2
Black /
Fuse block /
Ignition switch /
Blue (white stripe) /
(
)
Red /
Yellow /
*
3
To the metallic body or chassis of the car /
To an accessory terminal /
To a live terminal (constant 12 V) /
(
12 V)
To the automatic antenna if any (250 mA max.) /
( 250 mA)
White /
White (black stripe) /
(
)
Gray /
Gray (black stripe) /
(
)
Green /
Green (black stripe) /
(
)
Purple /
Purple (black stripe) /
(
)
Rear ground terminal /
15 A fuse /
15 A
Antenna input /
Front speaker (left) /
()
Front speaker (right) /
()
Rear speaker (left) /
()
Rear speaker (right) /
()
ELECTRICAL CONNECTIONS /
Reset the unit. /
To the remote lead of other equipment (200 mA max.) /
( 200 mA)
Blue
/
IMPORTANT: A custom wiring harness (separately purchased) which is suitable for your car is
recommended for connection between the unit and your car.
• Consult your JVC car audio dealer or a company supplying kits for details.
:
(
)
• JVC
D Power cord /
*
1
Firmly attach the ground wire to the metallic body or to the chassis of the car—to the place uncoated
with paint.
*
2
Not supplied for this unit.
*
3
Before checking the operation of this unit prior to installation, this lead must be connected; otherwise,
the power cannot be turned on.
*
1
—
*
2
*
3
Steering wheel remote input /
Orange with white stripe /
To car light control switch /
USB cable (approx. 1.2 m) /
USB ( 1.2 .)
To the blue (white stripe)
lead of the unit /
(
)
Connecting a subwoofer (through a JVC amplifier) /
(
JVC)
Connecting the front speakers (through a JVC amplifier) /
(
JVC)
Connecting the rear speakers (through a JVC amplifier) /
(
JVC)
Å Signal cord /
*
2
ı Remote lead /
Ç Y-connector /
Y *
2
JVC Amplifier /
JVC
JVC Amplifier /
JVC
JVC Amplifier /
JVC
Subwoofer /
Front speakers /
Rear speakers /
Adjust the microphone angle /
Secure the microphone
cord using cord cramps *
2
if necessary. /
*
2
F Microphone clip /
F Microphone clip /
E Microphone /
– – – – – – – – – – or / – – – – – – – – – –
MIC (microphone
input terminal /
)
Connecting the microphone unit /
