3-3
General Assembly
Block No. [M][1][M][M]
Symbol No. Part No. Part Name Description Local
1 LV22109-002A PWB BRACKET-L
2 LV22110-002A PWB BRACKET-R
3 LV44487-001A SPACER (x2)
4 LV44487-002A SPACER (x2)
5 LV40846-048A SPACER(F) (x2)
6 QYSDSG3006ZA TAP SCREW M3 x 6mm(x2)
7 QYSDSG3006ZA TAP SCREW M3 x 6mm
8 QYSDSG3008ZA TAP SCREW M3 x 8mm(x4)
9 QYSBST3006ZA TAP SCREW M3 x 6mm(x2)
10 QYSDSG3006ZA TAP SCREW M3 x 6mm(x2)
11 QYSDSG3008ZA TAP SCREW M3 x 8mm(x2)
12 LV36141-004A LED PWB BRACKET
13 LV36141-005A LED PWB BRACKET
14 LV22107-002A FRONT PANEL
15 QYSDSG3008MA TAP SCREW M3 x 8mm(x2)
16 QYSDSG3008MA TAP SCREW M3 x 8mm(x4)
17 QYSPSF2008MA TAP SCREW M2 x 8mm(x4)
18 QYSDSG3008MA TAP SCREW M3 x 8mm(x2)
19 QYSDSG3008MA TAP SCREW M3 x 8mm(x2)
20 LV11140-001A MAIN COVER
21 LV40847-031A SPACER(H) (x2)
22 LV40847-032A SPACER(H)
23 LV36173-002A LED LENS
24 QYSDSG3008ZA TAP SCREW M3 x 8mm
25 LV36143-002A WINDOW FRAME
26 LV36241-002A WINDOW SHEET
27 LV36142-002A MESH WINDOW
28 QYSDSG3006MA TAP SCREW M3 x 6mm(x2)
29 LV44496-001A SPACER
30 LV40846-050A SPACER(F) (x2)
31 LV22102-001A TOP COVER
32 QYSDSG3010MA TAP SCREW M3 x 10mm(x3)
33 LV22118-001A TOP LED LENS
34 LV44458-003A SCREW (x4)
35 QYSDSG3010ZA TAP SCREW M3 x 10mm(x2)
36 LV22112-002A BOTTOM PLATE
37 QYSDSG3010MA TAP SCREW M3 x 10mm(x4)
38 QYSDSG3010MA TAP SCREW M3 x 10mm(x2)
39 LV22113-001A COVER-L
40 LV22114-001A COVER-R
41 QYYYSP4008RA BOLT M4 x 8mm(x6)
42 LV44484-001A SPACER (x2)
43 LV36745-001A NAME PLATE J
43 LV36723-001A NAME PLATE E,U
44 QMFZ047-400-T FUSE 40A(x2)
45 LV36139-003A SUB HEAT SINK-L
46 LV36140-003A SUB HEAT SINK-R
47 LV36138-003A SUB HEAT SINK-1 (x2)
48 LV44458-003A SCREW (x10)
49 QYSDSG3008ZA TAP SCREW M3 x 8mm(x8)
50 LV44458-002A ASSY T.SCREW (x8)
51 LV44458-001A ASSY T.SCREW (x2)
52 LV44388-002A SUB HS SHEET 1 (x2)
53 LV44389-002A SUB HS SHEET 1 (x2)
54 LV44385-001A RECYCLE LABEL E
