(No.MA606<Rev.002>)2/20
SPECIFICATION
For US
• Subject to change without notice.
TUNER
FM Frequency Range 87.9 MHz - 107.9 MHz (200 kHz step)
87.5 MHz - 108.0 MHz (50 kHz step)
Channel Space Selection 50 kHz/200 kHz
Usable Sensitivity (S/N = 26 dB) 8.2 dBf (0.71 µV/75 Ω)
Quieting Sensitivity(DIN S/N = 46 dB) 17.2 dBf (2.0 µV/75 Ω)
Frequency Response (±3 dB) 30 Hz - 15 kHz
Signal-to-Noise Ratio (MONO) 64 dB
Stereo Separation (1 kHz) 40 dB
AM Frequency Range 530 kHz - 1 700 kHz (10 kHz step)
531 kHz - 1 611 kHz (9 kHz step)
Channel Space Selection 9 kHz/10 kHz
Usable Sensitivity (S/N = 20 dB) 29 dBµ (28.2 µV)
USB
USB Standard USB 1.1, USB 2.0 (Full speed)
Compatible Devices Mass storage class
File System FAT12/ 16/ 32
Maximum Supply Current DC 5 V 1 A
D/A Converter 24 Bit
Frequency Response (±1 dB) 20 Hz - 20 kHz
Signal-to-Noise Ratio (1 kHz) 105 dB
Dynamic Range 88 dB
Channel Separation 90 dB
MP3 Decode Compliant with MPEG-1/2 Audio Layer-3
WMA Decode Compliant with Windows Media Audio
AAC Decode AAC-LC ".m4a" files
WAV Decode RIFF waveform Audio Format (Linear PCM only)
FLAC Decode FLAC files
Auxiliary
Frequency Response (±3 dB) 20 Hz - 20 kHz
Input Maximum Voltage 1 000 mV
Input Impedance 30 kΩ
Audio
Maximum Output Power 50 W × 4 or 50 W × 2 + 50 W × 1 (Subwoofer = 4 Ω)
Full Bandwidth Power(at less than 1 % THD) 22 W × 4
Speaker Impedance 4 Ω - 8 Ω
Preout Level/Load (USB) 2 500 mV/10 kΩ
Preout Impedance ≤ 600 Ω
General
Operating Voltage (10.5 V - 16 V allowable) 14.4 V
Maximum Current Consumption 10A
Operating Temperature Range 0°C to + 40°C
Installation Size (W × H × D) 182 mm × 53 mm × 108 mm (7-3/16" × 2-1/8" × 4-5/16")
Weight 0.58 kg (1.3 lbs)
