3-8
Signal control board
Block No. [0][2]
R601 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R609 NRS181F-223X MG RESISTOR 22k
Ω
1/8W F
R610 NRS181F-823X MG RESISTOR 82k
Ω
1/8W F
R611 NRS181F-273X MG RESISTOR 27k
Ω
1/8W F
R612 NRS181F-223X MG RESISTOR 22k
Ω
1/8W F
R613 NRS181F-823X MG RESISTOR 82k
Ω
1/8W F
R614 NRS181F-273X MG RESISTOR 27k
Ω
1/8W F
R615 NRS144J-102X MG RESISTOR 1k
Ω
1/4W J
R621 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R622 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R625 NRS181F-223X MG RESISTOR 22k
Ω
1/8W F
R626 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R701 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R707 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R709 NRS181F-223X MG RESISTOR 22k
Ω
1/8W F
R710 NRS181F-823X MG RESISTOR 82k
Ω
1/8W F
R711 NRS181F-273X MG RESISTOR 27k
Ω
1/8W F
R712 NRS181F-223X MG RESISTOR 22k
Ω
1/8W F
R713 NRS181F-823X MG RESISTOR 82k
Ω
1/8W F
R714 NRS181F-273X MG RESISTOR 27k
Ω
1/8W F
R715 NRS144J-102X MG RESISTOR 1k
Ω
1/4W J
R721 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R722 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R725 NRS181F-223X MG RESISTOR 22k
Ω
1/8W F
R726 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R801 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R809 NRS181F-223X MG RESISTOR 22k
Ω
1/8W F
R810 NRS181F-823X MG RESISTOR 82k
Ω
1/8W F
R811 NRS181F-273X MG RESISTOR 27k
Ω
1/8W F
R812 NRS181F-223X MG RESISTOR 22k
Ω
1/8W F
R813 NRS181F-823X MG RESISTOR 82k
Ω
1/8W F
R814 NRS181F-273X MG RESISTOR 27k
Ω
1/8W F
R815 NRS144J-102X MG RESISTOR 1k
Ω
1/4W J
R821 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R822 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R825 NRS181F-223X MG RESISTOR 22k
Ω
1/8W F
R826 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R830 NRS181J-0R0X MG RESISTOR 0
Ω
1/8W J
R901 NRS181F-223X MG RESISTOR 22k
Ω
1/8W F
R902 NRS181F-223X MG RESISTOR 22k
Ω
1/8W F
R911 NRS181F-223X MG RESISTOR 22k
Ω
1/8W F
R912 NRS181F-223X MG RESISTOR 22k
Ω
1/8W F
VR101 QVP0033-501Z TRIM RESISTOR 500
Ω
VR201 QVP0033-501Z TRIM RESISTOR 500
Ω
VR301 QVP0033-501Z TRIM RESISTOR 500
Ω
VR401 QVP0033-501Z TRIM RESISTOR 500
Ω
L1 QQR1664-001 CHORK COIL
L2 QQR1277-001Z COIL
L3 QQR1277-001Z COIL
L5 QQR1277-001Z COIL
L6 QQR1277-001Z COIL
L7 QQR1277-001Z COIL
L8 QQR1277-001Z COIL J
L9 QQR1277-001Z COIL J
L101 QQLZ005-R45 COIL 0.45uH
L201 QQLZ005-R45 COIL 0.45uH
L301 QQLZ005-R45 COIL 0.45uH
L401 QQLZ005-R45 COIL 0.45uH
T1 QQS0353-001 SW TRANSF
BK1 LV36137-001A CON-BRACKET
BK2 LV36137-001A CON-BRACKET
CN1 QNB0277-001 SCREW TERMINAL
CN2 QGA2001F1-04 CONNECTOR W-B (1-4)
CN101 QNB0278-001 SCREW TERMINAL
CN301 QNB0278-001 SCREW TERMINAL
CN501 QGA2001C1-05 CONNECTOR W-B (1-5)
CN502 QGA2001C1-05 CONNECTOR W-B (1-5)
CN504 QGA2001C1-10 CONNECTOR W-B (1-10)
CN505 QGA2001C1-10 CONNECTOR W-B (1-10)
CN591 QGA2001F1-03 CONNECTOR W-B (1-3)
CN704 QGA2001C1-10 CONNECTOR W-B (1-10)
CN705 QGA2001C1-10 CONNECTOR W-B (1-10)
CN901 QGA4201F1-04 CONNECTOR W-B (1-4)
CN911 QGA4201F1-04 CONNECTOR W-B (1-4)
EP101 QNZ0136-001Z EARTH PLATE
F1 QNG0059-001 FUSE HOLDER
Symbol No.
Part No. Part Name Description Local
F2 QNG0059-001 FUSE HOLDER
F3 ICP-S1.2-X IC PROTECTOR 1.2A
F4 ICP-S1.2-X IC PROTECTOR 1.2A
F5 ICP-S1.2-X IC PROTECTOR 1.2A
J501 QNN0745-001 PIN JACK
J701 QNN0745-001 PIN JACK
TH1 QAD0070-222 P THERMISTOR 120Åé 2.2k
Ω
16V
TH2 QAD0070-222 P THERMISTOR 120Åé 2.2k
Ω
16V
TH3 NAD0041-471X POSISTOR 470
Ω
W301 QZW0010-001 STYLE PIN
W302 QZW0010-001 STYLE PIN
Symbol No.
Part No. Part Name Description Local
IC531 NJM4580V-X IC
IC532 NJM4580V-X IC
IC533 NJM4580V-X IC
IC561 NJM4580V-X IC
IC562 NJM4580V-X IC
IC563 NJM4580V-X IC
IC731 NJM4580V-X IC
IC732 NJM4580V-X IC
IC733 NJM4580V-X IC
IC761 NJM4580V-X IC
IC762 NJM4580V-X IC
IC763 NJM4580V-X IC
D1921 SLR343BBT-T LED
D1922 SLR343BBT-T LED
C1531 NDC31HJ-470X C CAPACITOR 47pF 50V J
C1532 QFV61HJ-563Z MF CAPACITOR 0.056uF 50V J
C1533 QFV61HJ-563Z MF CAPACITOR 0.056uF 50V J
C1534 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C1535 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C1536 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C1537 NCF31HZ-104X C CAPACITOR 0.1uF 50V Z
C1538 NCF31HZ-104X C CAPACITOR 0.1uF 50V Z
C1561 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C1562 NDC31HJ-180X C CAPACITOR 18pF 50V J
C1563 QFV61HJ-224Z MF CAPACITOR 0.22uF 50V J
C1564 QFV61HJ-183Z MF CAPACITOR 0.018uF 50V J
C1565 NCF31HZ-104X C CAPACITOR 0.1uF 50V Z
C1566 NCF31HZ-104X C CAPACITOR 0.1uF 50V Z
C1567 NDC31HJ-470X C CAPACITOR 47pF 50V J
C1631 NDC31HJ-470X C CAPACITOR 47pF 50V J
C1632 QFV61HJ-563Z MF CAPACITOR 0.056uF 50V J
C1633 QFV61HJ-563Z MF CAPACITOR 0.056uF 50V J
C1634 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C1635 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C1636 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C1661 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C1662 NDC31HJ-270X C CAPACITOR 27pF 50V J
C1663 QFV61HJ-224Z MF CAPACITOR 0.22uF 50V J
C1664 QFV61HJ-183Z MF CAPACITOR 0.018uF 50V J
C1667 NDC31HJ-470X C CAPACITOR 47pF 50V J
C1731 NDC31HJ-470X C CAPACITOR 47pF 50V J
C1732 QFV61HJ-563Z MF CAPACITOR 0.056uF 50V J
C1733 QFV61HJ-563Z MF CAPACITOR 0.056uF 50V J
C1734 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C1735 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C1736 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C1737 NCF31HZ-104X C CAPACITOR 0.1uF 50V Z
C1738 NCF31HZ-104X C CAPACITOR 0.1uF 50V Z
C1761 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C1762 NDC31HJ-180X C CAPACITOR 18pF 50V J
C1763 QFV61HJ-224Z MF CAPACITOR 0.22uF 50V J
C1764 QFV61HJ-183Z MF CAPACITOR 0.018uF 50V J
C1765 NCF31HZ-104X C CAPACITOR 0.1uF 50V Z
C1766 NCF31HZ-104X C CAPACITOR 0.1uF 50V Z
C1767 NDC31HJ-470X C CAPACITOR 47pF 50V J
Symbol No.
Part No. Part Name Description Local
