3-6
PWM-C board
Block No. [0][2]
Sub1 board
Block No. [0][3]
RU1 HR300011C CHIP RESISTOR 2012 2.7 K Ω
RU2 HR300011C CHIP RESISTOR 2012 2.7 K Ω
SE1 HR107023A C.F RESISTOR 1/8W 1.5 K Ω 1%
SE2 HR107023A C.F RESISTOR 1/8W 1.5 K Ω 1%
TRH1 HR300006C CHIP RESISTOR 2012 100 K Ω
L1 HO501201H-3 BEED ATS 3550
L2 HO501201H-3 BEED ATS 3550
L3 HO501201H-3 BEED ATS 3550
L4 HO501201H-3 BEED ATS 3550
CON1 HK502506H WAFER YMW 025-09P
CON2 HK502504H WAFER YMW 025-03P
CON3 HK502505H WAFER YMW 025-02P
CON2-1 HE503026H CONNECTOR WIRE #26 3P 100M/M
2.5mm pitch
CON3-1 HE503025H CONNECTOR WIRE #26 2P 80M/M
2.5mm pitch
FUSE1 HH500007H FUSE HOLD BXS02-10
HI1 HE503020H HI INPUT 4P MOLD
JP1 HJ502004H JUMP PLATE 5P GOLD 15m/m pitch
JP2 HJ502003H JUMP PLATE 4P GOLD 15m/m pitch
JP3 HO501201H-4 CUPPER WIRE 2PHI 90m/m
(H= 15m/m)
JP4 HO501201H-5 CUPPER WIRE 2PHI 100m/m
(H= 15m/m)
JP5 HO501201H-5 CUPPER WIRE 2PHI 100m/m
(H= 15m/m)
JP6 HO501201H-4 CUPPER WIRE 2PHI 90m/m
(H= 15m/m)
RCA1 HK501013H RCA JACK AV4-8 4-38 (R/W)
RFC1 HO501201H-2 RFC 27PHI 11L 5T
TER1 HM505017H TERMINAL WB03-33GDTH
(MILKY)
TER2 HM505019H TERMINAL WB04-34GDTH
(MILKY)
TH1 HR506004H THERMISTOR NTC5D-153H25-BK
(MOLD)
TH2 HR506004H THERMISTOR NTC5D-153H25-BK
(MOLD)
TRANS1 HO501201H-1 POWER TRANS 4916 5/16/8 T1=4T
(4T/8T=7)
 Symbol No. Part No. Part Name Description Local
IC1 HI500005H IC KIA494AF
IC2 HI300002C IC NJM2904M
IC3 HI300002C IC NJM2904M
QB1 KTC4373YRTF TRANSISTOR HT300003C
QB2 KTC3875YRTF TRANSISTOR HT300004C
QB3 KTC3875YRTF TRANSISTOR HT300004C
QS1 KTA1661YRTF TRANSISTOR HT300002C
D1 LL4148 SWITCH DIODE HD300001C
D2 LL4148 SWITCH DIODE HD300001C
D3 LL4148 SWITCH DIODE HD300001C
D4 LL4148 SWITCH DIODE HD300001C
DB1 LL4148 SWITCH DIODE HD300001C
DG1 LL4148 SWITCH DIODE HD300001C
DG2 LL4148 SWITCH DIODE HD300001C
DS1 LL4148 SWITCH DIODE HD300001C
DS2 LL4148 SWITCH DIODE HD300001C
ZG1 HD301004C Z DIODE 201215V
ZG2 HD301003C Z DIODE 20126.2V
C1 HC202007R E CAPACITOR 16V 100uF
C2 HC202007R E CAPACITOR 16V 100uF
C3 HC202007R E CAPACITOR 16V 100uF
C4 HC202001R E CAPACITOR 50V 0.1uF
C6 HC205001R TF CAPACITOR 102
C7 HC205004R METAL CAPACITOR 47nJ 100V (473)
C8 HC300007C CHIP CAPACITOR 2012 104
 Symbol No. Part No. Part Name Description Local
C9 HC300007C CHIP CAPACITOR 2012 104
C10 HC300007C CHIP CAPACITOR 2012 104
C11 HC300007C CHIP CAPACITOR 2012 104
CB1 HC300007C CHIP CAPACITOR 2012 104
CB2 HC300007C CHIP CAPACITOR 2012 104
CG1 HC300007C CHIP CAPACITOR 2012 104
CS1 HC202032R E CAPACITOR 100V 10uF
CS2 HC202007R E CAPACITOR 16V 100uF
CX1 HC300004C CHIP CAPACITOR 2012 102
R1 HR300003C CHIP RESISTOR 2012 10 K Ω
R2 HR300001C CHIP RESISTOR 2012 1 K Ω
R3 HR300011C CHIP RESISTOR 2012 2.7 K Ω
R4 HR300011C CHIP RESISTOR 2012 2.7 K Ω
R6 HR300004C CHIP RESISTOR 2012 15 K Ω
R7 HR300053C CHIP RESISTOR 2012 20 K Ω
R8 HR300022C CHIP RESISTOR 2012 470 K Ω
R9 HR300011C CHIP RESISTOR 2012 2.7 K Ω
R10 HR300011C CHIP RESISTOR 2012 2.7 K Ω
R11 HR300005C CHIP RESISTOR 2012 18 K Ω
R12 HR300017C CHIP RESISTOR 2012 33 K Ω
R13 HR300017C CHIP RESISTOR 2012 33 K Ω
R14 HR300021C CHIP RESISTOR 2012 470 Ω
R16 HR300041C CHIP RESISTOR 2012 3.9 K Ω
R19 HR300002C CHIP RESISTOR 2012 1 M Ω
R20 HR300019C CHIP RESISTOR 2012 4.7 K Ω
R21 HR300005C CHIP RESISTOR 2012 18 K Ω
R22 HR300026C CHIP RESISTOR 2012 1 K Ω
R23 HR300026C CHIP RESISTOR 2012 1 K Ω
RB1 HR300019C CHIP RESISTOR 2012 4.7 K Ω
RB2 HR300003C CHIP RESISTOR 2012 10 K Ω
RG1 HR300001C CHIP RESISTOR 2012 1 K Ω
RG2 HR300003C CHIP RESISTOR 2012 10 K Ω
RG3 HR300016C CHIP RESISTOR 2012 3.3 K Ω
RG4 HR300025C CHIP RESISTOR 2012 6.8 K Ω
RG5 HR300025C CHIP RESISTOR 2012 6.8 K Ω
RG6 HR300025C CHIP RESISTOR 2012 6.8 K Ω
RG7 HR300003C CHIP RESISTOR 2012 10 K Ω
RG8 HR300010C CHIP RESISTOR 2012 2.2 K Ω
RS1 HR300011C CHIP RESISTOR 2012 2.7 K Ω
RS2 HR300003C CHIP RESISTOR 2012 10 K Ω
RS3 HR300020C CHIP RESISTOR 2012 47 K Ω
RS4 HR300019C CHIP RESISTOR 2012 4.7 K Ω
RS5 HR300003C CHIP RESISTOR 2012 10 K Ω
PIN1 HK502502H WAFER FAU0640-06P
PIN2 HK502503H WAFER FAU0640-07P
PIN3 HK502501H WAFER FAU0640-03P
 Symbol No. Part No. Part Name Description Local
ICF5 HI300006C IC NJM 2068(M)
ICF6 HI300006C IC NJM 2068(M)
ICF7 HI300006C IC NJM 2068(M)
ICS1 HI300006C IC NJM 2068(M)
ICS2 HI300006C IC NJM 2068(M)
ICS3 HI300006C IC NJM 2068(M)
ICS4 HI300006C IC NJM 2068(M)
ICS5 HI300006C IC NJM 2068(M)
ICS6 HI300006C IC NJM 2068(M)
ICS7 HI300006C IC NJM 2068(M)
ICX1 HI300006C IC NJM 2068(M)
CF7A HC300015C CHIP CAPACITOR 2012 47P
CF7B HC300015C CHIP CAPACITOR 2012 47P
CF8A HC300004C CHIP CAPACITOR 2012 102
CF8B HC300004C CHIP CAPACITOR 2012 102
CF9A HC202002R E CAPACITOR 50V 2.2uF
CF9B HC202002R E CAPACITOR 50V 2.2uF
CF10A HC205011R METAL CAPACITOR 100nJ 100V (104)
CF10B HC205011R METAL CAPACITOR 100nJ 100V (104)
 Symbol No. Part No. Part Name Description Local
