JVC KD-X361BT User Manual

9
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
BLUETOOTH®
Depending on the operating system and the firmware version of your
mobile phone, Bluetooth features may not work with this unit.
Connect the microphone
Connect the supplied microphone to the microphone input jack on the rear
panel.
Adjust the
microphone
angle
Secure using cord
clamps (not supplied)
if necessary.
Pair and connect a Bluetooth device for the first time
1 Press SRC-B to turn on the unit.
2 Search and select the name of your receiver (“KD-X3 BT”) on the
Bluetooth device.
3 Perform (A) or (B) depending on what appears on the display.
For some Bluetooth devices, pairing sequence may vary from the steps
described below.
(A) “[Device Name]”
“XXXXXX” “ENTER–YES” “BACK–NO”
“XXXXXX” is a 6-digit passkey randomly generated during each pairing.
Ensure that the passkeys appear on the unit and Bluetooth device
are the same.
Press * ENTER to confirm the passkey.
Operate the Bluetooth device to confirm the passkey.
(B) “[Device Name]”
“ENTER–YES” “BACK–NO”
Press * ENTER to start pairing.
• If “PAIRING” “PIN 0000” scrolls on the display, enter the PIN code
“0000” into the Bluetooth device.
• If only “PAIRING” appears, operate the Bluetooth device to confirm
pairing.
“PAIRING COMPLETED” appears when pairing is completed and “
” will light
up when the Bluetooth connection is established.
Answer a call
Press or * ENTER.
• To adjust the phone volume [00] to [35] , press VOL +/–.
• To end a call, press and hold or * ENTER.
Audio player via Bluetooth
1 Press SRC-B repeatedly to select BTAUDIO.
• Pressing enters BT AUDIO directly.
2 Operate the audio player via Bluetooth to start playback.
To On the faceplate
Play back/pause
Press * ENTER.
Select group or folder
Press 2 J / 1 K.
Reverse skip/Forward skip
Press S / T.
Reverse/Fast-forward
Press and hold S / T.
Repeat play
Press 4  repeatedly.
Random play
Press 3  repeatedly.
JS_JVC_QSG_KD_X361BT_E_EN_1.indd 9JS_JVC_QSG_KD_X361BT_E_EN_1.indd 9 6/13/2018 10:46:26 AM6/13/2018 10:46:26 AM

JVC KD-X361BT Specifications

General

DIN size	1 DIN
Output power	350 W
Product color	Black
Ready for iPod	Yes
Disc types supported	No
Audio output channels	- channels
Equalizer bands quantity	13
Maximum power per channel	50 W
Audio system	MOSFET
Display type	LCD
Bluetooth version	3.0+HS
Bluetooth functions	Audiostreaming, Handsfree calling
AM band range	531 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	24
Hands-free calling	Keep your hands on wheel with Bluetooth™ Hands-free calling. After pairing your compatible Bluetooth mobile phone to your TomTom GPS, you’ll be able to see incoming call information, make and answer calls, and talk hands-free through your device. You’ll e
Package weight	900 g

Weight and Dimensions

Depth	100 mm
Width	182 mm
Height	53 mm
Weight	600 g
