KS-AX6700
3-5
Item
Parts number Parts name Area
Remarks
FH 01 WF-9604 FUSE HOLDER PCB TYPE
L 102 CL-200C INDUCTOR AIR COIL
L 202 CL-200C INDUCTOR AIR COIL
L 701 CL-900A INDUCTOR CHOCK COIL
L 702 CL-1112 INDUCTOR 21PHI
(
1.2X2
)
12T
L 721 TN000004730 INDUCTOR AXIAL INDUCTOR
LED01 KLR124-E CARBON RESISTOR LED
(
RED
)
P 01 TMN005-01 TERMINAL POWER 3P
P 02 TMN004-02 TERMINAL SPEAKER 4P
Q
142 KTA1023Y CARBON RESISTOR SMALL SIGNAL PN
Q
143 KTA1023Y CARBON RESISTOR SMALL SIGNAL PN
Q
144 KTC1027Y TRANSISTOR SMALL SIGNAL NP
Q
145 KTC1027Y TRANSISTOR SMALL SIGNAL NP
Q
146 KTC1027Y TRANSISTOR SMALL SIGNAL NP
Q
148 KTA1220A-Y TRANSISTOR MIDDLE POWER PN
Q
149 KTA1220A-Y TRANSISTOR MIDDLE POWER PN
Q
150 J108 F.E.T J-FET
Q
152 KTC2690A-Y TRANSISTOR MIDDLE POWER NP
Q
161 IRF640 F.E.T N-CH POWER MOSF
Q
162 IRF640 F.E.T N-CH POWER MOSF
Q
163 IRF640 F.E.T N-CH POWER MOSF
Q
164 IRF640 F.E.T N-CH POWER MOSF
Q
165 IRF640 F.E.T N-CH POWER MOSF
Q
166 IRF640 F.E.T N-CH POWER MOSF
Q
171 KTA1023Y CARBON RESISTOR SMALL SIGNAL PN
Q
172 KTC1027Y TRANSISTOR SMALL SIGNAL NP
Q
173 KTA1023Y CARBON RESISTOR SMALL SIGNAL PN
Q
174 KTA1023Y CARBON RESISTOR SMALL SIGNAL PN
Q
175 KTC3198GR CARBON RESISTOR SMALL SIGNAL NP
Q
176 KTC3198GR CARBON RESISTOR SMALL SIGNAL NP
Q
242 KTA1023Y CARBON RESISTOR SMALL SIGNAL PN
Q
243 KTA1023Y CARBON RESISTOR SMALL SIGNAL PN
Q
244 KTC1027Y TRANSISTOR SMALL SIGNAL NP
Q
245 KTC1027Y TRANSISTOR SMALL SIGNAL NP
Q
246 KTC1027Y TRANSISTOR SMALL SIGNAL NP
Q
248 KTA1220A-Y TRANSISTOR MIDDLE POWER PN
Q
249 KTA1220A-Y TRANSISTOR MIDDLE POWER PN
Q
250 J108 F.E.T J-FET
Q
252 KTC2690A-Y TRANSISTOR MIDDLE POWER NP
Q
261 IRF640 F.E.T N-CH POWER MOSF
Q
262 IRF640 F.E.T N-CH POWER MOSF
Q
263 IRF640 F.E.T N-CH POWER MOSF
Q
264 IRF640 F.E.T N-CH POWER MOSF
Q
265 IRF640 F.E.T N-CH POWER MOSF
Q
266 IRF640 F.E.T N-CH POWER MOSF
Q
271 KTA1023Y CARBON RESISTOR SMALL SIGNAL PN
Q
701 KTA1023Y CARBON RESISTOR SMALL SIGNAL PN
Q
702 KTC3198GR CARBON RESISTOR SMALL SIGNAL NP
Q
705 KTA1266GR CARBON RESISTOR SMALL SIGNAL PN
Q
706 KTA1266GR CARBON RESISTOR SMALL SIGNAL PN
Q
707 KTC3198BL CARBON RESISTOR SMALL SIGNAL NP
Q
708 KTA1268GR CARBON RESISTOR SMALL SIGNAL PN
Q
710 KTC3198GR CARBON RESISTOR SMALL SIGNAL NP
Q
730 KTA1266GR CARBON RESISTOR SMALL SIGNAL PN
Q
731 KTA1266GR CARBON RESISTOR SMALL SIGNAL PN
Q
745 IRFZ44 F.E.T N-CH POWER MOSF
Q
746 IRFZ44 F.E.T N-CH POWER MOSF
Q
747 IRFZ44 F.E.T N-CH POWER MOSF
Q
755 IRFZ44 F.E.T N-CH POWER MOSF
Q
756 IRFZ44 F.E.T N-CH POWER MOSF
Q
757 IRFZ44 F.E.T N-CH POWER MOSF
Q
780 J108 F.E.T J-FET
Q
790 TIP117 TRANSISTOR PNP EPITAXIAL D
Q
850 KTA1023Y CARBON RESISTOR SMALL SIGNAL PN
Q
851 KTC3198GR CARBON RESISTOR SMALL SIGNAL NP
R 101 CAR1/5WJ22K RESISTOR CARBON FILM 1/5
R 102 MET1/5WF22K RESISTOR METAL FILM FILM
R 103 MET1/5WF22K RESISTOR METAL FILM FILM
R 105 MET1/5WF56K RESISTOR METAL FILM FILM
R 106 MET1/5WF56K RESISTOR METAL FILM FILM
R 133 CAR1/5WJ100K RESISTOR CARBON FILM 1/5
R 141 MET1/5WF5.6K RESISTOR METAL FILM FILM
R 142 CAR1/5WJ330 RESISTOR CARBON FILM 1/5
R 143 CAR1/5WJ330 RESISTOR CARBON FILM 1/5
R 144 CAR1/5WJ360 RESISTOR CARBON FILM 1/5
R 145 CAR1/5WJ100K RESISTOR CARBON FILM 1/5
R 146 CAR1/5WJ510 RESISTOR CARBON FILM 1/5
R 147 CAR1/5WJ1K RESISTOR CARBON FILM 1/5
R 148 CAR1/5WJ430 RESISTOR CARBON FILM 1/5
R 149 CAR1/5WJ22 RESISTOR CARBON FILM 1/5
R 150 CAR1/5WJ3.3K RESISTOR CARBON FILM 1/5
R 151 MET1/5WF22K RESISTOR METAL FILM FILM
R 152 CAR1/5WJ51 RESISTOR CARBON FILM 1/5
R 154 MET1/5WF1K RESISTOR METAL FILM FILM
R 160 MET1/5WF22K RESISTOR METAL FILM FILM
R 161 CAR1/5WJ47 RESISTOR CARBON FILM 1/5
R 162 CAR1/5WJ330 RESISTOR CARBON FILM 1/5
R 163 CAR1/5WJ47 RESISTOR CARBON FILM 1/5
R 164 CAR1/5WJ330 RESISTOR CARBON FILM 1/5
R 165 CAR1/5WJ56K RESISTOR CARBON FILM 1/5
R 166 MET1/5WF150K RESISTOR METAL FILM FILM
R 167 WIREWOUND5WJ RESISTOR WIREWOUND 5WJ
R 168 WIREWOUND5WJ RESISTOR WIREWOUND 5WJ
R 169 CAR1/2WJ4.7 RESISTOR CARBON FILM 1/2
R 170 CAR1/5WJ10K RESISTOR CARBON FILM 1/5
R 171 CAR1/5WJ330 RESISTOR CARBON FILM 1/5
R 172 CAR1/5WJ1K RESISTOR CARBON FILM 1/5
R 173 CAR1/5WJ330 RESISTOR CARBON FILM 1/5
R 174 CAR1/5WJ43K RESISTOR CARBON FILM 1/5
R 175 CAR1/5WJ82K RESISTOR CARBON FILM 1/5
R 176 CAR1/5WJ100K RESISTOR CARBON FILM 1/5
R 177 CAR1/5WJ390 RESISTOR CARBON FILM 1/5
R 178 CAR1/5WJ1K RESISTOR CARBON FILM 1/5
R 179 CAR1/5WJ15K RESISTOR CARBON FILM 1/5
R 180 MET1/5WF22K RESISTOR METAL FILM FILM
R 181 CAR1/5WJ47 RESISTOR CARBON FILM 1/5
R 182 MET3WJ560 RESISTOR METAL FILM 3WJ
R 183 CAR1/5WJ100K RESISTOR CARBON FILM 1/5
R 185 CAR1/5WJ47 RESISTOR CARBON FILM 1/5
R 186 CAR1/5WJ47 RESISTOR CARBON FILM 1/5
R 187 CAR1/5WJ47 RESISTOR CARBON FILM 1/5
R 188 MET1/5WF150K RESISTOR METAL FILM FILM
R 191 MET2WJ22 CARBON RESISTOR METAL FILM 2WJ
R 195 CAR1/5WJ100 RESISTOR CARBON FILM 1/5
R 201 CAR1/5WJ22K RESISTOR CARBON FILM 1/5
R 202 MET1/5WF22K RESISTOR METAL FILM FILM
R 203 MET1/5WF22K RESISTOR METAL FILM FILM
R 205 MET1/5WF56K RESISTOR METAL FILM FILM
R 206 MET1/5WF56K RESISTOR METAL FILM FILM
R 233 CAR1/5WJ100K RESISTOR CARBON FILM 1/5
R 241 MET1/5WF5.6K RESISTOR METAL FILM FILM
R 242 CAR1/5WJ330 RESISTOR CARBON FILM 1/5
R 243 CAR1/5WJ330 RESISTOR CARBON FILM 1/5
R 244 CAR1/5WJ360 RESISTOR CARBON FILM 1/5
R 245 CAR1/5WJ100K RESISTOR CARBON FILM 1/5
R 246 CAR1/5WJ510 RESISTOR CARBON FILM 1/5
Electrical parts list ( MAIN PCB )
Block No. 01
A
Item
Parts number Parts name Area
Remarks
A
