KS-FX483R,KS-FX480R,KS-FX43R
(No.49812)1-25
47 AM E0 O PLL error output for AM
48 FM E0 O PLL error output for FM
49 IC(VPP) - Setting to write for flsh
50 RESET I System reset
51 RDS CK O Clock output for RDS
52 RDS DA O Data ouytput for RDS
53 MONO O Mono by power force
54 SD/ST I Station detectior/Stereo indicator
55 FM/AM O FM / AM band selection
56 AFCK I AF check input
57 DETACH I Detach signal iunput
58,59 -- - No use
60 LCD DA O LCD data output
61 LCD CLK O LCD clock output
62 LCD CE O LCD chip enable output
63~68 NC - No use
69 RX - No use
70 TX - No use
71 SEEK2 O SEEK 2 signal output
72~77 NC - No use
78 REMOCON I Remocon signal input
79 NC - No use
80 J-BUS INT I J-BUS interrupt signal input
81 STERRING REMOTE - No use
82 GND1 - GND
83 STAGE1 - No use
84 STAGE2 - No use
85 MUTE O System mute
86 T MUTE O Tape mute signal output
87 TAPE IN I Tape in singal input
88 TEL MUTE O Telephone mute output
89 UNLOCK - No use
80~98 NC - No use
99 VDDPORT - Vdd
100 GNDPORT - Connect to GND
