3-4
Electrical parts list
Main board
Block No. [0][1]

Symbol No.
Part No. Part Name Description Local
IC1 UPC494GS-X IC
IC501 NJM4580V-X IC
IC502 NJM4580V-X IC
IC521 NJM4580V-X IC
IC701 NJM4580V-X IC
IC702 NJM4580V-X IC
IC721 NJM4580V-X IC
Q1 2SC5734K/QR/-X TRANSISTOR
Q2 2SA2054K/Q/-X TRANSISTOR
Q3 2SA2054K/Q/-X TRANSISTOR
Q4 2SC5734K/QR/-X TRANSISTOR
Q5 FKV550N POWER MOSFET
Q6 FKV550N POWER MOSFET
Q7 FKV550N POWER MOSFET
Q8 FKV550N POWER MOSFET
Q9 2SC5171 POW TRANSISTOR
Q10 2SA1930 POW TRANSISTOR
Q15 FKV550N POWER MOSFET
Q16 FKV550N POWER MOSFET
Q17 FKV550N POWER MOSFET
Q18 FKV550N POWER MOSFET
Q19 2SC3928A/R/-X TRANSISTOR
Q20 2SC3928A/R/-X TRANSISTOR
Q21 2SB1197K/QR/-X TRANSISTOR
Q22 2SC3928A/R/-X TRANSISTOR
Q23 2SC3928A/R/-X TRANSISTOR
Q25 2SA1530A/R/-X TRANSISTOR
Q26 2SC3928A/R/-X TRANSISTOR
Q27 2SC3928A/R/-X TRANSISTOR
Q28 2SA2054K/Q/-X TRANSISTOR
Q30 2SK368/Y/-X CHIP JFET.C.M
Q31 2SK368/Y/-X CHIP JFET.C.M
Q32 2SC3928A/R/-X TRANSISTOR
Q33 2SA1530A/R/-X TRANSISTOR
Q34 2SC3928A/R/-X TRANSISTOR
Q101 2SK198/R/-X CHIP JFET.C.M
Q102 2SC5734K/QR/-X TRANSISTOR
Q103 2SC5734K/QR/-X TRANSISTOR
Q104 2SA2054K/Q/-X TRANSISTOR
Q105 2SA2054K/Q/-X TRANSISTOR
Q106 2SA1930 POW TRANSISTOR
Q107 2SC5171 POW TRANSISTOR
Q108 2SC1815/GL/-T TRANSISTOR
Q109 2SC5171 POW TRANSISTOR
Q110 2SA1930 POW TRANSISTOR
Q111 MLE20 POWER MOSFET
Q112 MJD20 POWER MOSFET
Q119 2SC3138/Y/-X TRANSISTOR
Q120 2SA1255/Y/-X TRANSISTOR
Q130 2SC3928A/R/-X TRANSISTOR
Q131 2SA1530A/R/-X TRANSISTOR
Q132 2SC3138/Y/-X TRANSISTOR
Q133 2SA1255/Y/-X TRANSISTOR
Q134 2SK368/Y/-X CHIP JFET.C.M
Q135 2SC5734K/QR/-X TRANSISTOR
Q136 2SA2054K/Q/-X TRANSISTOR
Q137 2SA2054K/Q/-X TRANSISTOR
Q138 2SC5734K/QR/-X TRANSISTOR
Q201 2SK198/R/-X CHIP JFET.C.M
Q202 2SC5734K/QR/-X TRANSISTOR
Q203 2SC5734K/QR/-X TRANSISTOR
Q204 2SA2054K/Q/-X TRANSISTOR
Q205 2SA2054K/Q/-X TRANSISTOR
Q206 2SA1930 POW TRANSISTOR
Q207 2SC5171 POW TRANSISTOR
Q208 2SC1815/GL/-T TRANSISTOR
Q209 2SC5171 POW TRANSISTOR
Q210 2SA1930 POW TRANSISTOR
Q211 MLE20 POWER MOSFET
Q212 MJD20 POWER MOSFET
Q219 2SC3138/Y/-X TRANSISTOR
Q220 2SA1255/Y/-X TRANSISTOR
Q301 2SK198/R/-X CHIP JFET.C.M
Q302 2SC5734K/QR/-X TRANSISTOR
Q303 2SC5734K/QR/-X TRANSISTOR
Q304 2SA2054K/Q/-X TRANSISTOR
Q305 2SA2054K/Q/-X TRANSISTOR
Q306 2SA1930 POW TRANSISTOR
Q307 2SC5171 POW TRANSISTOR
Q308 2SC1815/GL/-T TRANSISTOR
Q309 2SC5171 POW TRANSISTOR
Q310 2SA1930 POW TRANSISTOR
Q311 MLE20 POWER MOSFET
Q312 MJD20 POWER MOSFET
Q319 2SC3138/Y/-X TRANSISTOR
Q320 2SA1255/Y/-X TRANSISTOR
Q401 2SK198/R/-X CHIP JFET.C.M
Q402 2SC5734K/QR/-X TRANSISTOR
Q403 2SC5734K/QR/-X TRANSISTOR
Q404 2SA2054K/Q/-X TRANSISTOR
Q405 2SA2054K/Q/-X TRANSISTOR
Q406 2SA1930 POW TRANSISTOR
Q407 2SC5171 POW TRANSISTOR
Q408 2SC1815/GL/-T TRANSISTOR
Q409 2SC5171 POW TRANSISTOR
Q410 2SA1930 POW TRANSISTOR
Q411 MLE20 POWER MOSFET
Q412 MJD20 POWER MOSFET
Q419 2SC3138/Y/-X TRANSISTOR
Q420 2SA1255/Y/-X TRANSISTOR
D1 FMG-22R SI DIODE
D3 1SS355-X SI DIODE
D4 1SS355-X SI DIODE
D5 FMG-32S SI DIODE
D6 FMG-32R SI DIODE
D7 UDZS15B-X Z DIODE
D8 UDZS15B-X Z DIODE
D11 1SR156-400-X DIODE C.M
D16 UDZS7.5B-X Z DIODE
D17 UDZS15B-X Z DIODE
D18 1SS355-X SI DIODE
D19 1SR156-400-X DIODE C.M
D22 1SS355-X SI DIODE
D23 1SS355-X SI DIODE
D27 1SS355-X SI DIODE
D30 1SR156-400-X DIODE C.M
D31 1SR156-400-X DIODE C.M
D37 1SS355-X SI DIODE
D101 1SS355-X SI DIODE
D102 1SS355-X SI DIODE
D103 1SR156-400-X DIODE C.M
D104 1SR156-400-X DIODE C.M
D105 1SS355-X SI DIODE
D106 1SS376-X SI DIODE
D110 1SS376-X SI DIODE
D111 1SS376-X SI DIODE
D201 1SS355-X SI DIODE
D202 1SS355-X SI DIODE
D203 1SR156-400-X DIODE C.M
D204 1SR156-400-X DIODE C.M
D205 1SS355-X SI DIODE
D206 1SS376-X SI DIODE
D210 1SS376-X SI DIODE
D211 1SS376-X SI DIODE
D301 1SS355-X SI DIODE
D302 1SS355-X SI DIODE
D303 1SR156-400-X DIODE C.M
D304 1SR156-400-X DIODE C.M
D305 1SS355-X SI DIODE
D306 1SS376-X SI DIODE
D310 1SS376-X SI DIODE
D311 1SS376-X SI DIODE
D401 1SS355-X SI DIODE
D402 1SS355-X SI DIODE
D403 1SR156-400-X DIODE C.M
D404 1SR156-400-X DIODE C.M

Symbol No.
Part No. Part Name Description Local
