1-8 (No.MB515)
SECTION 3
DISASSEMBLY
3.1 Main body
3.1.1 Removing the metal cover
(See Fig.1, 2)
(1) Remove the six screws A attaching the metal cover. (See
Fig.1)
(2) Remove the two screws B attaching the metal cover. (See
Fig.2)
Fig.1
Fig.2
A
L
A
A
J
K
A
A
B
