JVC KW-XC8

1-35
KW-XC828
Cassette mechanism
(Surface)
Arrangement of adjusting & test points
Azimuth screw
(Forward side)
Playback head
Tape speed adjust
Capstan motor
Azimuth screw (Reverse side)
DOLBY NR Level Adj.
Lch : VR401
DOLBY NR Level Adj.
Rch : VR402
Head amplifier board
DOLBY NR Level Adj.
Lch : VR401
DOLBY NR Level Adj.
Rch : VR402
Head amplifier board
