JVC LT-32EX19/AT - Digital P.w. Board Assy

!REF. PART No. PART NAME DESCRIPTION
D9602 HSU119-X SI DIODE
D9603 HSU119-X SI DIODE
D9701 SJPB-L4-X SB DIODE
D9702 SJPB-L4-X SB DIODE
D9703 PTZ6.8B-X Z DIODE
!C9001 QFZ9072-474 MM CAPACITOR 0.47µF AC250V K
!C9002 QFZ9072-474 MM CAPACITOR 0.47µF AC250V K
!C9003 QCZ9078-222 C CAPACITOR 2200pF AC250V M
!C9004 QCZ9078-222 C CAPACITOR 2200pF AC250V M
!C9005 QCZ9078-222 C CAPACITOR 2200pF AC250V M
!C9007 QCZ9071-102 C CAPACITOR 1000pF AC400V M
!C9008 QCZ9071-102 C CAPACITOR 1000pF AC400V M
C9501 QEZ0867-337 E CAPACITOR 330uF
C9502 QFP32JK-332 PP CAPACITOR 3300pF 630V K
C9503 QCZ0364-561 C CAPACITOR 560pF 2kV K
C9504 NCB31HK-102X C CAPACITOR 1000pF 50V K
C9505 QEHR1HM-107Z E CAPACITOR 100µF 50V M
C9506 QEHR1HM-107Z E CAPACITOR 100µF 50V M
C9507 QEHR1HM-106Z E CAPACITOR 10µF 50V M
C9508 NCB31HK-103X C CAPACITOR 0.01µF 50V K
!C9509 QCZ9071-102 C CAPACITOR 1000pF AC400V M
!C9512 QCZ9071-102 C CAPACITOR 1000pF AC400V M
C9514 NCB31HK-104X C CAPACITOR 0.1µF 50V K
C9517 QCB32HK-682 C CAPACITOR 6800pF 500V K
C9520 QEZ0849-128 E CAPACITOR 1200uF
C9521 QEZ0849-128 E CAPACITOR 1200uF
C9522 QEZ0849-128 E CAPACITOR 1200uF
C9523 QECR1VM-477Z E CAPACITOR 470µF 35V M
C9524 NCB31CK-563X C CAPACITOR 0.056µF 16V K
C9601 NCB31HK-222X C CAPACITOR 2200pF 50V K
C9603 QEHQ1VM-228 E CAPACITOR 2200µF 35V M
C9705 QECR1EM-687Z E CAPACITOR 680µF 25V M
C9706 NCB31HK-104X C CAPACITOR 0.1µF 50V K
C9708 QECR1VM-337Z E CAPACITOR 330µF 35V M
C9709 NCB31HK-103X C CAPACITOR 0.01µF 50V K
C9710 NCB31HK-102X C CAPACITOR 1000pF 50V K
C9804 QECR1VM-477Z E CAPACITOR 470µF 35V M
!R9001 QRZ0107-474Z C RESISTOR 470k¯ 1/2W K
!R9005 QAD0141-4R0 N THERMISTOR 4¯
R9501 QRE121J-154Y C RESISTOR 150k¯ 1/2W J
R9502 QRZ0237-R18 UNF WW RESISTOR 0.18¯ 3W J
R9503 QRT029J-R27 MF RESISTOR 0.27¯ 2W J
R9504 NRSA02J-0R0X MG RESISTOR 0¯ 1/10W J
R9505 NRSA63J-472X MG RESISTOR 4.7k¯ 1/16W J
R9506 NRSA63J-473X MG RESISTOR 47k¯ 1/16W J
R9507 QRE121J-473Y C RESISTOR 47k¯ 1/2W J
!R9508 QRZ9017-470 FUSI RESISTOR 47¯ 1/4W J
R9509 NRSA63J-473X MG RESISTOR 47k¯ 1/16W J
!R9510 QRZ9046-825Z C RESISTOR 8.2M¯ 1/2W K
R9511 NRSA63J-473X MG RESISTOR 47k¯ 1/16W J
R9512 QRL039J-220 OMF RESISTOR 22¯ 3W J
R9513 NRSA63J-102X MG RESISTOR 1k¯ 1/16W J
R9514 NRSA63J-102X MG RESISTOR 1k¯ 1/16W J
R9517 NRSA63J-682X MG RESISTOR 6.8k¯ 1/16W J
R9518 NRSA63D-273X MG RESISTOR 27k¯ 1/16W D
R9519 NRSA63D-152X MG RESISTOR 1.5k¯ 1/16W D
R9520 NRSA63D-332X MG RESISTOR 3.3k¯ 1/16W D
R9524 NRSA63J-472X MG RESISTOR 4.7k¯ 1/16W J
R9525 NRSA63D-912X MG RESISTOR 9.1k¯ 1/16W D
R9526 NRSA63D-821X MG RESISTOR 820¯ 1/16W D
R9527 NRSA63D-822X MG RESISTOR 8.2k¯ 1/16W D
R9551 NRSA63J-471X MG RESISTOR 470¯ 1/16W J
R9552 NRSA63J-562X MG RESISTOR 5.6k¯ 1/16W J
R9553 NRSA63J-102X MG RESISTOR 1k¯ 1/16W J
R9555 QRL039J-121 OMF RESISTOR 120¯ 3W J
R9604 NRSA63J-822X MG RESISTOR 8.2k¯ 1/16W J
R9605 NRSA63J-102X MG RESISTOR 1k¯ 1/16W J
R9606 NRSA63J-822X MG RESISTOR 8.2k¯ 1/16W J
R9607 NRSA63J-102X MG RESISTOR 1k¯ 1/16W J
L9503 QQLZ026-140 COIL 14uH
L9504 QQLZ026-140 COIL 14uH
L9701 QQR1827-001 CHOKE COIL
!T9501 QQS0444-001 SW TRANSF
!CP9501 ICP-N75-T IC PROTECTOR 2.7A
!CP9502 ICP-N75-T IC PROTECTOR 2.7A
!CP9506 QMFZ043-5R0Z-J1 FUSE 5A AC250V
!F9001 QMF5AD2-6R3-J1 FUSE 6.3A AC250V
K9505 QQR0621-002Z FERRITE BEADS
!REF. PART No. PART NAME DESCRIPTION
K9702 QQR1113-001Z FERRITE BEADS
K9703 QQR0621-002Z FERRITE BEADS
K9704 QQR0621-002Z FERRITE BEADS
K9705 QQR0621-002Z FERRITE BEADS
!LF9002 QQR1281-004 LINE FILTER
!LF9003 QQR1514-001 LINE FILTER
!PC9501 PS2581AL1/QW/ PHOTO COUPLER
!VA9001 QAF0060-621 VARISTOR 620V
DIGITAL P.W. BOARD ASS'Y
[0][D]
!REF. PART No. PART NAME DESCRIPTION
IC6001 R2A15112FP-X IC
IC6002 BH3547F-X IC
IC6003 MC4558CD-X IC
IC6661 NJU26123VC2-X IC
IC6771 AK4384ET-X IC
IC7001 R8J66619FP IC
IC7002 ATF64-32EX19RB IC (SERVICE)
IC7003 25VF080B32EX19B IC(MICRO C ROM) (SERVICE)
IC7004 TC7WH08FU-X IC
IC7005 S-80928CLNB-G-W IC
IC9201 MM1689AH-X IC
IC9231 MM1663DH-X IC
IC9251 SI-8015Q-X IC
IC9401 SI-8005Q-X IC
IC9501 PQ090DNA1Z-X IC
IC9601 SI-8005Q-X IC
Q6104 2SC1623A/5-6/-X TRANSISTOR
Q6105 2SC1623A/5-6/-X TRANSISTOR
Q6501 2SA812A/5-6/-X TRANSISTOR
Q6503 2SC1623A/5-6/-X TRANSISTOR
Q7003 2SA812A/5-6/-X TRANSISTOR
Q7004 2SA812A/5-6/-X TRANSISTOR
Q7005 2SA812A/5-6/-X TRANSISTOR
Q7006 2SA812A/5-6/-X TRANSISTOR
Q7007 SSM3K02F-X MOS FET
Q7008 2SC1623A/5-6/-X TRANSISTOR
Q9702 2SC1623A/5-6/-X TRANSISTOR
Q9703 2SC1623A/5-6/-X TRANSISTOR
Q9704 2SC1623A/5-6/-X TRANSISTOR
Q9705 2SC1623A/5-6/-X TRANSISTOR
D6301 RKZ5.1B2KG-X Z DIODE
D6501 HSU119-X SI DIODE
D6502 HSU119-X SI DIODE
D6503 HSU119-X SI DIODE
D6504 HSU119-X SI DIODE
D6505 HSU119-X SI DIODE
D7004 RKZ5.6B2KG-X Z DIODE
D7005 RKZ5.6B2KG-X Z DIODE
D7006 RKZ5.6B2KG-X Z DIODE
D7007 RKZ5.6B2KG-X Z DIODE
D7008 RKZ5.6B2KG-X Z DIODE
D7009 RKZ5.6B2KG-X Z DIODE
D7010 RKZ5.6B2KG-X Z DIODE
D7011 RKZ5.6B2KG-X Z DIODE
D7012 RKZ5.6B2KG-X Z DIODE
D7013 RKZ5.6B2KG-X Z DIODE
D7014 RKZ5.6B2KG-X Z DIODE
D7015 RKZ5.6B2KG-X Z DIODE
D7016 RKZ5.6B2KG-X Z DIODE
D7018 RKZ5.6B2KG-X Z DIODE
D7019 RKZ5.6B2KG-X Z DIODE
D9251 EC30QSA045-X SB DIODE
D9252 EC30QSA045-X SB DIODE
D9401 EC30QSA045-X SB DIODE
D9402 EC30QSA045-X SB DIODE
D9403 PTZ16B-X Z DIODE
D9404 HSU119-X SI DIODE
D9601 EC30QSA045-X SB DIODE
D9602 EC30QSA045-X SB DIODE
D9603 PTZ6.8B-X Z DIODE
D9604 HSU119-X SI DIODE
D9705 RKZ3.0B2KG-X Z DIODE
