Page #26 background image
KS-FX202
3-4
Item
Parts number Parts name Area
A
Parts list (General assembly)
Q'ty
Description
Block No. M1MM
49 FSKS3021-001
LENS CASE
1
50 GE30331-002A
NAME PLATE
1
51 VMA4652-001SS
EARTH PLATE
1
52 FSKL4018-00B
IC BRACKET
1
53 QMFZ047-100-T
FUSE
A
1
54 FSKM3010-011
REAR BRACKET
1
55 QYSDST2606Z
SCREW
1
REAR BKT+ANT JACK
56 QYSDST2606Z
SCREW
2
REAR BKT+15P
57 QYSDSF3006Z
SCREW
1
REAR BKT+PIN JACK
58 QYSDST2606Z
SCREW
1
REAR BKT+CD IN JACK
