KS-FX483R/KS-FX480R/KS-FX43R
3-3
Item
Parts number Parts name Area
A
Parts list (General assembly)
Q'ty
Description
Block No. M1MM
1 ---------------------
CDS-363SJ1
1
NEW MECHA
2 VKL7821-001
EJECT LEVER
1
3 QYSPSPT2625Z
MINI SCREW
1
4 QYSDSP2604Z
SCREW
4
MECHA+M.BKT
5 QYSDST2605Z
SCREW
2
PCB+MECHA
6 GE20134-001A
MECHA BRACKET
1
7 GE10043-011A
TOP CHASSIS
1
8 GE40135-001A
EARTH PLATE
1
9 GE30568-006A
HEAT SINK
1
10 GE30393-001A
BOTTOM COVER
1
11 FSMA3004-203
INSULATOR
1
12 QYSDST2604Z
SCREW
4
CHASSIS+MECHA B
13 FSKZ4005-001
SCREW
2
CHASSIS+SIDE PA
14 QYSDST2604Z
SCREW
2
CHASSIS+REAR BK
15 QYSDST2606Z
SCREW
2
CHASSIS+MAIN PW
16 QYSDST2612Z
SCREW
2
SIDE PANEL+IC B
17 QYSDST2004M
SCREW
2
T.CHASS+F.CHASS
18 GE10053-001A
FRONT CHASSIS
1
19 GE30583-001A
LOCK LEVER
1
20 FSKW4005-003
TORSION SPRING
1
21 FSXP3026-002
RLS KNOB
1
22 FSKW3002-004
COMP.SPRING
1
23 FSJC3014-003
CASSETTE LID
1
24 VKW4947-002
DOOR SPRING
1
25 GE10051-001A
FRONT PANEL
1
26 GE30584-009A
FINDER ASSY
1
FX480R
GE30584-012A
FINDER ASSY
1
FX43R
GE30584-008A
FINDER ASSY
1
FX483R
27 FSJK3014-001
LIGHT LENS
1
28 GE20119-001A
PRESET BUTTON
1
1-6
29 FSYH4036-077
SHEET
1
PRESET BUTTON
30 GE30304-001A
POWER BUTTON
1
31 GE20131-031A
D.FUNC BUTTON
1
FM,AM,CD-CH
32 GE30307-001A
SND FUNC BUTTON
1
33 FSYH4036-032
SHEET
1
34 GE20130-011A
PUSH BUTTON
1
TP/PTV.SEL.DISP
35 GE20120-001A
UP/DOWN BUTTON
1
36 GE20118-002A
+/- BUTTON
1
37 FSXP4007-00A
BUTTON ASSY
1
FF/REW/EJECT
38 FSKW3002-003
COMP. SPRING
1
FOR EJECT BUTTO
39 FSKW3002-003
COMP. SPRING
1
FOR FF BUTTON
40 FSKW3002-003
COMP. SPRING
1
FOR REW BUTTON
41 GE30306-001A
DETACH BUTTON
1
42 FSKW3002-012
COMP. SPRING
1
FOR DETACH BUTT
43 GE10052-001A
REAR COVER
1
44 VKZ4777-001
MINI SCREW
4
F.PANEL+REAR CO
45 QLD0250-001
LCD MODULE
1
46 QNZ0440-001
RUBBER CONNE
1
37- 1 FSXP3066-001
FF BUTTON
1
37- 2 FSXP3067-001
REW BUTTON
1
37- 3 FSXP3065-001
EJECT BUTTON
1
