3-22(No.YA509)
SW P.W. BOARD ASS'Y (SFT-7201A-U2)
REFER TO PARTS LIST IN PAGE 3-9 FOR THIS P.W. BOARD.
LED P.W. BOARD ASS'Y (SFT-8901A-U2)
REFER TO PARTS LIST IN PAGE 3-9 FOR THIS P.W. BOARD.
POWER P.W. BOARD ASS'Y (SFT-9002A-U2)
REFER TO PARTS LIST IN PAGE 3-9 FOR THIS P.W. BOARD.
R9321 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R9322 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R9401 NRSA02J-680X MG RESISTOR 68
Ω
1/10W J
R9402 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R9403 NRSA63D-273X MG RESISTOR 27k
Ω
1/16W D
R9404 NRSA63J-335X MG RESISTOR 3.3M
Ω
1/16W J
R9405 NRSA63D-103X MG RESISTOR 10k
Ω
1/16W D
R9410 NRS181J-181X MG RESISTOR 180
Ω
1/8W J
R9421 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R9422 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
RA7001 NRZ0034-103W NET RESISTOR 10k
Ω
1/32W J x4
RA7002 NRZ0034-0R0W NET RESISTOR 0
Ω
1/32W J x4
RA7003 NRZ0034-0R0W NET RESISTOR 0
Ω
1/32W J x4
RA7004 NRZ0034-0R0W NET RESISTOR 0
Ω
1/32W J x4
RA7007 NRZ0034-103W NET RESISTOR 10k
Ω
1/32W J x4
RA7008 NRZ0034-103W NET RESISTOR 10k
Ω
1/32W J x4
L1001 NQL79GM-220X COIL 22uH M
L1002 NQL79GM-100X COIL 10uH M
L1003 NQL093M-220X COIL 22uH M
L1004 NQL093M-180X COIL 18uH M
L6101 NQLF3EM-330X COIL 33uH M
L6102 NQLF3EM-330X COIL 33uH M
L6103 NQLF3EM-330X COIL 33uH M
L6104 NQLF3EM-330X COIL 33uH M
L7001 NQL79GM-100X COIL 10uH M
L7002 NQL79GM-100X COIL 10uH M
L7003 NQL79GM-100X COIL 10uH M
L7004 NQL79GM-100X COIL 10uH M
L7005 NQL79GM-100X COIL 10uH M
L7006 NQL79GM-100X COIL 10uH M
L7007 NQL79GM-100X COIL 10uH M
L7008 NQL79GM-2R2X COIL 2.2uH M
L7009 NQL79GM-2R2X COIL 2.2uH M
L7010 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
L7011 NQL79GM-100X COIL 10uH M
L7012 NQL79GM-100X COIL 10uH M
L7013 NQL79GM-4R7X COIL 4.7uH M
L7014 NQL79GM-100X COIL 10uH M
L7015 NQL79GM-100X COIL 10uH M
L7016 NQL79GM-100X COIL 10uH M
L7017 NQL79GM-100X COIL 10uH M
L9201 NQLD7EM-150X COIL 15uH M
L9301 NQL98EM-150X COIL 15uH M
L9401 NQL98EM-150X COIL 15uH M
J1001 QNZ0419-001 21P CONNECTOR EXT-1
J1002 QNZ0419-001 21P CONNECTOR EXT-2
J1003 QNN0801-001 PIN JACK EXT-3
J8501 QNZ0900-001 HDMI CONNECTOR EXT-4
J8502 QNZ0900-001 HDMI CONNECTOR EXT-5
K1001 NQR0389-003X FERRITE BEADS
K1101 NQR0599-004X FERRITE BEADS
K1102 NQR0389-003X FERRITE BEADS
K1103 NQR0389-003X FERRITE BEADS
K1201 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
K1202 NQR0389-003X FERRITE BEADS
K1203 NQR0389-003X FERRITE BEADS
K6101 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K6102 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K6103 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K6104 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K6111 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K6112 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K6113 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K6114 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K6115 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K7001 NQR0389-003X FERRITE BEADS
K7003 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K7004 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K7005 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K7006 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K9151 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K9161 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K9162 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K9201 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K9202 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K9301 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K9302 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
K9401 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
LC7001 NQR0479-001X EMI FILTER
OT1 LC42056-001A SHADE SPACER
TU1001 QAU0488-002 TUNER
X7001 NAX0661-001X CRYSTAL 20.2MHz
Ref No. Part No. Part Name Description Local
To Next Page
