JVC KW-XC828 - Page 89

KW-XC828
3-14
Item
Parts number Parts name Ar
ea
Electrical parts list (Main board)
Remarks
Block No. 01
A
C 992 NCS31HJ-101X C CAPACITOR
C 993 NCS31HJ-101X C CAPACITOR
C 994 NCS31HJ-101X C CAPACITOR
C 995 NCS31HJ-101X C CAPACITOR
C 996 NCS31HJ-101X C CAPACITOR
C 997 NCS31HJ-101X C CAPACITOR
C 998 NCS31HJ-101X C CAPACITOR
CN601 QGB2027M4-22S CONNECTOR
CN701 QGB1004K1-20 CONNECTOR
CN702 QGF1016F3-21 CONNECTOR
CN911 QNZ0002-001 JACK UNIT
CN951 QNN0175-001 PIN JACK
CN971 QNZ0095-001 CONNECTOR
CN972 QGF1016F3-15 CONNECTOR
CN973 QGF1016F3-21 CONNECTOR
D 1 1SS355-X DIODE
D 2 1SS355-X DIODE
D 3 MA152WK-X SI DIODE
D 81 MA152WK-X SI DIODE
D 82 1SS355-X DIODE
D 83 1SS355-X DIODE
D 84 CRS03-W SB DIODE
D 90 1SS355-X DIODE
D 91 1SS355-X DIODE
D 92 1SS355-X DIODE
D 101 MA152WA-X DIODE
D 201 MA152WA-X DIODE
D 791 1SS355-X DIODE
D 801 CRS03-W SB DIODE
D 901 UDZ11B-X ZENER DIODE
D 902 1SS355-X DIODE
D 911 1N5404-TU-15 DIODE
D 912 CRS03-W SB DIODE
D 913 CRS03-W SB DIODE
D 914 1SS355-X DIODE
D 921 UDZS6.2B-X SI DIODE
D 932 CRS03-W SB DIODE
D 933 CRS03-W SB DIODE
IC 21 TB2118F-X IC
IC701 UPD784215AGC173 IC
IC761 HD74HC126FP-X IC
IC791 IC-PST9333U-X IC
IC901 LA4743K IC
IC911 HA13164A IC
IC951 M61508FP-X IC
J 1 QNB0100-002 ANT TERMINAL
L 1 NQL334J-4R7X INDUCTOR
L 21 NQL114K-470X INDUCTOR
L 701 NQL114K-470X INDUCTOR
L 702 NQL114K-101X INDUCTOR
L 781 NQL093K-1R8X CHIP INDUCTOR
L 782 NQL093K-1R8X CHIP INDUCTOR
L 802 NQL114K-470X INDUCTOR
L 803 NQL114K-100X INDUCTOR
L 804 NQL114K-470X INDUCTOR
L 911 QQR0703-001 CHOKE COIL
L 941 NQL114K-100X INDUCTOR
L 942 NQL114K-470X INDUCTOR
L 999 NQL114K-470X INDUCTOR
Q
1 UN2211-X TRANSISTOR
Q
2 2SB815/7/-X TRANSISTOR
Q
3 2SB815/7/-X TRANSISTOR
Q
4 UN2211-X TRANSISTOR
Q
5 UN2211-X TRANSISTOR
Q
81 2SD601A/RS/-X TRANSISTOR
Q
91 UN2111-X TRANSISTOR
Q
101 2SD1048/6-7/-X TRANSISTOR
Q
102 2SD1048/6-7/-X TRANSISTOR
Q
201 2SD1048/6-7/-X TRANSISTOR
Q
202 2SD1048/6-7/-X TRANSISTOR
Q
701 UN2213-X TRANSISTOR
Q
801 UN2211-X TRANSISTOR
Q
802 UN2213-X TRANSISTOR
Q
803 UN2213-X TRANSISTOR
Q
804 UN2211-X TRANSISTOR
Q
805 UN2211-X TRANSISTOR
Q
901 UN2211-X TRANSISTOR
Q
903 UN2111-X TRANSISTOR
Q
911 UN2211-X TRANSISTOR
Q
914 2SB709A/QR/-X TRANSISTOR
Q
918 UN2111-X TRANSISTOR
Q
919 UN2211-X TRANSISTOR
Q
920 UN2211-X TRANSISTOR
Q
941 UN2211-X TRANSISTOR
Q
943 UN2213-X TRANSISTOR
R 1 NRSA63J-101X MG RESISTOR
R 2 NRSA63J-103X MG RESISTOR
R 3 NRSA63J-223X MG RESISTOR
R 4 NRSA63J-103X MG RESISTOR
R 5 NRSA63J-222X MG RESISTOR
R 6 NRSA63J-103X MG RESISTOR
R 7 NRSA63J-102X MG RESISTOR
R 8 NRS181J-100X MG RESISTOR
R 9 NRSA63J-103X MG RESISTOR
R 10 NRSA63J-221X MG RESISTOR
R 11 NRSA63J-471X MG RESISTOR
R 21 NRS181J-220X MG RESISTOR
R 22 NRSA63J-0R0X MG RESISTOR
R 23 NRSA63J-682X MG RESISTOR
R 24 NRSA63J-472X MG RESISTOR
R 25 NRSA63J-222X MG RESISTOR
R 26 NRSA63J-222X MG RESISTOR
R 27 NRSA63J-222X MG RESISTOR
R 28 NRSA63J-222X MG RESISTOR
R 29 NRSA63J-103X MG RESISTOR
R 30 NRSA63J-393X MG RESISTOR
R 31 NRSA63J-101X MG RESISTOR
R 32 NRSA63J-103X MG RESISTOR
R 33 NRSA63J-103X MG RESISTOR
R 81 NRSA63J-473X MG RESISTOR
R 82 NRSA63J-184X MG RESISTOR
R 83 NRSA63J-223X MG RESISTOR
R 84 NRSA63J-123X MG RESISTOR
R 85 NRSA63J-391X MG RESISTOR
R 86 NRSA63J-102X MG RESISTOR
R 87 NRSA63J-274X MG RESISTOR
R 108 NRSA63J-473X MG RESISTOR
R 109 NRSA63J-473X MG RESISTOR
R 111 NRSA63J-472X MG RESISTOR
R 115 NRSA63J-123X MG RESISTOR
R 121 NRSA63J-203X MG RESISTOR
R 122 NRSA63J-203X MG RESISTOR
R 131 NRSA63J-102X MG RESISTOR
R 132 NRSA63J-102X MG RESISTOR
R 133 NRSA63J-332X MG RESISTOR
R 134 NRSA63J-332X MG RESISTOR
