KW-XC828
3-19
Item
Parts number Parts name Ar
ea
Electrical parts list (CD mecha control board)
Remarks
Block No. 03
A
IC504 NJU7241F33-X IC
IC571 PCM1716E-X IC
IC572 NJM4565V-X IC
IC601 TA2157FN-X IC
IC621 TC94A14FA IC
IC651 NJU7241F25-X IC
IC652 TC94A02F-005 IC
IC653 W24L010AJ-12-X IC
IC681 LA6579H-X IC
L 501 NQL114K-470X INDUCTOR
L 502 NQL114K-470X INDUCTOR
L 571 NQL114K-470X INDUCTOR
L 572 NQL114K-470X INDUCTOR
L 621 NQL114K-470X INDUCTOR
L 622 NQL114K-470X INDUCTOR
L 623 NQL114K-470X INDUCTOR
L 651 NQL114K-470X INDUCTOR
L 652 NQL114K-470X INDUCTOR
L 653 NQL114K-470X INDUCTOR
Q
501 UN2111-X TRANSISTOR
Q
502 UN2211-X TRANSISTOR
Q
571 UN2111-X TRANSISTOR
Q
572 UN2211-X TRANSISTOR
Q
601 2SB1132/QR/-X TRANSISTOR
Q
681 2SB1184/QR/-X TRANSISTOR
R 501 NRSA63J-822X MG RESISTOR
R 502 NRSA63J-271X MG RESISTOR
R 503 NRSA63J-103X MG RESISTOR
R 504 NRSA63J-271X MG RESISTOR
R 505 NRSA63J-102X MG RESISTOR
R 506 NRSA63J-102X MG RESISTOR
R 507 NRSA63J-101X MG RESISTOR
R 508 NRSA63J-101X MG RESISTOR
R 509 NRSA63J-101X MG RESISTOR
R 510 NRSA63J-101X MG RESISTOR
R 511 NRSA63J-101X MG RESISTOR
R 512 NRSA63J-101X MG RESISTOR
R 513 NRSA63J-101X MG RESISTOR
R 514 NRSA63J-102X MG RESISTOR
R 515 NRSA63J-101X MG RESISTOR
R 516 NRSA63J-101X MG RESISTOR
R 517 NRSA63J-101X MG RESISTOR
R 518 NRSA63J-472X MG RESISTOR
R 519 NRSA63J-101X MG RESISTOR
R 520 NRSA63J-101X MG RESISTOR
R 521 NRSA63J-101X MG RESISTOR
R 522 NRSA63J-101X MG RESISTOR
R 523 NRSA63J-101X MG RESISTOR
R 524 NRSA63J-101X MG RESISTOR
R 525 NRSA63J-101X MG RESISTOR
R 527 NRSA63J-104X MG RESISTOR
R 528 NRSA63J-473X MG RESISTOR
R 530 NRSA63J-473X MG RESISTOR
R 531 NRSA63J-473X MG RESISTOR
R 533 NRSA63J-473X MG RESISTOR
R 534 NRSA63J-473X MG RESISTOR
R 535 NRSA63J-473X MG RESISTOR
R 536 NRSA63J-102X MG RESISTOR
R 537 NRSA63J-473X MG RESISTOR
R 538 NRSA63J-473X MG RESISTOR
R 539 NRSA63J-102X MG RESISTOR
R 540 NRSA63J-473X MG RESISTOR
R 541 NRSA63J-102X MG RESISTOR
R 542 NRSA63J-101X MG RESISTOR
R 543 NRSA63J-0R0X MG RESISTOR
R 544 NRSA63J-102X MG RESISTOR
R 545 NRSA63J-103X MG RESISTOR
R 546 NRSA63J-104X MG RESISTOR
R 547 NRSA63J-472X MG RESISTOR
R 548 NRSA63J-472X MG RESISTOR
R 549 NRSA63J-472X MG RESISTOR
R 550 NRSA63J-472X MG RESISTOR
R 551 NRSA63J-104X MG RESISTOR
R 552 NRSA63J-104X MG RESISTOR
R 553 NRSA63J-183X MG RESISTOR
R 554 NRSA63J-333X MG RESISTOR
R 555 NRSA63J-101X MG RESISTOR
R 556 NRSA63J-0R0X MG RESISTOR
R 557 NRSA63J-104X MG RESISTOR
R 558 NRSA63J-104X MG RESISTOR
R 559 NRSA63J-0R0X MG RESISTOR
R 560 NRSA63J-101X MG RESISTOR
R 561 NRSA63J-104X MG RESISTOR
R 562 NRSA63J-392X MG RESISTOR
R 563 NRSA63J-682X MG RESISTOR
R 567 NRSA63J-101X MG RESISTOR
R 568 NRSA63J-102X MG RESISTOR
R 569 NRSA63J-102X MG RESISTOR
R 570 NRSA63J-102X MG RESISTOR
R 572 NRSA63J-473X MG RESISTOR
R 573 NRSA63J-473X MG RESISTOR
R 574 NRSA63J-470X MG RESISTOR
R 581 NRSA63J-203X MG RESISTOR
R 582 NRSA63J-203X MG RESISTOR
R 583 NRSA63J-123X MG RESISTOR
R 584 NRSA63J-123X MG RESISTOR
R 585 NRSA63J-303X MG RESISTOR
R 586 NRSA63J-303X MG RESISTOR
R 587 NRSA63J-473X MG RESISTOR
R 588 NRSA63J-473X MG RESISTOR
R 589 NRSA63J-103X MG RESISTOR
R 590 NRSA63J-103X MG RESISTOR
R 591 NRSA63J-103X MG RESISTOR
R 592 NRSA63J-103X MG RESISTOR
R 593 NRSA63J-4R7X MG RESISTOR
R 601 NRSA63J-823X MG RESISTOR
R 602 NRSA63J-823X MG RESISTOR
R 603 NRSA63J-334X MG RESISTOR
R 604 NRSA63J-334X MG RESISTOR
R 605 NRSA63J-220X MG RESISTOR
R 606 NRSA63J-220X MG RESISTOR
R 607 NRSA63J-823X MG RESISTOR
R 608 NRSA63J-821X MG RESISTOR
R 609 NRSA63J-563X MG RESISTOR
R 610 NRSA63J-101X MG RESISTOR
R 611 NRSA63J-103X MG RESISTOR
R 612 NRSA63J-202X MG RESISTOR
R 613 NRSA63J-102X MG RESISTOR
R 614 NRSA63J-153X MG RESISTOR
R 615 NRSA63J-151X MG RESISTOR
R 616 NRSA63J-103X MG RESISTOR
R 621 NRSA63J-470X MG RESISTOR
R 622 NRSA63J-470X MG RESISTOR
R 623 NRSA63J-470X MG RESISTOR
R 624 NRSA63J-562X MG RESISTOR
R 625 NRSA63J-473X MG RESISTOR
Item
Parts number Parts name Ar
ea
Remarks
A
