JVC LT-32DA8BJ Service Manual

(No.YA509)3-11
PRINTED WIRING BOARD PARTS LIST [LT-26DA8BJ, LT-26DA8SJ, LT-26DT8ZJ]
MAIN P.W. BOARD ASS'Y (SFT-1001A-U2)
 Ref No. Part No. Part Name Description Local
IC1001 MM1510XN-X IC
IC1002 MM1510XN-X IC
IC1003 TC4066BF/N/-XE IC
IC1005 TC4066BF/N/-XE IC
IC6001 TPA3100D2PHP-W IC
IC6011 BH3547F-X IC
IC7001 VCT6973GFAB3000 IC
IC7002 S-80928CLNB-G-W IC
IC7003 ATE256-26DA8 IC (SERVICE)
IC7004 M62320FP-X IC
IC9101 MM1661JH-X IC
IC9151 MM1661JH-X IC
IC9161 MM1661JH-X IC
IC9201 MP2363DN-X IC
IC9301 MP2363DN-X IC
IC9401 MP2363DN-X IC
IC9451 PQ025EN01Z-X IC
IC9501 S7808D-W IC
IC9511 S7809D-W IC
IC9521 BAJ2CC0WFP-X IC
Q1001 2SA812A/5-6/-X SI TRANSISTOR
Q1002 2SC5477-X TRANSISTOR
Q1003 2SC1623A/5-6/-X SI TRANSISTOR
Q1004 2SC1623A/5-6/-X SI TRANSISTOR
Q1005 2SC1623A/5-6/-X SI TRANSISTOR
Q1101 2SA812A/5-6/-X SI TRANSISTOR
Q1102 RT4N430C-X DIGI TRANSISTOR
Q1103 RT4N430C-X DIGI TRANSISTOR
Q1201 2SA812A/5-6/-X SI TRANSISTOR
Q1202 RT4N430C-X DIGI TRANSISTOR
Q1203 RT4N430C-X DIGI TRANSISTOR
Q1204 2SC1623A/5-6/-X SI TRANSISTOR
Q1205 2SC1623A/5-6/-X SI TRANSISTOR
Q1206 RT1N441C-X TRANSISTOR
Q1207 RT1N441C-X TRANSISTOR
Q1208 2SA812A/5-6/-X SI TRANSISTOR
Q1209 2SC3928A/QR/-X TRANSISTOR
Q1210 2SC3928A/QR/-X TRANSISTOR
Q1351 RT1N441C-X TRANSISTOR
Q1352 RT1N441C-X TRANSISTOR
Q6105 RT1N441C-X TRANSISTOR
Q6106 2SC1623A/5-6/-X SI TRANSISTOR
Q6501 2SA812A/5-6/-X SI TRANSISTOR
Q6502 2SA812A/5-6/-X SI TRANSISTOR
Q6503 RT4N430C-X DIGI TRANSISTOR
Q7001 RT1P441C-X DIGI TRANSISTOR
Q7002 2SC1623A/5-6/-X SI TRANSISTOR
Q7003 2SC1623A/5-6/-X SI TRANSISTOR
Q7004 2SC1623A/5-6/-X SI TRANSISTOR
Q7005 RT1P441C-X DIGI TRANSISTOR
Q7008 RT1P441C-X DIGI TRANSISTOR
Q7010 2SK3019-X MOS FET
Q7011 2SK3019-X MOS FET
Q7013 RT1N441C-X TRANSISTOR
Q7022 RT1N441C-X TRANSISTOR
Q9201 2SC1623A/5-6/-X SI TRANSISTOR
Q9301 2SC1623A/5-6/-X SI TRANSISTOR
D1102 UDZW3.6B-X Z DIODE
D1103 UDZW8.2B-X Z DIODE
D1104 UDZW8.2B-X Z DIODE
D1202 UDZW3.6B-X Z DIODE
D1203 UDZW5.6B-X Z DIODE
D1204 UDZW5.6B-X Z DIODE
D1207 1SS355W-X DIODE
D1208 1SS355W-X DIODE
D1209 1SS355W-X DIODE
D1221 UDZW8.2B-X Z DIODE
D1222 UDZW8.2B-X Z DIODE
D1251 1SS355W-X DIODE
D1252 UDZW6.8B-X Z DIODE
D6101 1SS355W-X DIODE
D6104 1SS355W-X DIODE
D6501 1SS355W-X DIODE
D6503 1SS355W-X DIODE
D7001 UDZW8.2B-X Z DIODE
D7002 UDZW8.2B-X Z DIODE
D7003 UDZW8.2B-X Z DIODE
D7004 UDZW8.2B-X Z DIODE
D7005 UDZW8.2B-X Z DIODE
D7006 UDZW8.2B-X Z DIODE
D7008 UDZW3.6B-X Z DIODE
D7009 UDZW3.6B-X Z DIODE
D7010 UDZW3.6B-X Z DIODE
D7011 UDZW3.6B-X Z DIODE
D7012 UDZW3.6B-X Z DIODE
D7013 UDZW3.6B-X Z DIODE
D7014 UDZW3.6B-X Z DIODE
D7015 UDZW3.6B-X Z DIODE
D7016 UDZW3.6B-X Z DIODE
D7017 UDZW3.6B-X Z DIODE
D7018 UDZW3.6B-X Z DIODE
D7019 UDZW3.6B-X Z DIODE
D7020 UDZW3.6B-X Z DIODE
D7023 UDZS3.3B-X Z DIODE
D7024 UDZS3.3B-X Z DIODE
D7025 UDZS3.3B-X Z DIODE
D7026 UDZW5.6B-X Z DIODE
D7027 UDZW5.6B-X Z DIODE
D7028 UDZW5.6B-X Z DIODE
D7029 UDZW5.6B-X Z DIODE
D7030 UDZW5.6B-X Z DIODE
D9201 RB055L-40-X SB DIODE
D9202 RB055L-40-X SB DIODE
D9203 PTZ6.8B-X Z DIODE
D9204 1SS355W-X DIODE
D9206 UDZW3.0B-X Z DIODE
D9301 RB055L-40-X SB DIODE
D9302 RB055L-40-X SB DIODE
D9303 PTZ6.8B-X Z DIODE
D9304 1SS355W-X DIODE
D9401 RB055L-40-X SB DIODE
D9402 RB055L-40-X SB DIODE
D9403 PTZ3.9B-X Z DIODE
D9421 RB501V-40-X SB DIODE
C1001 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1002 NEHL1AM-107X E CAPACITOR 100uF 10V M
C1006 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C1007 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C1008 NEHL1HM-106X E CAPACITOR 10uF 50V M
C1009 NEHL1EM-106X E CAPACITOR 10uF 25V M
C1010 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1011 NCB31HK-821X C CAPACITOR 820pF 50V K
C1012 NDC31HJ-470X C CAPACITOR 47pF 50V J
C1013 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1014 NDC31HJ-470X C CAPACITOR 47pF 50V J
C1015 NDC31HJ-180X C CAPACITOR 18pF 50V J
C1016 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1017 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C1101 NEHL1CM-106X E CAPACITOR 10uF 16V M
C1102 NEHL1AM-107X E CAPACITOR 100uF 10V M
C1103 NEHL1CM-106X E CAPACITOR 10uF 16V M
C1104 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1105 NCB31CK-105X C CAPACITOR 1uF 16V K
C1107 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1110 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1111 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1112 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1113 NEHL1CM-106X E CAPACITOR 10uF 16V M
C1114 NEHL1CM-106X E CAPACITOR 10uF 16V M
C1201 NEHL1CM-106X E CAPACITOR 10uF 16V M
C1202 NEHL1AM-107X E CAPACITOR 100uF 10V M
C1203 NEHL1CM-106X E CAPACITOR 10uF 16V M
C1204 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1205 NCB31CK-105X C CAPACITOR 1uF 16V K
C1207 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1208 NCB31HK-152X C CAPACITOR 1500pF 50V K
C1209 NCB31HK-152X C CAPACITOR 1500pF 50V K
C1210 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1211 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1212 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1213 NEHL1CM-106X E CAPACITOR 10uF 16V M
C1214 NEHL1CM-106X E CAPACITOR 10uF 16V M
C1215 NCB11CK-475X C CAPACITOR 4.7uF 16V K
C1216 NCB31CK-105X C CAPACITOR 1uF 16V K
C1217 NCB31CK-105X C CAPACITOR 1uF 16V K
C1218 NCB31CK-105X C CAPACITOR 1uF 16V K
C1219 NCB31CK-105X C CAPACITOR 1uF 16V K
C1220 NEHL1CM-106X E CAPACITOR 10uF 16V M
C1221 NEHL1CM-107X E CAPACITOR 100uF 16V M
C1251 NEHL1CM-476X E CAPACITOR 47uF 16V M
C1306 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1307 NCB31HK-472X C CAPACITOR 4700pF 50V K
C1351 NEHL1CM-106X E CAPACITOR 10uF 16V M
C1352 NCB31CK-105X C CAPACITOR 1uF 16V K
C1353 NCB31CK-105X C CAPACITOR 1uF 16V K
C1354 NCB31CK-105X C CAPACITOR 1uF 16V K
C1355 NCB31CK-105X C CAPACITOR 1uF 16V K
C1356 NEHL1CM-106X E CAPACITOR 10uF 16V M
C6011 NCJ21CK-475X-R C CAPACITOR 4.7uF 16V K
