JVC LT-32EX19/AT User Manual

(YA702-R005) 3
Title Line No.YA702<Rev.004> No.YA702<Rev.005> Description
115 -
Speaker
4.0 cm × 16.0 cm, oval type × 2
116 -
Aerial terminal (VHF/UHF)
75 Ω unbalanced, coaxial
117 -
Video / Audio
Input-1/2
Component Video
750p / 1125i
625p / 525p / 625i / 525i
RCA pin jack × 3
Y : 1V (p-p) (Sync signal: ±0.35V(p-
p), 3-value sync.), 75 Ω / Pb/Pr :
±0.35V(p-p), 75 Ω
Y : 1V (p-p), Positive (Negative sync
provided), 75 Ω / Pb/Pr : 0.7V(p-p), 75
Ω
118 -
Video
1V (p-p), Positive (Negative sync
provided), 75 Ω, RCA pin jack × 2
119 -
Audio
500mV (rms), High impedance, RCA
pin jack × 4
120 -
PC (RGB) Input
Video
D-sub 15 pin × 1
R/G/B : 0.7 V (p-p), 75Ω
HD / VD : 1 V (p-p) to 5 V (p-p), high
impedance
< Available signal >
VGA : 640 pixels × 480 pixels
(Horizontal : 31.5 kHz / Vertical : 60
Hz)
XGA : 1024 pixels × 768 pixels
(Horizontal : 48.4 kHz / Vertical : 60
Hz)
121 -
Audio
3.5 mm stereo mini jack × 1
122 -
HDMI Input
Video
HDMI connector × 3(Digital-input
terminal is not compatible with picture
signals of computer signal)
123 -
Audio
Digital: HDMI connector × 3
Analog: 500mV(rms) (-4dBs), high
impedance, RCA pin jack × 2 [HDMI-
1]
124 -
Video / Audio Output
Video
1V (p-p), Positive (Negative sync
provided), 75 Ω, RCA pin jack × 1
125 -
Audio
500mV (rms), Low impedance, RCA
pin jack × 2
126 -
Headphone
3.5 mm stereo mini jack × 1
127 -
Remote Control Unit
RM-C2020 (AAA/R6 dry cell battery ×
2)
