KS-FX742R
3-8
Electrical parts list
Main board
Block No. [0][1][0][0]
Symbol No.
Part No. Part Name Description Local
IC71 SAA6579T-X IC
IC161 TEA6320T-X IC
IC301 LA4743K POWER IC
IC701 UPD178078GF-596 IC
IC801 HD74HC126FP-X IC
IC901 HA13164A IC
Q1 UN2211-X TRANSISTOR
Q2 2SA1037AK/RS/-X CHIP TR.C.M
Q3 2SA1037AK/RS/-X CHIP TR.C.M
Q4 UN2111-X TRANSISTOR
Q5 UN2111-X TRANSISTOR
Q6 2SC2412K/R/-X TRANSISTOR
Q7 2SC2412K/R/-X TRANSISTOR
Q8 2SC2412K/R/-X TRANSISTOR
Q9 UN2211-X TRANSISTOR
Q12 UN2211-X TRANSISTOR
Q31 2SC3661-X TRANSISTOR
Q32 2SC3661-X TRANSISTOR
Q33 UN2211-X TRANSISTOR
Q41 2SC2412K/R/-X TRANSISTOR
Q42 2SC2412K/R/-X TRANSISTOR
Q51 2SC2412K/R/-X TRANSISTOR
Q52 2SC2412K/R/-X TRANSISTOR
Q53 UN2211-X TRANSISTOR
Q241 2SD601A/R/-X TRANSISTOR
Q341 2SD1781K/QR/-X TRANSISTOR
Q351 2SD1781K/QR/-X TRANSISTOR
Q701 2SC2412K/R/-X TRANSISTOR
Q781 UN2111-X TRANSISTOR
Q782 UN2111-X TRANSISTOR
Q784 UN2211-X TRANSISTOR
Q891 UN2211-X TRANSISTOR
Q901 UN2211-X TRANSISTOR
Q902 2SA1855/RST/-T TRANSISTOR
Q976 UN2211-X TRANSISTOR
Q977 2SA1037AK/RS/-X CHIP TR.C.M
D2 1SS355-X SI DIODE
D3 1SS355-X SI DIODE
D4 1SS355-X SI DIODE
D5 1SS355-X SI DIODE
D6 1SS355-X SI DIODE
D7 1SS355-X SI DIODE
D161 1SS355-X SI DIODE
D162 1SS355-X SI DIODE
D241 1SS355-X SI DIODE
D242 RB160M-30-X SB DIODE
D243 UDZS5.1B-X Z DIODE
D343 1SS355-X SI DIODE
D353 1SS355-X SI DIODE
D701 UDZS6.2B-X Z DIODE
D702 UDZS6.2B-X Z DIODE
D703 UDZS6.2B-X Z DIODE
D704 UDZS6.2B-X Z DIODE
D705 UDZS6.2B-X Z DIODE
D706 UDZS6.2B-X Z DIODE
D707 UDZS6.2B-X Z DIODE
D781 MTZJ11C-T1 Z DIODE
D782 1SS355-X SI DIODE
D783 1SS355-X SI DIODE
D891 1SS355-X SI DIODE
D892 1SS355-X SI DIODE
D901 1N5401-F64 DIODE
D902 1SS355-X SI DIODE
D981 RB160M-30-X SB DIODE
D982 RB160M-30-X SB DIODE
C1 QERF1CM-107Z E CAPACITOR 100uF 16V M
C2 NDC31HJ-470X C CAPACITOR 47pF 50V J
C3 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C4 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C5 QERF1HM-105Z E CAPACITOR 1uF 50V M
C6 QERF1HM-105Z E CAPACITOR 1uF 50V M
C7 QERF1HM-104Z E CAPACITOR 0.1uF 50V M
C8 NDC31HJ-470X C CAPACITOR 47pF 50V J
C9 QERF1AM-227Z E CAPACITOR 220uF 10V M
C31 NCB31EK-123X C CAPACITOR 0.012uF 25V K
C32 NCB21EK-124X C CAPACITOR 0.12uF 25V K
C33 NDC31HJ-151X C CAPACITOR 150pF 50V J
C34 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C41 NCB31HK-102X C CAPACITOR 1000pF 50V K
C42 QEQF1HM-225Z E CAPACITOR 2.2uF 50V M
C43 QERF1HM-474Z E CAPACITOR 0.47uF 50V M
C51 NDC31HJ-331X C CAPACITOR 330pF 50V J
C52 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C53 NCB31HK-472X C CAPACITOR 4700pF 50V K
C54 NCB21EK-104X C CAPACITOR 0.1uF 25V K
C55 QERF1HM-474Z E CAPACITOR 0.47uF 50V M
C71 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C72 NCB31HK-561X C CAPACITOR 560pF 50V K
C73 QERF1HM-225Z E CAPACITOR 2.2uF 50V M
C74 NDC31HJ-820X C CAPACITOR 82pF 50V J
C75 NDC31HJ-470X C CAPACITOR 47pF 50V J
C76 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C77 QERF1CM-476Z E CAPACITOR 47uF 16V M
C78 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C81 NCB31EK-153X C CAPACITOR 0.015uF 25V K
C82 NCB31HK-153X C CAPACITOR 0.015uF 50V K
C83 NCB31HK-122X C CAPACITOR 1200pF 50V K
C84 NCB31HK-122X C CAPACITOR 1200pF 50V K
C87 NCB31HK-391X C CAPACITOR 390pF 50V K
C161 QERF1HM-225Z E CAPACITOR 2.2uF 50V M
C162 QERF1HM-105Z E CAPACITOR 1uF 50V M
C163 QERF1HM-105Z E CAPACITOR 1uF 50V M
C164 QERF1HM-105Z E CAPACITOR 1uF 50V M
C165 QERF1HM-105Z E CAPACITOR 1uF 50V M
C166 QERF1HM-225Z E CAPACITOR 2.2uF 50V M
C167 QERF1CM-476Z E CAPACITOR 47uF 16V M
C168 QERF1CM-107Z E CAPACITOR 100uF 16V M
C169 NCB31HK-822X C CAPACITOR 8200pF 50V K
C170 NCB21CK-184X C CAPACITOR 0.18uF 16V K
C171 NCB31AK-224X C CAPACITOR 0.22uF 10V K
C172 NCB31HK-822X C CAPACITOR 8200pF 50V K
C173 NCB21CK-184X C CAPACITOR 0.18uF 16V K
C174 NCB31AK-224X C CAPACITOR 0.22uF 10V K
C175 NCB31EK-333X C CAPACITOR 0.033uF 25V K
C176 NCB31EK-333X C CAPACITOR 0.033uF 25V K
C177 NCB31HK-562X C CAPACITOR 5600pF 50V K
C178 NCB31HK-562X C CAPACITOR 5600pF 50V K
C180 QERF1CM-107Z E CAPACITOR 100uF 16V M
C181 QERF1HM-225Z E CAPACITOR 2.2uF 50V M
C182 QERF1HM-225Z E CAPACITOR 2.2uF 50V M
C183 QERF1HM-225Z E CAPACITOR 2.2uF 50V M
C184 QERF1HM-225Z E CAPACITOR 2.2uF 50V M
C241 QERF1HM-105Z E CAPACITOR 1uF 50V M
C242 QERF1CM-226Z E CAPACITOR 22uF 16V M
C243 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C244 NCB21EK-224X C CAPACITOR 0.22uF 25V K
C301 QERF1CM-475Z E CAPACITOR 4.7uF 16V M
C302 QERF1CM-476Z E CAPACITOR 47uF 16V M
C303 NCS31HJ-391X C CAPACITOR 390pF 50V J
C304 NCS31HJ-391X C CAPACITOR 390pF 50V J
C305 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C306 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C307 QERF1HM-475Z E CAPACITOR 4.7uF 50V M
C308 QFVD1HJ-224Z MF CAPACITOR 0.22uF 50V J
C309 QFVD1HJ-224Z MF CAPACITOR 0.22uF 50V J
C313 NCS31HJ-391X C CAPACITOR 390pF 50V J
C314 NCS31HJ-391X C CAPACITOR 390pF 50V J
C318 QFVD1HJ-224Z MF CAPACITOR 0.22uF 50V J
C319 QFVD1HJ-224Z MF CAPACITOR 0.22uF 50V J
C323 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C324 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C325 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C326 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C327 QERF1CM-226Z E CAPACITOR 22uF 16V M
C701 NCB31HK-102X C CAPACITOR 1000pF 50V K
Symbol No.
