JVC LT-32DA8BJ Service Manual

3-4(No.YA509)
EXPLODED VIEW PARTS LIST
 Ref.No. Part No. Part Name Description Local
1 LC42446-002A SCREW (x5)
2 QYSBSFG4016MA TAP SCREW M4 x 16mm(x6)
3 QYSBSF3010MA TAP SCREW M3 x 10mm(x5)
4 QYSPSPD5014MA SCREW M5 x 14mm(x4)
5 LC33651-001A-JK BACK BRACKET (x2)
6 WJZ0247-002A-E WIRE POWER-LCD PANEL
LT-26A80ZU,LT-26A80SU,LT-26DA8BJ,LT-26DA8SJ,LT-26DT8ZJ,LT-26DA8SU,LT-26DA8ZU
6 WJZ0248-002A-E WIRE POWER-LCD PANEL LT-32A80SU,LT-32A80ZU,LT-32DA8SJ,LT-32DT8ZJ,LT-32DA8BJ,LT-32DA8SU,LT-32DA8ZU
7 QJK002-091004-E WIRE POWER-MAIN
8 QJK002-080903-E WIRE POWER-MAIN
9 QQR0490-001 NOISE FILTER
10 WJW0041-001A-E DIGITAL(LVDS)CABLE LCD PANEL-MAIN
11 WJX0044-003A-E E-COAXIAL ASSY MAIN-DIGITAL LT-26DA8BJ,LT-26DA8SJ,LT-26DT8ZJ,LT-26DA8SU,LT-26DA8ZU,LT-32DA8SJ,LT-32DT8ZJ,LT-32DA8BJ,LT-32DA8SU,LT-32DA8ZU
12 QYSPSP3004ZA SCREW M3 x 4mm(x2)
13 QYSBSF3010MA TAP SCREW M3 x 10mm
14 LC42828-001A-C NUT
15 GG20176-001A-H PC SHEET LT-26DA8BJ,LT-26DA8SJ,LT-26DT8ZJ,LT-26DA8SU,LT-26DA8ZU,LT-32DA8SJ,LT-32DT8ZJ,LT-32DA8BJ,LT-32DA8SU,LT-32DA8ZU
16 QNB0036-001 CONNECTOR ACCESSORY (x2) LT-26DA8BJ,LT-26DA8SJ,LT-26DT8ZJ,LT-26DA8SU,LT-26DA8ZU,LT-32DA8SJ,LT-32DT8ZJ,LT-32DA8BJ,LT-32DA8SU,LT-32DA8ZU
 17 LC33857-001A-U DIGITAL BASE LT-26DA8BJ,LT-26DA8SJ,LT-26DT8ZJ,LT-26DA8SU,LT-26DA8ZU,LT-32DA8SJ,LT-32DT8ZJ,LT-32DA8BJ,LT-32DA8SU,LT-32DA8ZU
 18 QMPK450-170-JC POWER CORD(EU) 1.7m BLACK LT-26A80ZU,LT-26A80SU,LT-26DA8SU,LT-26DA8ZU,LT-32A80SU,LT-32A80ZU,LT-32DA8SU,LT-32DA8ZU
 18 QMPN370-170-JC POWER CORD(EK) 1.7m BLACK LT-26DA8BJ,LT-26DA8SJ,LT-26DT8ZJ,LT-32DA8SJ,LT-32DT8ZJ,LT-32DA8BJ
20 WJZ0270-001A-E WIRE LT-26DA8BJ,LT-26DA8SJ,LT-26DT8ZJ,LT-26DA8SU,LT-26DA8ZU,LT-32DA8SJ,LT-32DT8ZJ,LT-32DA8BJ,LT-32DA8SU,LT-32DA8ZU
21 LC13067-001A-U SUPPORT UNIT
22 LC13068-001A-U STAND BASE LT-26A80ZU,LT-26DT8ZJ,LT-26DA8ZU,LT-32A80ZU,LT-32DT8ZJ,LT-32DA8ZU
22 LC13068-002A-U STAND BASE LT-26A80SU,LT-26DA8BJ,LT-26DA8SJ,LT-26DA8SU,LT-32A80SU,LT-32DA8SJ,LT-32DA8BJ,LT-32DA8SU
23 LC42759-001A-C FOOT (x6)
24 QYSBSF4012ZA TAP SCREW M4 x 12mm(x4) LT-26A80ZU,LT-26A80SU,LT-26DA8BJ,LT-26DA8SU,LT-26DA8ZU,LT-32A80SU,LT-32A80ZU,LT-32DA8BJ,LT-32DA8SU,LT-32DA8ZU
24 QYSBSF4010MA TAP SCREW M4 x 10mm(x4) LT-26DA8SJ,LT-26DT8ZJ,LT-32DA8SJ,LT-32DT8ZJ
 27 QLD0443-001-JUK LCD PANEL UNIT Inc.27A,27B LT-26A80ZU,LT-26A80SU,LT-26DA8BJ,LT-26DA8SJ,LT-26DT8ZJ,LT-26DA8SU,LT-26DA8ZU
 27 QLD0444-001-JUK LCD PANEL UNIT Inc.27A,27B LT-32A80SU,LT-32A80ZU,LT-32DA8SJ,LT-32DT8ZJ,LT-32DA8BJ,LT-32DA8SU,LT-32DA8ZU
 27A AU-55.26T02.055 CONTROL PWB T260 x W02 v6 LT-26A80ZU,LT-26A80SU,LT-26DA8BJ,LT-26DA8SJ,LT-26DT8ZJ,LT-26DA8SU,LT-26DA8ZU
 27A AU-55.31T03.035 CONTROL PWB T315 x W02 v1 LT-32A80SU,LT-32A80ZU,LT-32DA8SJ,LT-32DT8ZJ,LT-32DA8BJ,LT-32DA8SU,LT-32DA8ZU
 27B AU-19.26006.213 INVERTER PWB T260 x W02 v6 LT-26A80ZU,LT-26A80SU,LT-26DA8BJ,LT-26DA8SJ,LT-26DT8ZJ,LT-26DA8SU,LT-26DA8ZU
 27B AU-19.26006.191 INVERTER PWB T315 x W02 v1 LT-32A80SU,LT-32A80ZU,LT-32DA8SJ,LT-32DT8ZJ,LT-32DA8BJ,LT-32DA8SU,LT-32DA8ZU
 28 LC12642-004A-U FRONT PANEL LT-26A80ZU,LT-26DT8ZJ,LT-26DA8ZU
 28 LC12642-003A-U FRONT PANEL LT-26A80SU,LT-26DA8SJ,LT-26DA8SU
 28 LC12642-005A-U FRONT PANEL LT-26DA8BJ
 28 LC12647-003A-U FRONT PANEL LT-32A80SU,LT-32DA8SJ,LT-32DA8SU
 28 LC12647-004A-U FRONT PANEL LT-32A80ZU,LT-32DT8ZJ,LT-32DA8ZU
 28 LC12647-005A-U FRONT PANEL LT-32DA8BJ
30 LC22340-004A-H INDICATE WINDOW LT-26A80ZU
30 LC22340-003A-H INDICATE WINDOW LT-26A80SU
30 LC22340-007A-H INDICATE WINDOW LT-26DA8BJ
30 LC22340-005A-H INDICATE WINDOW LT-26DA8SJ,LT-26DA8SU
30 LC22340-006A-H INDICATE WINDOW LT-26DT8ZJ,LT-26DA8ZU
30 LC22341-004A-H INDICATE WINDOW LT-32A80SU
30 LC22341-005A-H INDICATE WINDOW LT-32A80ZU
30 LC22341-006A-H INDICATE WINDOW LT-32DA8SJ,LT-32DA8SU
30 LC22341-007A-H INDICATE WINDOW LT-32DT8ZJ,LT-32DA8ZU
30 LC22341-008A-H INDICATE WINDOW LT-32DA8BJ
31 LC41458-002A TAPPING SCREW (x6)
32 LC42801-001A-C JVC MARK
33 LC40226-005A-H SPACER (x6)
35 QAS0525-001 SPEAKER (x2)
 36 LC33854-001A-U CONTROL KNOB
 37 LC33855-001A-U POWER CODE HOLDER
 38 LC12939-002A-U REAR COVER LT-26A80ZU,LT-26A80SU
 38 LC12939-001A-U REAR COVER LT-26DA8BJ,LT-26DA8SJ,LT-26DT8ZJ,LT-26DA8SU,LT-26DA8ZU
 38 LC12942-002A-U REAR COVER LT-32A80SU,LT-32A80ZU
 38 LC12942-001A-U REAR COVER LT-32DA8SJ,LT-32DT8ZJ,LT-32DA8BJ,LT-32DA8SU,LT-32DA8ZU
39 QYSDSF3016MA TAP SCREW M3 x 16mm(x2)
40 LC22406-001A-H SPEAKER HOLDER LT-26A80ZU,LT-26A80SU,LT-32A80ZU,LT-32DA8BJ,LT-32DA8ZU
40 LC22406-001B-HK SPEAKER HOLDER LT-26DA8BJ,LT-26DA8ZU,LT-32A80SU
40 LC22334-001A-U SPEAKER HOLDER LT-26DA8SJ,LT-26DT8ZJ,LT-26DA8SU,LT-32DA8SJ,LT-32DT8ZJ,LT-32DA8SU
41 LC22406-002A-H SPEAKER HOLDER LT-26A80ZU,LT-26A80SU,LT-32A80ZU,LT-32DA8BJ,LT-32DA8ZU
41 LC22406-002B-HK SPEAKER HOLDER LT-26DA8BJ,LT-26DA8ZU,LT-32A80SU
41 LC22334-002A-U SPEAKER HOLDER LT-26DA8SJ,LT-26DT8ZJ,LT-26DA8SU,LT-32DA8SJ,LT-32DT8ZJ,LT-32DA8SU
42 QQR0490-001 NOISE FILTER LT-26A80ZU,LT-26A80SU,LT-26DA8BJ,LT-26DA8SJ,LT-26DT8ZJ,LT-26DA8SU,LT-26DA8ZU
43 WJZ0279-001A-E WIRE LT-26A80ZU,LT-26A80SU,LT-26DA8BJ,LT-26DA8SJ,LT-26DT8ZJ,LT-26DA8SU,LT-26DA8ZU
43 WJZ0279-002A-E WIRE LT-32A80ZU,LT-32DA8SJ,LT-32DT8ZJ,LT-32DA8BJ,LT-32DA8SU,LT-32DA8ZU
44 QNZ0901-001 RF CONNECTOR
 201 SFT-9002A-U2 POWER PWB
 202 SFT-1003A-U2 MAIN PWB LT-26A80ZU,LT-26A80SU
 202 SFT-1001A-U2 MAIN PWB LT-26DA8BJ,LT-26DA8SJ,LT-26DT8ZJ
 202 SFT-1008A-U2 MAIN PWB LT-26DA8SU,LT-26DA8ZU
 202 SFT-1004A-U2 MAIN PWB LT-32A80SU,LT-32A80ZU
 202 SFT-1002A-U2 MAIN PWB LT-32DA8SJ,LT-32DT8ZJ,LT-32DA8BJ
 202 SFT-1010A-U2 MAIN PWB LT-32DA8SU,LT-32DA8ZU
 203 SFT-7201A-U2 SW PWB
 204 SFT-8901A-U2 LED PWB
