KS-FX202
3-10
Item
Parts number Parts name Ar
e
a
Electrical parts list (Main board)
Remarks
Block No. 01
A
Item
Parts number Parts name Ar
e
a
Remarks
A
C 2 QDX11EK-223Z C CAPACITOR
C 3 QEKJ1HM-104Z E CAPACITOR 0.1MF 20% 50V
C 4 QEKJ1HM-104Z E CAPACITOR 0.1MF 20% 50V
C 5 QEKJ1CM-106Z E CAPACITOR 10MF 20% 16V
C 6 QDX11EK-223Z C CAPACITOR
C 7 QDX11EK-223Z C CAPACITOR
C 8 QERF1HM-104Z E CAPACITOR 0.1MF 20% 50V
C 9 QDYB1CM-103Y C CAPACITOR
C 11 QDYB1CM-103Y C CAPACITOR
C 15 QDYB1CM-103Y C CAPACITOR
C 101 QDGB1HK-821Y C CAPACITOR
C 102 QEKJ1HM-474Z E CAPACITOR 0.47MF 20% 50V
C 103 QCBB1HK-101Y C CAPACITOR 100PF 10% 50V
C 104 QEKJ0JM-476Z E CAPACITOR 47MF 20% 6.3V
C 105 QFV61HJ-103Z MF CAPACITOR 0.01MF 5% 50V
C 131 QEKJ1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 132 QEKJ1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 133 QEKJ1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 134 QFLK1HJ-822Z M CAPACITOR 8200PF 5% 50V
C 135 QFV61HJ-154Z MF CAPACITOR 0.15MF 5% 50V
C 136 QFV61HJ-224Z MF CAPACITOR 0.22MF 5% 50V
C 137 QFV61HJ-333Z MF CAPACITOR 0.033MF 5% 50V
C 138 QFLK1HJ-562Z M CAPACITOR 5600PF 5% 50V
C 150 QERF1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 152 QCBB1HK-471Y C CAPACITOR 470PF 10% 50V
C 160 QEKJ1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 162 QCBB1HK-471Y C CAPACITOR 470PF 10% 50V
C 201 QDGB1HK-821Y C CAPACITOR
C 202 QERF1HM-474Z E CAPACITOR 0.47MF 20% 50V
C 203 QCBB1HK-101Y C CAPACITOR 100PF 10% 50V
C 204 QEKJ0JM-476Z E CAPACITOR 47MF 20% 6.3V
C 205 QFV61HJ-103Z MF CAPACITOR 0.01MF 5% 50V
C 231 QERF1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 232 QERF1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 233 QERF1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 234 QFLK1HJ-822Z M CAPACITOR 8200PF 5% 50V
C 235 QFV61HJ-154Z MF CAPACITOR 0.15MF 5% 50V
C 236 QFV61HJ-224Z MF CAPACITOR 0.22MF 5% 50V
C 237 QFV61HJ-333Z MF CAPACITOR 0.033MF 5% 50V
C 238 QFLK1HJ-562Z M CAPACITOR 5600PF 5% 50V
C 250 QERF1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 252 QCBB1HK-471Y C CAPACITOR 470PF 10% 50V
C 260 QERF1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 262 QCBB1HK-471Y C CAPACITOR 470PF 10% 50V
C 701 QDUB1HJ-270Y C CAPACITOR
C 702 QDCB1HJ-220Y C CAPACITOR
C 703 QERF0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 704 QFV61HJ-224Z MF CAPACITOR 0.22MF 5% 50V
C 705 QERF1CM-106Z E CAPACITOR 10MF 20% 16V
C 706 QDYB1CM-103Y C CAPACITOR
C 707 QFV61HJ-103Z MF CAPACITOR 0.01MF 5% 50V
C 751 QDYB1CM-103Y C CAPACITOR
C 771 QERF1AM-227Z E CAPACITOR 220MF 20% 10V
C 772 QERF1HM-225Z E CAPACITOR 2.2MF 20% 50V
C 773 QDGB1HK-102Y C CAPACITOR
C 781 QEKJ1CM-106Z E CAPACITOR 10MF 20% 16V
C 783 QETN0JM-228Z E CAPACITOR 2200MF 20% 6.3V
C 784 QERF1AM-227Z E CAPACITOR 220MF 20% 10V
C 785 QERF1CM-106Z E CAPACITOR 10MF 20% 16V
C 786 QETM1AM-228 E CAPACITOR 2200MF 20% 10V
C 901 QEKJ1AM-107Z E CAPACITOR 100MF 20% 10V
C 931 QEKJ1AM-107Z E CAPACITOR 100MF 20% 10V
C 932 QDYB1CM-103Y C CAPACITOR
C 933 QERF1AM-107Z E CAPACITOR 100MF 20% 10V
C 934 QERF1CM-476Z E CAPACITOR 47MF 20% 16V
C 951 QERF1EM-475Z E CAPACITOR 4.7MF 20% 25V
C 971 QERF1EM-475Z E CAPACITOR 4.7MF 20% 25V
C 972 QERF1AM-227Z E CAPACITOR 220MF 20% 10V
C 980 QCBB1HK-271Y C CAPACITOR 270PF 10% 50V
C 981 QEZ0518-228 E CAPACITOR 2200MF
C 982 QDYB1CM-103Y C CAPACITOR
C 983 QDYB1CM-103Y C CAPACITOR
C 984 QERF1CM-106Z E CAPACITOR 10MF 20% 16V
C 985 QRE141J-472Y C RESISTOR 4.7K 5% 1/4W
C 986 QERF1CM-106Z E CAPACITOR 10MF 20% 16V
C 987 QEKJ1CM-106Z E CAPACITOR 10MF 20% 16V
C 988 QERF1CM-476Z E CAPACITOR 47MF 20% 16V
CJ701 VMC0334-001 CONNECTOR
CJ901 QGA2002C1-05 CONNECTOR
CJ921 QNN0183-001 PIN JACK
CN721 QGB1214J1-06S CONNECTOR
CN901 QGB1214J1-06S CONNECTOR
CP721 QGB1214K1-06S CONNECTOR
CP722 QGA2002F1-06 CONNECTOR
CP751 QNZ0095-001 CONNECTOR
CP901 QGB1214K1-06S CONNECTOR
CP981 QNZ0002-001 CONNECTOR
D 1 1SS119-041 SI DIODE
D 2 1SS119-041 SI DIODE
D 161 1SS119-041 SI DIODE
D 261 1SS119-041 SI DIODE
D 701 1SS119-041 SI DIODE
D 704 MTZJ5.6B-T2 ZENER DIODE
D 705 MTZJ5.6B-T2 ZENER DIODE
D 706 MTZJ5.6B-T2 ZENER DIODE
D 707 MTZJ5.6B-T2 ZENER DIODE
D 708 MTZJ5.6B-T2 ZENER DIODE
D 709 MTZJ5.6B-T2 ZENER DIODE
D 711 MTZJ5.6B-T2 ZENER DIODE
D 714 1SS119-041 SI DIODE
D 715 1SS119-041 SI DIODE
D 716 1SS119-041 SI DIODE
D 718 1SS119-041 SI DIODE
D 771 MTZJ9.1C-T2 ZENER DIODE
D 781 1SS119-041 SI DIODE
D 782 1SS119-041 SI DIODE
D 784 DSK10C-T1 DIODE
D 785 DSK10C-T1 DIODE
D 786 DSK10C-T1 DIODE
D 791 1SS119-041 SI DIODE
D 792 1SS119-041 SI DIODE
D 973 1SS119-041 SI DIODE
D 974 1SS119-041 SI DIODE
D 981 1N5401-TM DIODE
D 990 MTZJ11B-T2 ZENER DIODE
IC701 LC72362N-9920 IC
IC751 HD74HC126P IC
IC781 AN80T05LF IC
IC901 UPC1228HA IC
IC931 TEA6320T-X IC
IC981 HA13158A IC
J 1 QNZ0009-001 ANT JACK
L 1 QQL231K-4R7Y INDUCTOR
L 781 QQL231K-470Y INDUCTOR
L 782 QQL231K-470Y INDUCTOR
L 783 QQL231K-470Y INDUCTOR
