KS-AX6700
3-6
Item
Parts number Parts name Area
Remarks
R 247 CAR1/5WJ1K RESISTOR CARBON FILM 1/5
R 248 CAR1/5WJ430 RESISTOR CARBON FILM 1/5
R 249 CAR1/5WJ22 RESISTOR CARBON FILM 1/5
R 250 CAR1/5WJ3.3K RESISTOR CARBON FILM 1/5
R 251 MET1/5WF22K RESISTOR METAL FILM FILM
R 252 CAR1/5WJ51 RESISTOR CARBON FILM 1/5
R 254 MET1/5WF1K RESISTOR METAL FILM FILM
R 260 MET1/5WF22K RESISTOR METAL FILM FILM
R 261 CAR1/5WJ47 RESISTOR CARBON FILM 1/5
R 262 CAR1/5WJ330 RESISTOR CARBON FILM 1/5
R 263 CAR1/5WJ47 RESISTOR CARBON FILM 1/5
R 264 CAR1/5WJ330 RESISTOR CARBON FILM 1/5
R 265 CAR1/5WJ56K RESISTOR CARBON FILM 1/5
R 266 MET1/5WF150K RESISTOR METAL FILM FILM
R 267 WIREWOUND5WJ RESISTOR WIREWOUND 5WJ
R 268 WIREWOUND5WJ RESISTOR WIREWOUND 5WJ
R 269 CAR1/2WJ4.7 RESISTOR CARBON FILM 1/2
R 270 CAR1/5WJ10K RESISTOR CARBON FILM 1/5
R 271 CAR1/5WJ330 RESISTOR CARBON FILM 1/5
R 272 CAR1/5WJ1K RESISTOR CARBON FILM 1/5
R 280 MET1/5WF22K RESISTOR METAL FILM FILM
R 281 CAR1/5WJ47 RESISTOR CARBON FILM 1/5
R 285 CAR1/5WJ47 RESISTOR CARBON FILM 1/5
R 286 CAR1/5WJ47 RESISTOR CARBON FILM 1/5
R 287 CAR1/5WJ47 RESISTOR CARBON FILM 1/5
R 288 MET1/5WF150K RESISTOR METAL FILM FILM
R 291 MET2WJ22 CARBON RESISTOR METAL FILM 2WJ
R 295 CAR1/5WJ100 RESISTOR CARBON FILM 1/5
R 382 MET3WJ560 RESISTOR METAL FILM 3WJ
R 395 CAR1/5WJ4.7K RESISTOR CARBON FILM 1/5
R 701 CAR1/2WJ68 RESISTOR CARBON FILM 1/2
R 702 CAR1/5WJ4.7K RESISTOR CARBON FILM 1/5
R 703 CAR1/5WJ4.7K RESISTOR CARBON FILM 1/5
R 704 CAR1/5WJ4.7K RESISTOR CARBON FILM 1/5
R 705 CAR1/5WJ10K RESISTOR CARBON FILM 1/5
R 715 MET1/5WF140K RESISTOR METAL FILM FILM
R 716 MET1/5WF51K RESISTOR METAL FILM FILM
R 717 CAR1/5WJ4.7K RESISTOR CARBON FILM 1/5
R 718 CAR1/5WJ4.7K RESISTOR CARBON FILM 1/5
R 719 CAR1/5WJ10K RESISTOR CARBON FILM 1/5
R 720 CAR1/5WJ10K RESISTOR CARBON FILM 1/5
R 722 MET1WJ22 RESISTOR METAL FILM 1WJ
R 725 CAR1/5WJ10 RESISTOR CARBON FILM 1/5
R 726 CAR1/5WJ910 RESISTOR CARBON FILM 1/5
R 730 CAR1/5WJ1K RESISTOR CARBON FILM 1/5
R 731 CAR1/5WJ22K RESISTOR CARBON FILM 1/5
R 732 CAR1/5WJ33K RESISTOR CARBON FILM 1/5
R 733 CAR1/5WJ15K RESISTOR CARBON FILM 1/5
R 734 CAR1/5WJ15K RESISTOR CARBON FILM 1/5
R 740 CAR1/5WJ47K RESISTOR CARBON FILM 1/5
R 741 MWT1/5WF24K RESISTOR METAL FILM FILM
R 742 CAR1/2WJ220 RESISTOR CARBON FILM 1/2
R 743 CAR1/2WJ220 RESISTOR CARBON FILM 1/2
R 744 CAR1/5WJ1K RESISTOR CARBON FILM 1/5
R 745 CAR1/5WJ100 RESISTOR CARBON FILM 1/5
R 746 CAR1/5WJ100 RESISTOR CARBON FILM 1/5
R 747 CAR1/5WJ100 RESISTOR CARBON FILM 1/5
R 750 CAR1/5WJ27K RESISTOR CARBON FILM 1/5
R 751 CAR1/5WJ12K RESISTOR CARBON FILM 1/5
R 752 CAR1/5WJ1.5K RESISTOR CARBON FILM 1/5
R 754 CAR1/5WJ1K RESISTOR CARBON FILM 1/5
R 755 CAR1/5WJ100 RESISTOR CARBON FILM 1/5
R 756 CAR1/5WJ100 RESISTOR CARBON FILM 1/5
R 757 CAR1/5WJ100 RESISTOR CARBON FILM 1/5
R 760 MET2WJ100 RESISTOR METAL FILM 2WJ
R 777 CAR1/2WJ10K RESISTOR CARBON FILM 1/2
R 778 CAR1/2WJ10K RESISTOR CARBON FILM 1/2
R 780 CAR1/5WJ220K RESISTOR CARBON FILM 1/5
R 781 CAR1/5WJ10K RESISTOR CARBON FILM 1/5
R 782 CAR1/5WJ4.7M RESISTOR CARBON FILM 1/5
R 790 CAR1/5WJ10K RESISTOR CARBON FILM 1/5
R 791 CAR1/2WJ2.2 RESISTOR CARBON FILM 1/2
R 792 CAR1/5WJ2.2K RESISTOR CARBON FILM 1/5
R 850 CAR1/5WJ4.7K RESISTOR CARBON FILM 1/5
R 851 CAR1/5WJ4.7K RESISTOR CARBON FILM 1/5
R 852 CAR1/5WJ22K RESISTOR CARBON FILM 1/5
R 853 CAR1/5WJ4.7K RESISTOR CARBON FILM 1/5
R 854 CAR1/5WJ75K RESISTOR CARBON FILM 1/5
RCA01 SY-SW0406-82 RCA JACK GOLD PLATED
T 01 TF149051501 INDUCTOR TROID CORE ISU
TH 01 FTD5-350 CARBON RESISTOR NTC RESISTOR
U 101 NJM2068L-D I.C DUAL OP AMP
U 701 TL494CN I.C P.W.M
U 703 KIA7815PI I.C REGULATOR I.C +
U 704 KIA7915PI I.C REGULATOR I.C -
VR701 SEMX-VR2 SEMI VOLUME 6.5PHI
WR 1 CHDW1140-N CONNECTOR ASS'Y CRIMP TERMINAL
Electrical parts list ( MAIN PCB )
Block No. 01
A
Item
Parts number Parts name Area
Remarks
A
