KS-AX7300
3-3
Item
Parts number Parts name
Area
A
Parts list (General assembly)
Q'ty
Description
Block No. M1MM
1 HEA-01-530AA
HEAT SINK 1
2 MAFPIT6859-0
FRONT PANEL 1
3 MARPIT6864-0
REAR PANEL 1
4 MABCIT6867-0
BOTTOM COVER 1
5 MATC058406-0
CONTROL PANEL 1
6 MASO051491-1
CCFL COVER 1
7 MABR031492-0
TR BRACKET A 2
8 MABR031493-0
TR BRACKET B 2
9 MOCU011502-2
TR BKT CUSHION 2
10 MOCU011503-2
TR BKT CUSHION 2
11 MASP001518-0
SILICON PAD A 2
12 MASP001509-0
SILICON PAD B 2
13 MAPO022903-0
PIPE 1
14 MATC046670-0
TOP PLATE 1
15 MAIL001501-1
ILLUMINATOR 1
16 MOKB076023-3
VOLUME KNOB 6
17 MOKB076024-1
SWITCH KNOB 2
18 MOWA051506-0
POLY WASHER 2
19 MABU031496-0
WIRE BUSHING 1
20 MOCU111508-0
INSULATION SHEE 1
21 MOCU111535-1
INSULATION SHEE 1
22 MOFI011536-0
FIBER PLATE 1
23 MOCU011511-1
CCFL CUSHION A 1
24 MOCU011512-0
CCFL CUSHION B 6
25 MOCU001521-0
RUBBER CUSHION 1
26 MOCU014097-0
RUBBER CUSHION 5
27 MOCU021701-0
FIBER CUSHION 2
29 MOCU061498-0
EVA CUSHION 2
30 MNSC00140-9.3
SCREW 2
M4.0 NI-P
32 MNSC00740-14
SCREW 10
SMT 4X14 NI-P
33 MBSC03230-08
SCREW 8
STT2 BH 3X8 BK
34 MBSC00230-06
SCREW 14
SMB 3X6 BK
35 MBSC00330-08
SCREW 6 SMP 3X8 BK
36 MNSC00630-06
SCREW 8
SML 3X6 NI-P
37 MBSC04330-05
SCREW 4
STT3 PH 3X5 BK
38 LV34204-001A
NAME PLATE 1
39 SHIELDSTICKER
STICKER 1
40 FUSE20A/32V
AUTO FUSE 2
41 SUB-33-024A0
RUBBER CUSHION 1
