIN]
[00DB] ﺎﺗ [–08DB]
[MID RANGE][HPF FRQ] / [90HZ] / [80HZ] / [70HZ] / [60HZ] / [50HZ] / [40HZ] / [30HZ]
/ [250HZ] / [220HZ] / [180HZ] / [150HZ] / [120HZ] / [100HZ]
[THROUGH]
[HPF SLOPE]
[–12DB] / [–06DB]
[LPF FRQ]
/ [6.3KHZ] / [5KHZ] / [4KHZ] / [2.5KHZ] / [1.6KHZ] / [1KHZ]
[THROUGH]
/ [12.5KHZ] / [10KHZ] / [8KHZ]
[LPF SLOPE]
[–12DB] / [–06DB]
[PHASE]
(0°) [NORMAL] /(180°) [REVERSE]
[GAIN]
[00DB] ﺎﺗ [–08DB]
3* [WOOFER][LPF FRQ] / [90HZ] / [80HZ] / [70HZ] / [60HZ] / [50HZ] / [40HZ] / [30HZ]
/ [250HZ] / [220HZ] / [180HZ] / [150HZ] / [120HZ] / [100HZ]
[THROUGH]
[SLOPE]
[–12DB] / [–06DB]
[PHASE]
(0°) [NORMAL] /(180°) [REVERSE]
[GAIN]
[00DB] ﺎﺗ [–08DB]
ﻩﺩﺍﺩ ﺶﻳﺎﻤﻧ ﺪﺷﺎﺑ ﻩﺪﺷ ﻢﻴﻈﻨﺗ [REAR/SUB.W] ﺎﻳ [REAR/REAR] ￯ﻭﺭ ﺮﺑ [SPK/PRE OUT] ﻰﺘﻗﻭ ﻂﻘﻓ 1*
(22 ﻪﺤﻔﺻ) .ﺩﻮﺷ ﻰﻣ
ﻩﺪﺷ ﻢﻴﻈﻨﺗ
[SUB.W/SUB.W] ﺎﻳ [REAR/SUB.W] ￯ﻭﺭ ﺮﺑ [SPK/PRE OUT] ﻰﺘﻗﻭ ﻂﻘﻓ :KD-T752BT 2*
(22 ﻪﺤﻔﺻ) .ﺩﻮﺷ ﻰﻣ ﻩﺩﺍﺩ ﺶﻳﺎﻤﻧ ﺪﺷﺎﺑ
(21 ﻪﺤﻔﺻ) .ﺩﻮﺷ ﯽﻣ ﻩﺩﺍﺩ ﺶﻳﺎﻤﻧ ،ﺪﺷﺎﺑ ﻩﺪﺷ ﻢﻴﻈﻨﺗ
[ON] ￯ﻭﺭ ﺮﺑ [SUBWOOFER SET] ﯽﺘﻗﻭ ﻂﻘﻓ 3*
