JVC LT-32EX19/AT User Manual

(No.YA702<Rev.005>)1-13
119 SDI I Data for external flash memory
120 CS O Chip select for external flash memory
121 RESET I CPU reset [Reset=L]
122 VCCQ10 - 1.05V power supply
123 SCK O Clock for external flash memory
124 GOIO23/CSIO1_RTS/
UART1_RTS/
UART3_TXD
- Not used
125 GOIO24/CSIO1_CTS/
UART1_CTS/
UART3_RXD
- Not used
126 SDITDO O Data for external flash memory
127 SDITDI I Data for external flash memory
128 SDITCK I Clock for external flash memory
129 VCCQ10 - 1.05V power supply
130 SDVDD - 3.3V power supply
131 VCCQ33 - 3.3V power supply
132 SDITRST I Reset for external flash memory
133 SDITMS I Mode select for external flash memory
134 GPIO00/MFT0A/MFT1B/
PWD0
O DC dimming control for back-light inverter
135 GPIO01/MFT1A/MFT0B/
PWD1
O
PWM dimming control for back-light inverter
136 GPIO02/MFT2A/MFT7B/
UART2_TXD
O Power on/off control for back-light [60Hz=H]
137 GPIO03/MFT3A/MFT2B/
UART2_RXD
I Headphone detect [Detect=H]
138 GPIO04/MFT4A/MFT3B/
CSIO2_TXD
O Power on/off control for LCD [ON=L]
139 GPIO05/MFT5A/MFT4B/
CSIO2_RXD
I Remote control sensor input
140 GPIO06/MFT6A/MFT5B/
CSIO2_SCLK
O Rest for HDMI-3
141 GPIO07/SCL0 O Clock for I2C bus (EEPROM)
142 GPIO10/_SDA0 I/O Data for I2C bus (EEPROM)
143 VCCQ10 - 1.05V power supply
144 GPIO11/SCL1 O Clock for I2C bus (fro tuner/audio/HDMI)
145 GPIO12/SDA1 I/O Data for I2C bus (fro tuner/audio/HDMI)
146 HDIN(PC) I H sync for PC
147 VDIN(PC) I V sync for PC
148 VCCQ33 - 3.3V power supply
149 PLLSAVDD - 3.3V power supply
150 SDVDD - 3.3V power supply
151 PLLDVDD - 3.3V power supply
152 PLLMAVDD - 3.3V power supply
153 ADIN4/INPUT04/
CSIO_CTS/UART0_CTS
I AFT voltage for VHF/UHF tuner
154 ADIN3/INPUT03 I Key scan for side control (Input/Vol+/Vol-)
155 ADIN2/INPUT02/INT2 I Key scan for side control (Power/ CH+/
CH-/Menu)
156 ADIN1/INPUT01/INT1 - Not used
157 ADIN0/INPUT00/INT0 I Power abnormality detection [Emer-
gent=H]
158 MAVDD - 3.3V power supply
159 SSIN1 I Y sync input
160 SSIN2 - Not used
161 VINFB - Not used
162 DGND - GND
163 ADCVDDA18 - 1.8V power supply
164 VIN1A I PC G for input-PC
165 ADCVSSA - GND
166 VIN2A I Y for input-1
167 ADCVDDA18 - 1.8V power supply
168 VVIN3A - Not used
169 ADCVSSA - GND
170 VREFA I Reference voltage setting
171 ADCVDDA33 - 3.3V power supply
Pin Pin name I/O Function
172 AVSSSL - GND
173 AVDDSL - 3.3V power supply
174 ADCVDDMX33 - 3.3V power supply
175 ADCVDDMX18 - 1.8V power supply
176 REXT I For external resistor
177 VRP I Reference voltage setting
178 VRM I Reference voltage setting
179 ADCVSSMX - GND
180 ADCVDDB18 - 1.8V power supply
181 VIN1B I PC B for input-PC
182 ADCVSSB - GND
183 VIN2B I Pb for input-1
184 ADCVDDB18 - 1.8V power supply
185 VIN3B - Not used
186 ADCVSSB - GND
187 VREFB I Reference voltage setting
188 ADCVDDB33 - 3.3V power supply
189 ADCVDDC18 - 1.8V power supply
190 VIN1C I PC R for input-PC
191 ADCVSSC - GND
192 VIN2C I Pr for input-1
193 ADCVDDC18 - 1.8V power supply
194 VREFC I Reference voltage setting
195 ADCVSSC - GND
196 ADCVDDC33 - 3.3V power supply
197 PLL1VDD33A - 3.3V power supply
198 LPF1 I LPF setting for PLL
199 PLL1VSS33A - GND
200 PLL1VDDD - 3.3V power supply
201 PLL1VSSD - GND
202 VCCQ10 - 1.05V power supply
203 ETXOUT4P - Not used
204 ETXOUT4M - Not used
205 ETXOUT3P O LVDS data for LCD panel
206 ETXOUT3M O LVDS data for LCD panel
207 ETXCLKOUTP O LVDS data for LCD panel
208 ETXCLKOUTM O LVDS data for LCD panel
209 VDD33LVDS - 3.3V power supply
210 ETXOUT2P O LVDS data for LCD panel
211 ETXOUT2M O LVDS data for LCD panel
212 VSS33LVDS - GND
213 ETXOUT1P O LVDS data for LCD panel
214 ETXOUT1M O LVDS data for LCD panel
215 ETXOUT0P O LVDS data for LCD panel
216 ETXOUT0M O LVDS data for LCD panel
