4.3 HD74HC126FP-X (IC801) : Buffer
• Pin layout • Pin function
Note:
H:High level
L:Low level
X:Irrelevant
Z:Off(High-impedance)
State a 3-state input
• Block diagram
Note:
CL includes probe and jig capacitance
4.4 LB1641 (IC402) : DC motor driver
• Pin layout • Truth table
Input Output
CA Y
LX Z
HL H
HH L
1
2
3
4
5
6
7
8
9
10
GND
OUT1
P1
VZ
IN1
IN2
VCC1
VCC2
P2
OUT2
Input Output Mode
IN1 IN2 OUT1 OUT2
0000 Brake
1010 CLOCKWISE
0 1 0 1 COUNTER-CLOCKWISE
1100 Brake
