3-7
CS1 HC202006R E CAPACITOR 16V 47uF
CS2 HC202006R E CAPACITOR 16V 47uF
CS1A HC300015C CHIP CAPACITOR 2012 47P
CS1B HC300015C CHIP CAPACITOR 2012 47P
CS2A HC205013R METAL CAPACITOR 82nJ 100V (823)
CS2B HC205013R METAL CAPACITOR 82nJ 100V (823)
CS3A HC205013R METAL CAPACITOR 82nJ 100V (823)
CS3B HC205013R METAL CAPACITOR 82nJ 100V (823)
CS4A HC205013R METAL CAPACITOR 82nJ 100V (823)
CS4B HC205013R METAL CAPACITOR 82nJ 100V (823)
CS5A HC305002C CHIP CAPACITOR 3216 224
CS5B HC305002C CHIP CAPACITOR 3216 224
CS6A HC305002C CHIP CAPACITOR 3216 224
CS6B HC305002C CHIP CAPACITOR 3216 224
JS1 HR300031C CHIP RESISTOR 2012 0 Ω
RF9A HR300010C CHIP RESISTOR 2012 2.2 K Ω
RF9B HR300010C CHIP RESISTOR 2012 2.2 K Ω
RF10A HR300019C CHIP RESISTOR 2012 4.7 K Ω
RF10B HR300019C CHIP RESISTOR 2012 4.7 K Ω
RF11A HE503075H CHIP RESISTOR 2012 68 K Ω
RF11B HE503075H CHIP RESISTOR 2012 68 K Ω
RF12A HR300020C CHIP RESISTOR 2012 47 K Ω
RF12B HR300020C CHIP RESISTOR 2012 47 K Ω
RF13A HR300019C CHIP RESISTOR 2012 4.7 K Ω
RF13B HR300019C CHIP RESISTOR 2012 4.7 K Ω
RF14A HR300003C CHIP RESISTOR 2012 10 K Ω
RF14B HR300003C CHIP RESISTOR 2012 10 K Ω
RF15A HR300041C CHIP RESISTOR 2012 3.9 K Ω
RF15B HR300041C CHIP RESISTOR 2012 3.9 K Ω
RF16A HR300021C CHIP RESISTOR 2012 470 Ω
RF16B HR300021C CHIP RESISTOR 2012 470 Ω
RF17A HR300037C CHIP RESISTOR 2012 120 K Ω 1%
RF17B HR300037C CHIP RESISTOR 2012 120 K Ω 1%
RS1 HR300003C CHIP RESISTOR 2012 10 K Ω
RS2A HR300020C CHIP RESISTOR 2012 47 K Ω
RS2B HR300020C CHIP RESISTOR 2012 47 K Ω
RS3A HR300003C CHIP RESISTOR 2012 10 K Ω
RS3B HR300003C CHIP RESISTOR 2012 10 K Ω
RS4A HR300003C CHIP RESISTOR 2012 10 K Ω
RS4B HR300003C CHIP RESISTOR 2012 10 K Ω
RS5A HR300003C CHIP RESISTOR 2012 10 K Ω
RS5B HR300003C CHIP RESISTOR 2012 10 K Ω
RS6A HR300041C CHIP RESISTOR 2012 3.9 K Ω
RS6B HR300041C CHIP RESISTOR 2012 3.9 K Ω
RS7A HR300041C CHIP RESISTOR 2012 3.9 K Ω
RS7B HR300041C CHIP RESISTOR 2012 3.9 K Ω
RS8A HR300041C CHIP RESISTOR 2012 3.9 K Ω
RS8B HR300041C CHIP RESISTOR 2012 3.9 K Ω
RS9A HR300003C CHIP RESISTOR 2012 10 K Ω
RS9B HR300003C CHIP RESISTOR 2012 10 K Ω
RS10A HR300019C CHIP RESISTOR 2012 4.7 K Ω
RS10B HR300019C CHIP RESISTOR 2012 4.7 K Ω
RS11A HR300019C CHIP RESISTOR 2012 4.7 K Ω
RS11B HR300019C CHIP RESISTOR 2012 4.7 K Ω
RS12A HE503075H CHIP RESISTOR 2012 68 K Ω
RS12B HE503075H CHIP RESISTOR 2012 68 K Ω
RS13A HR300049C CHIP RESISTOR 2012 56 K Ω
RS13B HR300049C CHIP RESISTOR 2012 56 K Ω
RS14A HR300003C CHIP RESISTOR 2012 10 K Ω
RS14B HR300003C CHIP RESISTOR 2012 10 K Ω
RS15A HR300003C CHIP RESISTOR 2012 10 K Ω
RS15B HR300003C CHIP RESISTOR 2012 10 K Ω
RS16A HR300020C CHIP RESISTOR 2012 47 K Ω
RS16B HR300020C CHIP RESISTOR 2012 47 K Ω
RS17A HR300054C CHIP RESISTOR 2012 22 Ω
RS17B HR300054C CHIP RESISTOR 2012 22 Ω
RX1 HR300003C CHIP RESISTOR 2012 10 K Ω
RX2 HR300003C CHIP RESISTOR 2012 10 K Ω
VR1 HV500048H VOLUME V09M 3B20KX2
(S=10mm)NEW
VR2 HV500049H VOLUME V09M 15C10KX2
(S=10mm)NEW
CON1-1 HE503027H CONNECTOR WIRE #26 9P 210M/M
2.5mm pitch
SW1 HW501012H SWITCH KSA2342T (9)
VRS1 HV500052H VOLUME V09M 15C50KX6
(S=10mm)NEW
 Symbol No. Part No. Part Name Description Local
