JVC KD-X272BT User Manual

14
ENGLISH
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
• This unit supports Secure Simple Pairing (SSP).
• Up to five devices can be registered (paired) in total.
• Once the pairing is completed, the Bluetooth device will remain registered
in the unit even if you reset the unit. To delete the paired device, see
[DEVICE DELETE] on page17.
• A maximum of two Bluetooth phones and one Bluetooth audio device can
be connected at any time. To connect or disconnect the registered device,
see
[PHONESELECT] or [AUDIOSELECT] in [BTMODE] . (Page17)
However, while in BT AUDIO source, you can connect to five Bluetooth
audio devices and switch between these five devices. (Page18)
• Some Bluetooth devices may not automatically connect to the unit after
pairing. Connect the device to the unit manually.
• When the battery of the connected Bluetooth device runs low, “Device
Name”
“LOW BATTERY” appears.
• Refer to the instruction manual of the Bluetooth device for more
information.
Auto Pairing (for KD-X372BT)
When you connect iPhone/iPod touch to the USB input terminal, pairing
request (via Bluetooth) is automatically activated if
[AUTO PAIRING] is set to
[ON] . (Page17)
Press the volume knob to pair once you have confirmed the device name.
Bluetooth — Mobile phone
Receive a call
When there is an incoming call:
• The buttons will blink in the blinking pattern you have selected in
[RING ILLUMI] . (Page15)
• The unit answers the call automatically if
[AUTO ANSWER] is set to a selected
time. (Page15)
During a call:
• The buttons stop blinking.
• If you turn off the unit or detach the faceplate, Bluetooth is disconnected.
The following operations may differ or be unavailable depending on the
connected phone.
To On the faceplate
First incoming call...
Answer a call
Press
or the volume knob.
Reject a call
Press and hold
or the volume knob.
End a call
Press and hold
or the volume knob.
Bluetooth®
JS_JVC_KD_X372BT_E_EN_6th.indd 14JS_JVC_KD_X372BT_E_EN_6th.indd 14 18/7/2019 9:46:32 AM18/7/2019 9:46:32 AM

JVC KD-X272BT Specifications

General

DIN size	-
Output power	400 W
Product color	Black
Volume control	Rotary
High pass filter	Yes
Disc types supported	No
Audio output channels	- channels
Equalizer bands quantity	13
Maximum power per channel	50 W
Audio formats supported	AAC, FLAC, MP3, SBC, WAV, WMA
Display type	LCD
Bluetooth version	4.2
USB port position	Front
Bluetooth profiles	A2DP, AVRCP, PBAP
Line outputs (RCA)	1
USB connector type	Mini-USB A
Bluetooth functions	Handsfree calling
Hands-free calling	Keep your hands on wheel with Bluetooth™ Hands-free calling. After pairing your compatible Bluetooth mobile phone to your TomTom GPS, you’ll be able to see incoming call information, make and answer calls, and talk hands-free through your device. You’ll e
Package width	900 mm
AM band range	153 - 531 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM

Weight and Dimensions

Weight	600 g
