JVC LT-32DA8BJ Service Manual

3-10(No.YA509)
D9514 FR105GT-T3 SI DIODE
D9515 TL431/A/-T IC
D9516 MTZJ16B-T2 Z DIODE
D9517 MTZJ16B-T2 Z DIODE
D9518 1SS355W-X DIODE
D9519 UDZW3.0B-X Z DIODE
D9520 1SS355W-X DIODE
D9522 FMX-G22S SI DIODE
 C9001 QFZ9084-224 MPP CAPACITOR 0.22uF
 C9002 QFZ9084-224 MPP CAPACITOR 0.22uF
 C9003 QCZ9078-222 C CAPACITOR 2200pF AC250V M
 C9004 QCZ9078-222 C CAPACITOR 2200pF AC250V M
 C9005 QCZ9078-222 C CAPACITOR 2200pF AC250V M
 C9007 QCZ9071-102 C CAPACITOR 1000pF AC400V M
 C9008 QCZ9071-102 C CAPACITOR 1000pF AC400V M
C9205 QCB32HK-103 C CAPACITOR 0.01uF 500V K
C9206 QEHR1HM-105Z E CAPACITOR 1uF 50V M
C9207 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9208 NCB31HK-222X C CAPACITOR 2200pF 50V K
 C9209 QCZ9071-471 C CAPACITOR 470pF AC400V K
C9210 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9211 QECR1AM-128Z E CAPACITOR 1200uF 10V M
C9212 QECR1AM-477Z E CAPACITOR 470uF 10V M
C9215 QEHR1HM-476Z E CAPACITOR 47uF 50V M
C9216 QEHR1HM-476Z E CAPACITOR 47uF 50V M
C9217 QEHR1HM-476Z E CAPACITOR 47uF 50V M
C9222 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C9501 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9502 QEHR1HM-225Z E CAPACITOR 2.2uF 50V M
C9503 NCB31HK-102X C CAPACITOR 1000pF 50V K
C9504 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9505 NCB31HK-272X C CAPACITOR 2700pF 50V K
C9506 QCZ0340-821 C CAPACITOR 820pF 2kV K
C9507 QEZ0866-227 E CAPACITOR 220uF
C9508 QFP32JK-332 PP CAPACITOR 3300pF 630V K
C9509 QEHR1HM-107Z E CAPACITOR 100uF 50V M
 C9512 QCZ9071-471 C CAPACITOR 470pF AC400V K
C9518 QECR2AM-156Z E CAPACITOR 15uF 100V M
C9519 QEZ0849-128 E CAPACITOR 1200uF
C9520 QEZ0849-128 E CAPACITOR 1200uF
C9521 QEZ0849-128 E CAPACITOR 1200uF
C9522 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9523 QEZ0848-188 E CAPACITOR 1800uF
C9526 QECQ1EM-228 E CAPACITOR 2200uF 25V M
C9527 QECR1EM-227Z E CAPACITOR 220uF 25V M
C9528 QECR1VM-477Z E CAPACITOR 470uF 35V M
C9529 QEHR1HM-105Z E CAPACITOR 1uF 50V M
C9530 NCB31HK-222X C CAPACITOR 2200pF 50V K
 R9001 QRZ0107-474Z C RESISTOR 470k Ω 1/2W K
R9205 QRE121J-224Y C RESISTOR 220k Ω 1/2W J
R9206 QRE121J-471Y C RESISTOR 470 Ω 1/2W J
R9207 NRSA63J-474X MG RESISTOR 470k Ω 1/16W J
R9208 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
 R9209 QRZ9046-825Z C RESISTOR 8.2M Ω 1/2W K
R9210 NRSA63J-182X MG RESISTOR 1.8k Ω 1/16W J
R9211 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R9212 NRSA63J-561X MG RESISTOR 560
Ω 1/16W J
R9213 NRSA63D-103X MG RESISTOR 10k Ω 1/16W D
R9214 NRSA63J-820X MG RESISTOR 82
Ω 1/16W J
R9215 NRSA63D-332X MG RESISTOR 3.3k
Ω 1/16W D
R9501 NRS12BJ-564W MG RESISTOR 560k Ω 1/2W J
R9502 NRS12BJ-564W MG RESISTOR 560k Ω 1/2W J
R9503 NRSA63J-332X MG RESISTOR 3.3k
Ω 1/16W J
R9504 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R9505 QRK126J-101X UNF C RESISTOR 100
Ω 1/2W J
R9506 QRT029J-R27 MF RESISTOR 0.27
Ω 2W J
R9507 QRT029J-R27 MF RESISTOR 0.27
Ω 2W J
R9508 NRSA63J-332X MG RESISTOR 3.3k
Ω 1/16W J
R9509 QRL039J-220 OMF RESISTOR 22
Ω 3W J
R9510 QRE121J-564Y C RESISTOR 560k
Ω 1/2W J
 R9512 QRE121J-220Y C RESISTOR 22 Ω 1/2W J
R9513 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R9514 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R9515 QRG01GJ-821 OMF RESISTOR 820 Ω 1W J
R9517 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R9518 NRSA63D-273X MG RESISTOR 27k
Ω 1/16W D
R9519 NRSA63J-152X MG RESISTOR 1.5k Ω 1/16W J
R9520 NRSA63D-332X MG RESISTOR 3.3k Ω 1/16W D
R9521 NRSA63J-182X MG RESISTOR 1.8k
Ω 1/16W J
R9525 NRSA63J-822X MG RESISTOR 8.2k Ω 1/16W J
R9526 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R9527 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R9528 QRL029J-182 OMF RESISTOR 1.8k
Ω 2W J
R9529 QRL029J-104 OMF RESISTOR 100k
Ω 2W J
R9531 NRS12BJ-102W MG RESISTOR 1k Ω 1/2W J
R9532 NRSA63J-822X MG RESISTOR 8.2k
Ω 1/16W J
R9533 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R9534 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
 Ref No. Part No. Part Name Description Local
 L9001 QQR1764-001 CHOKE COIL
L9201 QQL26AM-5R6Z CHOKE COIL 5.6uH M
L9502 QQL26AM-5R6Z CHOKE COIL 5.6uH M
L9503 QQL26AM-5R6Z CHOKE COIL 5.6uH M
L9504 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
 T9202 QQS0394-001 SW TRANSF
 T9501 QQS0391-001 SW TRANSF
 CP9201 QMFZ052-2R0Z-E FUSE 2A
 CP9501 QMFZ049-5R0Z-E FUSE 5A 125V
 CP9503 ICP-N70-T IC PROTECTOR 2.5A
 CP9504 ICP-N70-T IC PROTECTOR 2.5A
 CP9505 ICP-N70-T IC PROTECTOR 2.5A
 CP9506 QMFZ043-5R0Z-J1 FUSE 5A AC250V
 F9001 QMF5AD2-6R3-J1 FUSE 6.3A AC250V
 LF9002 QQR1281-004 LINE FILTER
 LF9003 QQR1514-001 LINE FILTER
 PC9202 PS2581AL1/QW/ PHOTO COUPLER
 PC9501 PS2581AL1/QW/ PHOTO COUPLER
 PC9502 PS2581AL1/QW/ PHOTO COUPLER
 VA9001 QAF0060-621 VARISTOR 620V
 Ref No. Part No. Part Name Description Local
