JVC LT-32DA8BJ Service Manual

1-2 (No.YA509)
SPECIFICATION
Design & specifications are subject to change without notice.
Items
Contents
LT-26A80SU
LT-26A80ZU
LT-26DA8SU
LT-26DA8ZU
LT-26DA8BJ
LT-26DA8SJ
LT-26DT8ZJ
Dimensions ( W × H × D ) 67.2 cm × 51.9 cm × 23.0 cm [Included stand]
67.2 cm × 47.1 cm × 10.7 cm [TV only]
Mass 11.2 kg [Included stand]
10.4 kg [TV only]
11.6 kg [Included stand]
10.8 kg [TV only]
Power Input AC220V - AC240 V, 50 Hz
Power Consumption 105 W (Standby: 1.6 W) 116 W (Standby: 1.6 W)
TV RF System Analog CCIR (B/G, I, D/K, L) CCIR (I)
Digital --- DVB-T
Colour System PAL,
SECAM,
NTSC 3.58/4.43 [EXT only]
PAL,
NTSC 3.58/4.43 [EXT only]
Stereo System NICAM (B/G, I, D/K, L), A2 (B/G, D/K) NICAM (I)
Receiving
Frequency
Analog VHF: 47MHz - 470MHz
UHF: 470 MHz - 862 MHz
CATV: 116MHz - 172MHz / 220MHz - 469MHz
UHF: 470 MHz - 862 MHz
Digital --- UHF:
177.5 MHz - 858 MHz UHF: 474 MHz - 850 MHz
Intermediate
Frequency
VIF 38.9MHz (B/G, I, D/K, L) 38.9MHz (I)
SIF 33.4MHz (5.5MHz :B/G)
32.9MHz (6.0MHz :I)
32.4MHz (6.5MHz :D/K)
32.9MHz (6.0MHz :I)
Colour Sub
Carrier
Frequency
PAL 4.43MHz
SECAM 4.40625MHz / 4.25MHz ---
NTSC 3.58MHz / 4.43MHz
Teletext System Analog FLOF (Fastext level 2.5)
TOP
WST(World Standard system)
FLOF (Fastext level 2.5)
WST(World Standard system)
Digital --- EBU TEXT MHEG 5 UK profile
LCD panel 26V-inch wide aspect (16 : 9)
Screen Size Diagonal : 66 cm (H: 57.6 cm × V: 32.4 cm)
Display Pixels Horizontal : 1366 dots × Vertical : 768 dots (W-XGA)
Audio Power Output 6 W + 6 W
Speaker 5.0 cm × 12.0 cm, oval type × 2
Aerial terminal (VHF/UHF) 75 Ω unbalanced, coaxial
EXT-1 / EXT-2 (Input / Output) 21-pin Euro connector (SCART socket ) × 2
EXT-3 (Input) Component Video
750p / 1125i
625p / 525p / 625i / 525i
Audio
RCA pin jack × 3
Y : 1 V (p-p) (Sync signal: ±0.35V(p-p), 3-value sync.), 75Ω
Pb/Pr : ±0.35V(p-p), 75 Ω
Y : 1 V (p-p), Positive (Negative sync.), 75 Ω
Cb/Cr : 0.7V(p-p), 75 Ω
500 mV(rms) (-4dBs), high impedance, RCA pin jack × 2
EXT-4 / EXT-5
(HDMI Input)
Video/Audio HDMI 2-row 19pin connector × 2
(Digital-input terminal is not compatible with picture signals of personal computer)
Digital Audio Optical Output --- Digital SPDIF × 1
Headphone 3.5 mm stereo mini jack × 1
Remote Control Unit RM-C1508
(AA/R6 dry cell battery × 2)
RM-C1821
(AA/R6 dry cell battery × 2)
