1-12 (No.YA509)
154 DRO1_5 O Not used
155 DRO1_6 O Not used
156 VSUP3.3LVDS I 3.3V power supply
157 DRO1_8 O Not used
158 DRO1_9 O Not used
159 AGC I RF AGC voltage for VHF/UHF tuner
160 KEY1 I
Key scan for side control (POWER/CH+/CH-/MENU)
161 SLOW1 I EXT-1 SLOW detection
162 SLOW2 I EXT-2 SLOW detection
163 GND3.3DAC - GND
164 VSUP3.3DAC I 3.3V power supply
165 DC_DIM O DC dimming control for back-light inverter
166 PWM_DIM O
PWM dimming control for back-light inverter
167 DTV_SW O
Audio output select for EXT-2 [Digital tuner = H]
168 SUB_MUTE O Audio output muting [Muting = L]
169 VSUP1.8FE I 1.8V power supply
170 VSUP3.3FE I 3.3V power supply
171 HD_DV1 I H sync for HDMI
172 SC_B1 I B input for EXT-1
173 SC_G1 I G input for EXT-1
174 SC_R1 I R input for EXT-1
175 SC_YS2 I Ys input for EXT-2
176 E3_PB I Pb input for EXT-3
177 E3_Y I Y input for EXT-3
178 E3_PR I Pr input for EXT-3
179 SC_B2 I B input for EXT-2
180 SC_G2 I G input for EXT-2
181 SC_R2/C I R/C input for EXT-2
182 D_BY I Pb input for digital tuner
183 SC_YS1 I Ys input for EXT-1
184 D_Y I Y input for digital tuner
185 VSUP1.8FE I 1.8V power supply
186 GNDA - GND
187 D_RY I Pr input for digital tuner
188 D_CV I Video input for digital tuner
189 E1_CV I Video input for EXT-1
190 E2_CV/Y I Video/Y input for EXT-2
191 TV_CV I Video input for VHF/UHF tuner
192 VSUP3.3VO I 3.3V power supply
193 VOUT3 O Not used
194 VOUT2 O Not used
195 V2_OUT O Video output for EXT-2
196 GND3.3IO3 - GND
197 VSUP3.3IO3 I 3.3V power supply
198 656I0 I Not used
199 656I1 I Not used
200 656I2 I Not used
201 656I3 I Not used
202 656I4 I Not used
203 656I5 I Not used
204 656I6 I Not used
205 656I7 I Not used
206 656CLKI I Not used
207 656CLKO O Not used
208 TV_LINK_IN I Data input from T-V LINK
Pin Pin name I/O Function
