Item
Parts number Parts name Area
Remarks
C 107 CER470PF50V CAPACITOR CERAMIC DISK 50
C 108 CER33PF50VNPO CAPACITOR CERAMIC DISK 50
C 109 CER47PF50VNPO CAPACITOR CERAMIC DISK 50
C 110 MAL473J63VTL CAPACITOR MYLAR 5% 63V T
C 111 MAL473J63VTL CAPACITOR MYLAR 5% 63V T
C 112 ELE2.2/50VSE CAPACITOR ELECTROLYTIC SE
C 113 ELE2.2/50VSE CAPACITOR ELECTROLYTIC SE
C 114 ELE2.2/50VSE CAPACITOR ELECTROLYTIC SE
C 115 MAL224J63VTL CAPACITOR MYLAR 5% 63V T
C 116 MAL183J63VTL CAPACITOR MYLAR 5% 63V T
C 117 CER47PF50VNPO CAPACITOR CERAMIC DISK 50
C 125 ELE4.7UF/50VSE CAPACITOR ELECTROLYTIC SE
C 207 CER470PF50V CAPACITOR CERAMIC DISK 50
C 208 CER24PF50VNPO CAPACITOR CERAMIC DISK 50
C 209 CER47PF50VNPO CAPACITOR CERAMIC DISK 50
C 210 MAL473J63VTL CAPACITOR MYLAR 5% 63V T
C 211 MAL473J63VTL CAPACITOR MYLAR 5% 63V T
C 212 ELE2.2/50VSE CAPACITOR ELECTROLYTIC SE
C 213 ELE2.2/50VSE CAPACITOR ELECTROLYTIC SE
C 214 ELE2.2/50VSE CAPACITOR ELECTROLYTIC SE
C 215 MAL224J63VTL CAPACITOR MYLAR 5% 63V T
C 216 MAL183J63VTL CAPACITOR MYLAR 5% 63V T
C 217 CER47PF50VNPO CAPACITOR CERAMIC DISK 50
C 225 ELE4.7UF/50VSE CAPACITOR ELECTROLYTIC SE
C 801 MAL473K/100V CAPACITOR CERAMIC DISK 50
C 802 CER18P3KV CAPACITOR HIGH VOLTAGE CE
C 804 CER104PF50V CAPACITOR CERAMIC DISK 50
CFL01 190M/M CCFL
CON02 TM2007-T14G-09 HEADER PIN RIGHT ANGLE GOL
CON03 TM2007-T14G-09 HEADER PIN RIGHT ANGLE GOL
D 801 1N5241 DIODE ZENER 11V 0.5W
Q
801 KTC1027Y TRANSISTOR SMALL SIGNAL NP
Q
802 KTC1027Y TRANSISTOR MALL SIGNAL NP
Q
803 KTC2690A-Y TRANSISTOR MIDDLE POWER NP
R 108 CAR1/5WJ1K RESISTOR CARBON FILM 1/5
R 109 CAR1/5WJ1K RESISTOR CARBON FILM 1/5
R 110 CAR1/5WJ15K RESISTOR CARBON FILM 1/5
R 111 MET1/5WF11K RESISTOR METAL FILM 1/5W
R 112 MET1/5WF30K RESISTOR METAL FILM 1/5W
R 113 CAR1/5WJ10K RESISTOR CARBON FILM 1/5
R 114 CAR1/5WJ10K RESISTOR CARBON FILM 1/5
R 115 CAR1/5WJ10K RESISTOR CARBON FILM 1/5
R 116 CAR1/5WJ15K RESISTOR CARBON FILM 1/5
R 117 CAR1/5WJ10K RESISTOR CARBON FILM 1/5
R 118 CAR1/5WJ15K RESISTOR CARBON FILM 1/5
R 130 CAR1/5WJ22K RESISTOR CARBON FILM 1/5
R 131 CAR1/5WJ22K RESISTOR CARBON FILM 1/5
R 132 CAR1/5WJ22K RESISTOR CARBON FILM 1/5
R 134 CAR1/5WJ1K RESISTOR CARBON FILM 1/5
R 135 CAR1/5WJ1K RESISTOR CARBON FILM 1/5
R 136 CAR1/5WJ1K RESISTOR CARBON FILM 1/5
R 137 CAR1/5WJ20K RESISTOR CARBON FILM 1/5
R 138 CAR1/5WJ330K RESISTOR CARBON FILM 1/5
R 139 CAR1/5WJ5.6K RESISTOR CARBON FILM 1/5
R 140 CAR1/5WJ680K RESISTOR CARBON FILM 1/5
R 208 CAR1/5WJ1K RESISTOR CARBON FILM 1/5
R 209 CAR1/5WJ1K RESISTOR CARBON FILM 1/5
R 210 MET1/5WF15K RESISTOR METAL FILM 1/5W
R 211 CAR1/5WJ12K RESISTOR CARBON FILM 1/5
R 212 MET1/5WF56K RESISTOR METAL FILM 1/5W
R 213 CAR1/5WJ10K RESISTOR CARBON FILM 1/5
R 214 CAR1/5WJ10K RESISTOR CARBON FILM 1/5
R 215 CAR1/5WJ10K RESISTOR CARBON FILM 1/5
R 216 CAR1/5WJ15K RESISTOR CARBON FILM 1/5
R 217 CAR1/5WJ10K RESISTOR CARBON FILM 1/5
R 218 CAR1/5WJ15K RESISTOR CARBON FILM 1/5
R 230 CAR1/5WJ22K RESISTOR CARBON FILM 1/5
R 231 CAR1/5WJ22K RESISTOR CARBON FILM 1/5
R 232 CAR1/5WJ22K RESISTOR CARBON FILM 1/5
R 234 CAR1/5WJ1K RESISTOR CARBON FILM 1/5
R 235 CAR1/5WJ1K RESISTOR CARBON FILM 1/5
R 236 CAR1/5WJ1K RESISTOR CARBON FILM 1/5
R 237 CAR1/5WJ20K RESISTOR CARBON FILM 1/5
R 238 CAR1/5WJ330K RESISTOR CARBON FILM 1/5
R 239 CAR1/5WJ5.6K RESISTOR CARBON FILM 1/5
R 240 CAR1/5WJ680K RESISTOR CARBON FILM 1/5
R 801 CAR1/2WJ1.5K RESISTOR CARBON FILM 1/2
R 802 CAR1/2WJ4.7M RESISTOR CARBON FILM 1/2
R 803 CAR1/2WJ4.7M RESISTOR CARBON FILM 1/2
R 804 CAR1/5WK200 RESISTOR CARBON FILM 1/5
SW101 JSS2319 SWITCH SLIDE SWITCH
T 02 CL-113 INDUCTOR DRUM TYPE CHOKE
T 02 CHT-100 TRANS CCFL INVERTER T
U 102 NJM2068L-D I.C DUAL OP AMP
U 103 NJM2068L-D I.C DUAL OP AMP
U 104 NJM2068L-D I.C DUAL OP AMP
U 105 NJM2068L-D I.C DUAL OP AMP
U 106 NJM2068L-D I.C DUAL OP AMP
U 206 NJM2068L-D I.C DUAL OP AMP
VR101 V0142203211 VOLUME V9M
(
7X5
)
G3
(
PH3R
VR102 V0144503211 VOLUME V9M
(
7X5
)
G
(
4R
)(
P
VR103 V0142203211 VOLUME V9M
(
7X5
)
G3
(
PH3R
WR801 CHL0640-2P WIRE ASS'Y GND.+
Electrical parts list ( SUB1/SUB2/CCFL PCB )
