ENGLISH 7
BASICSBASICS
❏ Adjusting the volume
To adjust the volume (00 to 35)
KW-V230BT
KW-V235DBT
KW-V330BT
Press + to increase, and press − to decrease.
• Holding + increases the volume continuously to
level 15.
To attenuate the sound (only for KW-V330BT)
The [ ] button becomes blue.
To cancel the attenuation: Press the same button
again. (The [
] button becomes white.)
❏ Turning off the screen
On the monitor panel:
(Hold)
KW-V330BT
(Hold)
KW-V230BT
KW-V235DBT
On the pop-up short-cut menu (Page11) (only for
KW-V230BT/KW-V235DBT):
Display the pop-up short-cut menu by pressing FNC
on the monitor panel, then select [Display OFF].
To turn on the screen: Press and hold the same
button, or touch the display.
❏ Turning on/off the AV source
You can activate the AV function by selecting a
source on the Home screen.
KW-V230BT/KW-V235DBT
KW-V330BT
To select a source not displayed on the Home
screen:
For KW-V230BT/KW-V235DBT: Press [All].
(Page 10)
For KW-V330BT: Press [
]. (Page 10)
To turn off the AV source:
KW-V330BT
KW-V230BT
KW-V235DBT
2017KW-VEntryE.indb72017KW-VEntryE.indb7 2016/09/2717:402016/09/2717:40

JVC KW-V235DBT Specifications

General

Audio system	MOSFET
MP3 playback	Yes
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Video formats supported	DIVX, MPEG1, MPEG2
DIN size	2 DIN
Product color	Black
Disc types supported	CD-R, CD-RW, DVD+R, DVD+RW, DVD-R, DVD-RW
Audio output channels	4.0 channels
Equalizer bands quantity	13
Maximum power per channel	50 W
Bluetooth version	3.0+HS
Bluetooth profiles	A2DP, AVRCP, HFP, PBAP
Display diagonal	6.2 \
Key illumination color	White
FM band range	87.5 - 108 MHz
LW band range	153 - 279 kHz
Supported radio bands	DAB, FM, LW, MW
Preset stations quantity	20
Package weight	3100 g

Weight and Dimensions

Weight	2000 g
Dimensions (WxDxH)	182 x 160 x 111 mm
