JVC LT-32DA8BJ Service Manual

1-20 (No.YA509)
4.6 INITIAL SETTING VALUES IN THE SERVICE MODE
• Perform fine-tuning based on the "initial values" using the remote control when in the Service mode.
• The "initial values" serve only as an indication rough standard and therefore the values with which optimal display can be achieved
may be different from the default values.
• Never change the values of the items( ) that are not described in ADJUSTMENT PROCEDURE or in the below table as they
are fixed values.
4.6.1 ADJUSTMENT MODE
Item name Variable range Setting value
1. SC ADJ. 0 - 1023 ---
2. R DRIVE 0 - 1023 920
3. G DRIVE 0 - 1023 920
4. B DRIVE 0 - 1023 920
5. CUTOFF R 0 - 1023 0
6. CUTOFF G 0 - 1023 0
7. CUTOFF B 0 - 1023 0
Item name Input signal Variable range
Setting value
26 inch models 32 inch models
8. COLOUR Other
0 - 63
31 30
SECAM 20 20
NTSC 33 33
480i / 480p(Component/HDMI) 41 41
576i / 576p(Component/HDMI) 40 41
720p / 1080i(Component/HDMI) 38 40
9. HUE Other
0 - 63
30 31
SECAM 32 32
NTSC 28 30
480i / 480p(Component/HDMI) 32 28
576i / 576p(Component/HDMI) 31 30
720p / 1080i(Component/HDMI) 32 28
10. CONTRAST Other
0 - 63
43 43
NTSC 43 43
Component/HDMI 37 37
11. BRIGHT Other
0 - 511
266 259
NTSC 263 263
Component/HDMI 268 272
12. SHARP Other
-3 - +3
0 0
NTSC 0 0
480i / 480p(Component/HDMI) 0 0
576i / 576p(Component/HDMI) +2 +2
720p / 1080i(Component/HDMI) +3 +3
