KS-FX483R/KS-FX480R/KS-FX43R
3-11
Item
Parts number Parts name Area
Electrical parts list (Main board)
Remarks
Block No. 01
A
D 964 1SS355-X DIODE
D 965 RB160M-30-X SB DIODE
D 966 RB160M-30-X SB DIODE
D 977 1SS355-X DIODE
D 978 UDZS11B-X Z.DIODE
D 980 1SS355-X DIODE
D 982 1SS355-X DIODE
D 983 1SS355-X DIODE
D 984 1SS355-X DIODE
IC701 UPD178078GF-595 I.C(MICRO-COMP)
IC751 HD74HC126FP-X IC
IC761 SAA6579T-X IC
IC911 TEA6320T-X IC
IC941 LA4743K IC
IC961 AN80T05LF IC
J 1 QNB0100-002 ANT TERMINAL
J 751 QNZ0095-001 CONNECTOR
J 931 QNN0519-001 PIN JACK
L 1 QQL231K-4R7Y INDUCTOR
L 701 QQL231K-470Y INDUCTOR
L 702 QQL231K-470Y INDUCTOR
L 961 QQR1366-001 CHOKE COIL
PWB GEB10049-001A PRINTED BOARD
BOARD
Q
1 UN2211-X TRANSISTOR
Q
2 UN2211-X TRANSISTOR
Q
3 2SC2412K/R/-X TRANSISTOR
Q
4 UN2111-X TRANSISTOR
Q
5 2SA1037AK/RS/-X TRANSISTOR
Q
6 2SA1037AK/RS/-X TRANSISTOR
Q
7 2SC3661-X TRANSISTOR
Q
8 UN2211-X TRANSISTOR
Q
10 2SC3661-X TRANSISTOR
Q
11 2SC2412K/R/-X TRANSISTOR
Q
12 2SC2412K/R/-X TRANSISTOR
Q
131 2SC2412K/R/-X TRANSISTOR
Q
151 2SC2412K/R/-X TRANSISTOR
Q
231 2SC2412K/R/-X TRANSISTOR
Q
251 2SC2412K/R/-X TRANSISTOR
Q
301 2SD601A/R/-X TRANSISTOR
S
Q
USE
Q
302 2SD601A/R/-X TRANSISTOR
S
Q
USE
Q
701 2SC2412K/R/-X TRANSISTOR
Q
951 UN2111-X TRANSISTOR
Q
953 UN2211-X TRANSISTOR
Q
959 UN2211-X TRANSISTOR
Q
960 2SA1037AK/RS/-X TRANSISTOR
Q
961 2SA1037AK/RS/-X TRANSISTOR
Q
962 2SB1322/RS/-T TRANSISTOR
Q
963 2SA1037AK/RS/-X TRANSISTOR
Q
964 UN2211-X TRANSISTOR
Q
965 UN2211-X TRANSISTOR
Q
966 UN2211-X TRANSISTOR
Q
967 2SA1037AK/RS/-X TRANSISTOR
Q
978 UN2211-X TRANSISTOR
Q
979 UN2111-X TRANSISTOR
Q
980 UN2211-X TRANSISTOR
Q
981 UN2111-X TRANSISTOR
R 3 NRSA63J-472X MG RESISTOR
R 4 NRSA63J-473X MG RESISTOR
R 5 NRS181J-332X MG RESISTOR
R 6 NRSA63J-100X MG RESISTOR
R 7 NRSA63J-473X MG RESISTOR
R 8 NRSA63J-472X MG RESISTOR
R 9 NRSA63J-102X MG RESISTOR
R 10 NRSA63J-332X MG RESISTOR
R 12 NRSA63J-102X MG RESISTOR
R 14 NRSA63J-471X MG RESISTOR
R 24 NRS181J-102X MG RESISTOR
R 25 NRSA63J-102X MG RESISTOR
R 26 NRSA63J-103X MG RESISTOR
R 27 NRSA63J-102X MG RESISTOR
R 29 NRS181J-152X MG RESISTOR
R 32 NRSA63J-101X MG RESISTOR
R 34 NRSA63J-223X MG RESISTOR
R 112 NRSA63J-223X MG RESISTOR
R 113 NRSA63J-222X MG RESISTOR
R 132 NRSA63J-222X MG RESISTOR
R 135 NRSA63J-101X MG RESISTOR
R 136 NRSA63J-102X MG RESISTOR
R 141 NRSA63J-273X MG RESISTOR
R 142 NRSA63J-273X MG RESISTOR
R 143 NRSA63J-473X MG RESISTOR
R 144 NRSA63J-473X MG RESISTOR
R 151 NRSA63J-103X MG RESISTOR
R 152 NRSA63J-153X MG RESISTOR
R 153 NRSA63J-472X MG RESISTOR
R 212 NRSA63J-223X MG RESISTOR
R 213 NRSA63J-222X MG RESISTOR
R 232 NRSA63J-222X MG RESISTOR
R 235 NRSA63J-101X MG RESISTOR
R 236 NRSA63J-102X MG RESISTOR
R 241 NRSA63J-273X MG RESISTOR
R 242 NRSA63J-273X MG RESISTOR
R 243 NRSA63J-473X MG RESISTOR
R 244 NRS181J-473X MG RESISTOR
R 251 NRSA63J-103X MG RESISTOR
R 252 NRSA63J-153X MG RESISTOR
R 253 NRSA63J-472X MG RESISTOR
R 301 NRSA63J-473X MG RESISTOR
S
Q
USE
R 302 NRSA63J-473X MG RESISTOR
S
Q
USE
R 303 NRSA63J-103X MG RESISTOR
S
Q
USE
R 304 NRSA63J-222X MG RESISTOR
S
Q
USE
R 305 NRSA63J-153X MG RESISTOR
S
Q
USE
R 306 NRSA63J-471X MG RESISTOR
S
Q
USE
R 307 NRSA63J-103X MG RESISTOR
S
Q
USE
R 701 NRS181J-271X MG RESISTOR
R 702 NRSA63J-271X MG RESISTOR
R 703 NRS181J-271X MG RESISTOR
R 704 NRSA63J-271X MG RESISTOR
R 705 NRSA63J-103X MG RESISTOR
R 707 NRSA63J-473X MG RESISTOR
R 708 NRSA63J-104X MG RESISTOR
R 709 NRSA63J-104X MG RESISTOR
R 710 NRSA63J-473X MG RESISTOR
R 711 NRSA63J-391X MG RESISTOR
R 712 NRS181J-103X MG RESISTOR
R 713 NRSA63J-103X MG RESISTOR
R 715 NRS181J-103X MG RESISTOR
R 716 NRS181J-103X MG RESISTOR
R 717 NRS181J-103X MG RESISTOR
R 718 NRSA63J-472X MG RESISTOR
R 719 NRSA63J-472X MG RESISTOR
R 720 NRSA63J-472X MG RESISTOR
R 721 NRSA63J-472X MG RESISTOR
R 722 NRSA63J-472X MG RESISTOR
R 723 NRSA63J-472X MG RESISTOR
R 724 NRSA63J-472X MG RESISTOR
R 725 NRSA63J-472X MG RESISTOR
R 726 NRSA63J-472X MG RESISTOR
R 727 NRSA63J-472X MG RESISTOR
R 728 NRSA63J-103X MG RESISTOR
INTI. RES.
R 729 NRSA63J-472X MG RESISTOR
INTI. RES.
R 730 NRSA63J-472X MG RESISTOR
INTI. RES.
