KS-FX483R/KS-FX480R/KS-FX43R
3-10
Item
Parts number Parts name Area
Electrical parts list (Main board)
Remarks
Block No. 01
A
C 1 QEKJ1HM-104Z E CAPACITOR
.10MF 20% 50V
C 2 NCB31EK-104X C CAPACITOR
C 3 QERF1AM-227Z E CAPACITOR
220MF 20% 10V
C 4 QERF1AM-227Z E CAPACITOR
220MF 20% 10V
C 6 NCB21EK-124X C CAPACITOR
C 7 NCB31EK-123X C CAPACITOR
C 8 QERF1AM-107Z E CAPACITOR
100MF 20% 10V
C 9 QERF1AM-227Z E CAPACITOR
220MF 20% 10V
C 17 NCS31HJ-151X C CAPACITOR
C 18 QERF1HM-474Z E CAPACITOR
.47MF 20% 50V
C 20 NCS31HJ-102X C CAPACITOR
C 21 QERF1HM-225Z E CAPACITOR
2.2MF 20% 50V
C 24 NCB31EK-473X C CAPACITOR
C 25 NCB31EK-104X C CAPACITOR
C 30 NDC31HJ-470X C CAPACITOR
C 111 QERF1HM-105Z E CAPACITOR
1.0MF 20% 50V
C 112 QERF1HM-105Z E CAPACITOR
1.0MF 20% 50V
C 113 NCB31HK-822X C CAPACITOR
C 114 NCB21CK-184X C CAPACITOR
C 115 QERF1HM-224Z E CAPACITOR
.22MF 20% 50V
C 116 NCB31EK-333X C CAPACITOR
C 117 NCB31EK-562X C CAPACITOR
C 118 QERF1HM-105Z E CAPACITOR
1.0MF 20% 50V
C 119 QERF1HM-105Z E CAPACITOR
1.0MF 20% 50V
C 143 NCS31HJ-391X C CAPACITOR
C 144 NCS31HJ-391X C CAPACITOR
C 151 QERF1HM-105Z E CAPACITOR
1.0MF 20% 50V
C 152 NCB31HK-122X C CAPACITOR
C 153 QERF1HM-105Z E CAPACITOR
1.0MF 20% 50V
C 154 NCB31HK-153X C CAPACITOR
C 211 QERF1HM-105Z E CAPACITOR
1.0MF 20% 50V
C 212 QERF1HM-105Z E CAPACITOR
1.0MF 20% 50V
C 213 NCB31HK-822X C CAPACITOR
C 214 NCB21CK-184X C CAPACITOR
C 215 QERF1HM-224Z E CAPACITOR
.22MF 20% 50V
C 216 NCB31EK-333X C CAPACITOR
C 217 NCB31EK-562X C CAPACITOR
C 218 QERF1HM-105Z E CAPACITOR
1.0MF 20% 50V
C 219 QERF1HM-105Z E CAPACITOR
1.0MF 20% 50V
C 243 NCS31HJ-391X C CAPACITOR
C 244 NCS31HJ-391X C CAPACITOR
C 251 QERF1HM-105Z E CAPACITOR
1.0MF 20% 50V
C 252 NCB31HK-122X C CAPACITOR
C 253 QERF1HM-105Z E CAPACITOR
1.0MF 20% 50V
C 254 NCB31HK-153X C CAPACITOR
C 301 NCB31HK-331X C CAPACITOR
S
USE
C 302 NCB31HK-103X C CAPACITOR
S
USE
C 303 NCB31EK-472X C CAPACITOR
S
USE
C 304 NCB31EK-104X C CAPACITOR
S
USE
C 305 QEKJ1HM-225Z E CAPACITOR
S
USE
C 701 NDC31HJ-270X C-CAPACITOR
C 702 NDC31HJ-270X C-CAPACITOR
C 703 NCB31EK-104X C CAPACITOR
C 704 NCB31EK-104X C CAPACITOR
C 705 NCB31HK-102X C CAPACITOR
C 706 NDC31HJ-101X CER.CAPACITOR
FX43R
C 707 NCB31EK-104X C CAPACITOR
C 708 QERF1AM-227Z E CAPACITOR
220MF 20% 10V
C 709 QERF0JM-107Z E CAPACITOR
100MF 20% 6.3V
C 710 NCB31EK-104X C CAPACITOR
C 711 NCB21CK-224X C CAPACITOR
C 712 NCB21HK-104X C CAPACITOR
C 713 NRSA02J-0R0X MG RESISTOR
C 751 NCB31EK-104X C CAPACITOR
C 761 NCB31EK-223X C CAPACITOR
C 762 NCS31HJ-561X C CAPACITOR
C 763 QEKJ1HM-225Z E CAPACITOR
2.2MF 20% 50V
C 764 NDC31HJ-820X C CAPACITOR
C 765 NDC31HJ-470X C CAPACITOR
C 766 QERF1CM-476Z E CAPACITOR
47MF 20% 16V
C 767 NCB31HK-103X C CAPACITOR
C 768 NCB31HK-103X C CAPACITOR
C 911 QERF1CM-476Z E CAPACITOR
47MF 20% 16V
C 912 QERF1CM-107Z E CAPACITOR
100MF 20% 16V
C 913 QERF1CM-107Z E CAPACITOR
100MF 20% 16V
C 932 NCB31EK-104X C CAPACITOR
C 941 NCB31EK-104X C CAPACITOR
C 942 NCB31EK-104X C CAPACITOR
C 943 NCB31EK-104X C CAPACITOR
C 945 QEKJ1EM-475Z E CAPACITOR
4.7MF 20% 25V
C 946 QERF1CM-226Z E CAPACITOR
22MF 20% 16V
C 947 QFVD1HJ-224Z CER.CAPACITOR
.22MF 5% 50V
C 948 QFVD1HJ-224Z CER.CAPACITOR
.22MF 5% 50V
C 949 QFVD1HJ-224Z CER.CAPACITOR
.22MF 5% 50V
C 950 QFVD1HJ-224Z CER.CAPACITOR
.22MF 5% 50V
C 951 NCB31EK-104X C CAPACITOR
C 952 NCB31EK-104X C CAPACITOR
C 953 NCB31EK-104X C CAPACITOR
C 954 NCB31EK-104X C CAPACITOR
C 961 QETM1CM-228 E CAPACITOR
2200MF 20% 16V
C 962 QERF1CM-106Z E CAPACITOR
10MF 20% 16V
C 963 QERF1CM-106Z E CAPACITOR
10MF 20% 16V
C 964 QERF1AM-227Z E CAPACITOR
220MF 20% 10V
C 965 QERF1AM-227Z E CAPACITOR
220MF 20% 10V
C 966 QERF1CM-106Z E CAPACITOR
10MF 20% 16V
C 967 QERF1CM-106Z E CAPACITOR
10MF 20% 16V
C 968 QERF1CM-106Z E CAPACITOR
10MF 20% 16V
C 969 NCB31EK-473X C CAPACITOR
C 970 NCB31EK-473X C CAPACITOR
C 971 NCB31EK-104X C CAPACITOR
C 977 QERF1AM-227Z E CAPACITOR
220MF 20% 10V
C 978 QEKJ1EM-475Z E CAPACITOR
4.7MF 20% 25V
C 979 QERF1CM-476Z E CAPACITOR
47MF 20% 16V
C 980 NCB31EK-473X C CAPACITOR
C 981 QERF1CM-107Z E CAPACITOR
100MF 20% 16V
C 982 QERF1CM-106Z E CAPACITOR
10MF 20% 16V
C 984 QERF1AM-227Z E CAPACITOR
220MF 20% 10V
CJ701 VMC0334-001 CONNECTOR
CN901 QGB1214J1-06S CONNECTOR
CN902 QGB1214J1-06S CONNECTOR
CN903 QGA2006F1-02 CONNECTOR
FX43R
CP981 QNZ0112-001 CAR CONNECTOR
D 1 1SS355-X DIODE
D 2 1SS355-X DIODE
D 3 1SS355-X DIODE
D 5 1SS355-X DIODE
D 6 UDZS9.1B-X Z DIODE
D 7 1SS355-X DIODE
D 703 UDZS6.2B-X ZENER DIODE
FX43R
D 744 1SS355-X DIODE
D 751 UDZS6.2B-X SI DIODE
D 752 UDZS6.2B-X SI DIODE
D 753 UDZS6.2B-X SI DIODE
D 754 UDZS6.2B-X SI DIODE
D 755 UDZS6.2B-X SI DIODE
D 756 UDZS6.2B-X SI DIODE
D 757 UDZS6.2B-X SI DIODE
D 776 1SS355-X DIODE
D 931 1SS355-X DIODE
D 932 1SS355-X DIODE
D 961 1N5401-F64 DIODE
D 963 1SS355-X DIODE
Item
Parts number Parts name Area
Remarks
A
B 212 NRS181J-100X MG RESISTOR
