4.4.6 VSM PRESET MODE
This mode is used to adjust the VSM.
4.4.6.1 HOW TO ENTER THE VSM PRESET MODE
When the SERVICE MENU SCREEN of SERVICE MODE is
displayed, press [6] key to enter the VSM PRESET MODE.
4.4.6.2 DESCRIPTION OF STATUS DISPLAY
(1) SETTING ITEM NAME
Setting item name are displayed.
(2) PICTURE MODE
The picture mode name are dispalayed.
(3) SETTING VALUE (DATA)
The setting values are displayed. The setting value to be
displayed are listed below.
4.5 INITIAL SETTING VALUES IN THE SERVICE MODE
• Perform fine-tuning based on the "initial values" using the remote control when in the Service mode.
• The "initial values" serve only as an indication rough standard and therefore the values with which optimal display can be achieved
may be different from the default values.
• <S004> to <S009> are the off set values.
4.5.1 ADJUSTMENT MODE [LT-32EX19/AT, LT-32EX19/
MAT, LT-32EX19/PAT, LT-32EX19/SAT]
Note: " ∗ " Adjustable range is -256 ~ 00 only and one colour(R
or G or B) should be "00"
4.5.2 ADJUSTMENT MODE [LT-32EX19/BT, LT-32EX19/
BBT, LT-32EX19/EBT, LT-32EX19/NBSK, LT-32EX19/
MBT, LT-32EX19/PBT, LT-32EX19/RBCK, LT-32EX19/
SBT, LT-32EX19/VBSK, LT-32EX29/NBSK]
Note: " ∗ " Adjustable range is -256 ~ 00 only and one colour(R
or G or B) should be "00"
SERVICE MODE SCREEN
Press [6] key
(1)SETTING ITEM
(2)PICTURE MODE
(3)
SETTING VALUE (DATA)
VSM PRESET MODE SCREEN
SERVICE MENU Ver.XXX
1. ADJUST
2. SELF CHECK
3. I2C STOP
VSM PRESET
Back Light Soft XX
Contrast Soft XX
Bright Soft XX
Sharp Soft XX
Colour Soft XX
Tint Soft XX
Back Light Bright XX
Contrast Bright XX
Bright Bright XX
Sharp Bright XX
Colour Bright XX
Tint Bright XX
Back Light Standard XX
Contrast Standard XX
Bright Standard XX
Sharp Standard XX
Colour Standard XX
Tint Standard XX
Back Light Game mode XX
Contrast Game mode XX
Bright Game mode XX
Sharp Game mode XX
Colour Game mode XX
Tint Game mode XX
Soft Bright Standard
Game mode
Back Light 16 32 24 16
Contrast 16 18 16 16
Bright 16 16 16 16
Sharp 16201616
Colour 16 16 16 16
Tint 16 16 16 16
Item No. Item name Variable range Setting value
S001 R DRIVE MID 0000 - 0255 ∗
S002 G DRIVE MID 0000 - 0255 ∗
S003 B DRIVE MID 0000 - 0255 ∗
S004 R DRIVE COOL 0000 - 0255 -150
S005 G DRIVE COOL 0000 - 0255 -35
S006 B DRIVE COOL 0000 - 0255 00
S007 R DRIVE WARM 0000 - 0255 00
S008 G DRIVE WARM 0000 - 0255 -32
S009 B DRIVE WARM 0000 - 0255 -140
Item No. Item name Variable range Setting value
S001 R DRIVE MID 0000 - 0255 ∗
S002 G DRIVE MID 0000 - 0255 ∗
S003 B DRIVE MID 0000 - 0255 ∗
S004 R DRIVE COOL 0000 - 0255 -157
S005 G DRIVE COOL 0000 - 0255 -33
S006 B DRIVE COOL 0000 - 0255 00
S007 R DRIVE WARM 0000 - 0255 00
S008 G DRIVE WARM 0000 - 0255 -20
S009 B DRIVE WARM 0000 - 0255 -120
