JVC KW-XC828 - Page 93

KW-XC828
3-18
Item
Parts number Parts name Ar
ea
Electrical parts list (CD mecha control board)
Remarks
Block No. 03
A
C 501 NCB31HK-103X C CAPACITOR
C 502 NCB31HK-103X C CAPACITOR
C 503 NCB31HK-103X C CAPACITOR
C 504 NEAD0JM-107X E CAPACITOR
C 505 NDC31HJ-270X C CAPACITOR
C 506 NDC31HJ-220X C CAPACITOR
C 507 NCS31HJ-471X C CAPACITOR
C 508 NCB31HK-103X C CAPACITOR
C 509 NCB31HK-103X C CAPACITOR
C 510 NCS31HJ-102X C CAPACITOR
C 511 NCB31CK-104X C CAPACITOR
C 512 NEAD0JM-107X E CAPACITOR
C 513 NCB31HK-103X C CAPACITOR
C 551 NCB31HK-103X C CAPACITOR
C 571 NDC31HJ-100X C CAPACITOR
C 572 NDC31HJ-100X C CAPACITOR
C 573 NCB31CK-104X C CAPACITOR
C 574 NEAD1CM-106X E CAPACITOR
C 575 NEAD0JM-476X E CAPACITOR
C 576 NCB31CK-104X C CAPACITOR
C 577 NCB31CK-104X C CAPACITOR
C 578 NEAD0JM-476X E CAPACITOR
C 579 NEAD1CM-106X E CAPACITOR
C 580 NCB31CK-104X C CAPACITOR
C 581 NCS31HJ-101X C CAPACITOR
C 582 NCS31HJ-101X C CAPACITOR
C 583 NCS31HJ-821X C CAPACITOR
C 584 NCS31HJ-821X C CAPACITOR
C 585 NEAD1VM-475X E CAPACITOR
C 586 NEAD1VM-475X E CAPACITOR
C 587 NCS31HJ-121X C CAPACITOR
C 588 NCS31HJ-121X C CAPACITOR
C 589 NEAD1VM-475X E CAPACITOR
C 590 NEAD1VM-475X E CAPACITOR
C 591 NEAD0JM-476X E CAPACITOR
C 592 NEAD0JM-476X E CAPACITOR
C 593 NEAD1CM-476X E CAPACITOR
C 594 NCS31HJ-102X C CAPACITOR
C 595 NCB31CK-473X C CAPACITOR
C 596 NCS31HJ-101X C CAPACITOR
C 597 NCS31HJ-102X C CAPACITOR
C 598 NCS31HJ-102X C CAPACITOR
C 601 NEAD0JM-476X E CAPACITOR
C 602 NCB31HK-103X C CAPACITOR
C 603 NEAD0JM-107X E CAPACITOR
C 604 NCB31HK-103X C CAPACITOR
C 605 NCB31HK-682X C CAPACITOR
C 606 NEAD0JM-476X E CAPACITOR
C 607 NCB31HK-103X C CAPACITOR
C 608 NCB31CK-104X C CAPACITOR
C 609 NCB31CK-104X C CAPACITOR
C 610 NDC31HJ-5R0X C CAPACITOR
C 611 NCS31HJ-680X C CAPACITOR
C 612 NCB31HK-103X C CAPACITOR
C 613 NCB31HK-103X C CAPACITOR
C 614 NCB31HK-103X C CAPACITOR
C 621 NCB31HK-103X C CAPACITOR
C 622 NEAD0JM-476X E CAPACITOR
C 623 NCS31HJ-470X C CAPACITOR
C 624 NCB31HK-153X C CAPACITOR
C 625 NCB31HK-103X C CAPACITOR
C 626 NCB31HK-272X C CAPACITOR
C 627 NCB31HK-103X C CAPACITOR
C 628 NEAD0JM-476X E CAPACITOR
C 629 NCB31EK-333X C CAPACITOR
C 630 NCB31EK-333X C CAPACITOR
C 631 NCS31HJ-471X C CAPACITOR
C 632 NCS31HJ-471X C CAPACITOR
C 633 NCB31CK-473X C CAPACITOR
C 634 NCB31CK-473X C CAPACITOR
C 635 NCB31CK-473X C CAPACITOR
C 636 NCB31CK-473X C CAPACITOR
C 637 NCB31CK-473X C CAPACITOR
C 638 NCB31HK-103X C CAPACITOR
C 639 NEAD0JM-476X E CAPACITOR
C 640 NCB31HK-103X C CAPACITOR
C 641 NEAD0JM-476X E CAPACITOR
C 642 NCS31HJ-101X C CAPACITOR
C 643 NCB31HK-103X C CAPACITOR
C 644 NCB31AK-334X C CAPACITOR
C 645 NEAD0JM-476X E CAPACITOR
C 646 NCB31HK-103X C CAPACITOR
C 651 NEAD0JM-476X E CAPACITOR
C 652 NCB31HK-103X C CAPACITOR
C 653 NEAD0JM-476X E CAPACITOR
C 654 NCB31CK-104X C CAPACITOR
C 655 NCB31HK-103X C CAPACITOR
C 656 NCB31CK-104X C CAPACITOR
C 657 NCB31CK-104X C CAPACITOR
C 658 NCB31CK-104X C CAPACITOR
C 659 NCB31CK-104X C CAPACITOR
C 660 NCS31HJ-101X C CAPACITOR
C 661 NCB31HK-103X C CAPACITOR
C 662 NCS31HJ-101X C CAPACITOR
C 663 NCB31CK-104X C CAPACITOR
C 664 NCB31EK-273X C CAPACITOR
C 665 NCB31AK-334X C CAPACITOR
C 666 NCS31HJ-101X C CAPACITOR
C 667 NCB31HK-103X C CAPACITOR
C 668 NEAD0JM-476X E CAPACITOR
C 669 NCB31HK-103X C CAPACITOR
C 671 NEAD0JM-476X E CAPACITOR
C 672 NCB31CK-104X C CAPACITOR
C 673 NCS31HJ-101X C CAPACITOR
C 682 NEAD1CM-106X E CAPACITOR
C 683 NCB31CK-104X C CAPACITOR
C 684 NEAD1CM-476X E CAPACITOR
C 685 NCB31CK-473X C CAPACITOR
C 686 NCB31CK-473X C CAPACITOR
C 687 NCB31CK-473X C CAPACITOR
C 688 NCB31CK-473X C CAPACITOR
C 689 NEAD1CM-476X E CAPACITOR
C 690 NBE20JM-106X TS E CAPACITOR
CN501 QGB2027L1-22X CONNECTOR
CN502 QGF0501F1-08X CONNECTOR
CN601 QGF0526F1-22X FPC CONNECTOR
D 501 1SS355-X DIODE
D 502 1SS355-X DIODE
D 503 1SS355-X DIODE
D 504 1SS355-X DIODE
D 505 1SS355-X DIODE
D 506 CRS03-W SB DIODE
D 682 1SR154-400-X DIODE
IC501 UPD784225GK-624 IC
IC502 BR24C01AFV-W-X IC
IC503 HD74HCT126T-X IC
Item
Parts number Parts name Ar
ea
Remarks
A
